Evaluation kit contents

The STM8S touch sensing evaluation kit (STM8/128-EV/TS) contains:
STM8S touch sensing evaluation daughterboard (STM8Sxxx-TS1)
STM8/128-EVAL board
AC/DC power supply and its AC adaptors
MCU selection guide
User manual (this document)
IMPORTANT: The STM8 TS library, STM8 Toolset, STM8S firmware library and related
documentation are available at www.st.com/touch-sense-sw-lib

Using the evaluation kit

After connecting the motherboard to the mains supply, the evaluation kit is ready for use.
Just use the joystick to navigate through the menu options as described in
interface.
The evaluation firmware enables the user to quickly evaluate the main features of the touch
sensing library.
Figure 2. TS evaluation kit assembly
Motherboard
SWIM connector
Power supply
Daughterboard
LCD display
Reset
Doc ID 15330 Rev 4
UM0671
Section 2.3: User
Pre-programmed
STM8S sample
Exit sub-menu
Scroll right
Scroll left
Enter sub-menu
Joystick
