Card Bring-Up and Validation

After installing the XRT and deployment shell, the card installation can be verified using the

following commands, which are explained in more detail below.

• lspci

• xbutil flash scan

• xbutil validate

The lspci Linux commad was previously used in

hardware was installed correctly. In this section, lspci and the Xilinx

to validate a successful hardware and software setup.

The second and third commands use the xbutil utility, which is included during the XRT

package installation. This utility includes multiple commands to validate and identify the installed

card(s) and report additional card details including DDR, PCIe

information. See SDx Command and Utility Reference Guide (UG1279) for a complete list of

xbutil command options and definitions along with debug information.

Set the environment to use the xbutil utility by running the following command. Note that the

command is dependent on the shell you are using.

Use the following command in csh shell:

$ source /opt/xilinx/xrt/setup.csh

Use the following command in bash shell:

$ source /opt/xilinx/xrt/setup.sh

Running lspci

1. Enter the following command:

$ sudo lspci -vd 10ee:

UG1301 (v1.3) February 12, 2019

Getting Started with Alveo Accelerator Cards
