The shell name is xilinx_u200_xdma_201830_1.
• Timestamp (-t):
DSA package installed in system:
xilinx_u200_xdma_201830_1,[TS=0x000000005bece8e1],[BMC=3.1]
The timestamp is 0x000000005bece8e1.
For the example output above, the xbutil flash command is:
sudo /opt/xilinx/xrt/bin/xbutil flash -a xilinx_u200_xdma_201830_1 -t
0x000000005bece8e1 -d 0
When the Alveo card is successfully flashed, the xbutil flash scan output will show the
same package information for both DSA package installed in FPGA: and DSA package
installed in system:.
IMPORTANT! Use a separate
UG1301 (v1.3) February 12, 2019
Getting Started with Alveo Accelerator Cards
Appendix C: Generating the xbutil flash Command
xbutil flash command to flash each card in the system.
