Xilinx Alveo U200 Getting Started Manual page 14

IMPORTANT! Ne débranchez pas le connecteur auxiliaire d'alimentation des cartes Alveo™ pendant
qu'elles sont sous-tension ("hot-plug" n'est pas autorisé).
Wichtig! Trennen Sie den Alveo™-Stromanschluss Karten Alveo im eingeschalteten Zustand nicht (Hot-
Plug ist nicht zulässig).
The following procedure is a guide for the Xilinx
installation. Consult your computer documentation for additional information.
1. Host power supply must be powered off.
2. For enclosed computers, open your computer by removing the casing.
3. If necessary, remove the two adjacent PCIe
slot in which you are installing the Alveo card.
4. Plug the Alveo card in the PCIe x16 slot on the motherboard.
5. Plug AUX Connector after the card has been inserted in PCIe
mechanically fixed (with the click).
IMPORTANT! Operation of the Alveo™ cards only with AUX Connector is not allowed.
IMPORTANT! Le fonctionnement des cartes Alveo™ uniquement avec le connecteur auxiliaire n'est
pas autorisé.
Wichtig! Der Betrieb von Alveo™-Karten nur mit AUX Connector ist nicht zulässig.
The card has an 8-pin female PCIe Aux Power Connector.
For actively cooled cards, connect the power cable to the Aux power connector at top of the
card as shown in the following figure.
UG1301 (v1.3) February 12, 2019
Getting Started with Alveo Accelerator Cards
Chapter 3: Card Installation Procedures
® Alveo™ Data Center accelerator card
® x16 slot covers corresponding to the PCIe x16
® slot, ensure the plug is
