Spectrum Industries 37386 Assembly Instructions

Assembly Instructions Assembly Instructions
Assembly Instructions Assembly Instructions
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt.
To report information regarding missing parts or damage, to purchase parts
or accessories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
PART# QTY
021538 8 #8 x 1/2" PHTS
Styrene angle
0160915 2 w/ adhesive
1.25" x 1.25" x 4"
0192395 2 3/4" x 3/4" Cable holder
058423 6 5-1/2" Cable tie
0192178 1 6" Driver adapter
0192179 1 12 volt power supply
12" RGB F to M
0192180 1
cable link
0192181 1 Plus shape connector
LED Controller
0192182 1
and RF Remote
72" Interconnection
0192183 2
cable
0192272 2 6" Interconnection cable
0192265 4 4" RGB LED Tape light
Important
ITEM
LED Lighting Kit for Shoutcaster LED Lighting Kit for Shoutcaster

1. Remove accent / side panels (if installed)

1. Remove the accent / side panels by removing
the 4mm JC bolts inside unit.
r
c k e
B a
e l
p a n
Accent / side panel
37386 37386
r
c k e
B a
e l
p a n
Accent / side panel
0192437 Page 1 of 4
4mm
