Assembly Instructions
Assembly Instructions
Assembly Instructions
Assembly Instructions
Important
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt.
To report information regarding missing parts or damage, to purchase parts
or accessories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
(1) Worksurface
(1) 0152138
Cord channel
front
(1) 0152137
Cord channel
bottom
(1) 0151223
Left Leg
0151838
Meta worksurface
0151201
Shadow
worksurface
(1) 0151801
Worksurface
support beam
(1) 0154472
Support panel
(1) 0151501
Right Leg
Esports Meta Desk - 37335
Esports Meta Desk - 37335
Esports Shadow Desk - 37339
Esports Shadow Desk - 37339
Hardware
(6) 0100167
8-32 x 1/2" PH
Thrd ctg
(9) 038064
#14 x 3/4" PHSM
(1) 021521
10-24 Keps nut
(1) 025069
Glide Wrench
(1) 0152128
Mid bracket
Note: Do not tighten fasteners completely until all have been installed.
Keeping them loose will help with alignment during assembly.
3
/
"
8
(3) 035728
1/4-20 x 1/2"
PHMS
(3) 037542
#8 X 5/8" PHSM
(4) 037779
5/16-18 x 1"
Glide
(1) 0150570
Headset
hanger
0192095 Page 1 of 4
Advertisement
Table of Contents
Related Manuals for Spectrum Industries Esports Meta 37335
Summary of Contents for Spectrum Industries Esports Meta 37335
- Page 1 Assembly Instructions Assembly Instructions Assembly Instructions Assembly Instructions Important Before you begin, read and comply with all safety and operating instructions, and ensure all parts and correct quantities are included. Any parts damaged during shipment must be reported within 5 days of receipt. To report information regarding missing parts or damage, to purchase parts or accessories, or if you have any questions, please contact us.
- Page 2 1. Assemble worksurface 1. Assemble worksurface 1. Place the worksurface laminate side-down onto a non-abrasive surface like a carpeted floor. Figure 1. 2. Install the mid bracket as shown with (1) #14 x 3/4” PHSM screw. (1) #14 x 3/4” PHSM Mid bracket Figure 1...
- Page 3 4. Attach cord channel 4. Attach cord channel 1. Align the cord channel front with the leg holes and mid bracket as shown. Figure 4.1. Secure with (2) 8-32 x 1/2” PH thread-cutting screws and (1) 10-24 Keps nut at the mid bracket. 8-32 x 1/2”...
- Page 4 925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM 925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM © 2020 Spectrum Industries Inc., All rights reserved. 0192095 Page 4 of 4...
