• For an 8-pin connector, connect the power supply to the card.
• For a 6-pin connector, connect the power supply to the card using the six rightmost pins
of the card's 8-pin power supply socket, leaving the two leftmost pins unused, as
identified by the red box in the following figures.
UG1301 (v1.3) February 12, 2019
Getting Started with Alveo Accelerator Cards
Example of 8-Pin PCIe Aux Power Connector
Figure 6:
Example of 6-Pin PCIe Aux Power Connector
Figure 7:
