SPEAKERS
System Sensor offers a wide range of power settings for your life safety needs,
including ¼, ½, 1, and 2W.
Sound levels data per UL 1480 can be found in Table 1.
FIGURE 4. SPEAKER WATTAGE AND VOLTAGE SETTINGS
TABLE 1. SOUND LEVELS FOR EACH TRANSFORMER POWER SETTING
Setting UL Reverberant (dBA @10 ft)
¼ W 77
½ W 80
1 W 83
2 W 86
TABLE 2. DIRECTIONAL SOUND CHARACTERISTICS
Angle (degrees) Decibels
+/- 50-degrees
+/- 95-degrees
Signal levels exceeding 130% rated signal voltage can damage the speaker.
Consequently, an incorrect tap connection may cause speaker damage. This
means that if a 25V tap is selected when a 70.7V amplifier is being used,
speaker damage may result. Therefore, be sure to select the proper taps for the
amplifier voltage/input power level combination being used.
UL Anechoic (dBA @10 ft)
79
82
85
88
-3dB
-6dB
CAUTION
STROBES
FIGURE 5. CANDELA SELECTOR
FIGURE 6. LIGHT OUTPUT - VERTICAL DISPERSION, CEILING TO WALLS
TO FLOOR
A0593-00
Minimum light output requirements per UL1971
Percent
Degrees* of Rating
0 100
5-25 90
30-45 75
50 55
60 45
65 35
70 35
75 30
80 30
85 25
90 25
TABLE 3. CEILING-MOUNT STROBE CURRENT DRAW (mA)
Current Draw
Candela
18-17.5 Volts
15
30
75
95
115
150
177
*NOTE: Products set at 15 and 30 candela automatically work on either 12V
or 24V power supplies. The products are not listed for 12V DC operation when
set to any other candela settings.
3
Candela Setting
15 30 75 95 115
15 30 75 95 115
13.5 27.0 67.5 85.5 103.5
11.3 22.5 56.3 71.3 86.3
8.3 16.5 41.3 52.3 63.3
6.8 13.5 33.8 42.8 51.8
5.3 10.5 26.3 33.3 40.3
5.3 10.5 26.3 33.3 40.3
4.5 9.0 22.5 28.5 34.5
4.5 9.0 22.5 28.5 34.5
3.8 7.5 18.8 23.8 28.8
3.8 7.5 18.8 23.8 28.8
Current Draw (mA)
(mA)
16–33 Volts
DC DC FWR
87 41 60
153 63 86
- 111 142
- 134 164
- 158 191
- 189 228
- 226 264
A0486-01
A0468-00
150 177
150 177
135.0 159.3
112.5 132.8
82.5 97.4
67.5 79.7
52.5 62.0
52.5 62.0
45.0 53.1
45.0 53.1
37.5 44.3
37.5 44.3
