Assembly Instructions
Assembly Instructions
Assembly Instructions
Assembly Instructions
Important
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt.
To report information regarding missing parts or damage, to purchase parts
or accessories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
37372 - Starter
Note: When multiple desks are attached together in
rows, the starter kit installs on the leftmost desk.
(2) 0159066
Side acrylic
divider 30"W
x 24"H
(1) 0159072
Rear acrylic
divider 44"W
x 24"H
(2) 0192262
Tape disk
.045" x 1.5" dia
(2) 0159148
Bracket
(4) 0101382
#14 x 7/8"
PHSM
Acrylic Divider Panels for
Acrylic Divider Panels for
Evolution Esports Desk
Evolution Esports Desk
Starter - 37372
Starter - 37372
Adder - 37373
Adder - 37373
37373 - Adder
(1) 0159066
Side acrylic
divider 30"W
x 24"H
(1) 0159072
Rear acrylic
divider 44"W
x 24"H
(2) 0192262
Tape disk
.045" x 1.5" dia
(1) 0159150
Bracket
(1) 0159149
Bracket
(1) 0159166
Bracket
(2) 0190174
#8 x 3/8"
PHSM
0192314 Page 1 of 5
Advertisement
Table of Contents
Related Manuals for Spectrum Industries Starter 37372
Summary of Contents for Spectrum Industries Starter 37372
- Page 1 Assembly Instructions Assembly Instructions Assembly Instructions Assembly Instructions Important Before you begin, read and comply with all safety and operating instructions, and ensure all parts and correct quantities are included. Any parts damaged during shipment must be reported within 5 days of receipt. To report information regarding missing parts or damage, to purchase parts or accessories, or if you have any questions, please contact us.
- Page 2 1. Attach 0159148 bracket to worksurface 1. Attach 0159148 bracket to worksurface 2. Attach rear divider 2. Attach rear divider 1. Attach the bracket to the left side of the worksurface with (2) #14 x 1. Loosen the (2) chair rail screws and pull the chair rail away from the 7/8”...
- Page 3 4. Attach divider at seam 4. Attach divider at seam Adder(s) and row of connected desks required - (skip to step 5 if no adders) Adder(s) and row of connected desks required - (skip to step 5 if no adders) Note: Repeat this step for each additional desk using adder components.
- Page 4 5. Attach 0159148 bracket to worksurface 5. Attach 0159148 bracket to worksurface 6. Attach right side divider 6. Attach right side divider 1. Attach the bracket to the right side of the worksurface with (2) #14 x 1. Insert the side divider tabs into the right rear divider slots and push 7/8”...
- Page 5 Page 1 of 1 925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM 925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM © 2020 Spectrum Industries Inc., All rights reserved. 0192314 Page 5 of 5...
