Installation and User Guide
VideoEdge™ 4-Channel IP Encoder
Version 1.02
Part Number 8200-0806-00 C0

Advertisement

Table of Contents
loading

Related Manuals for American Dynamics VideoEdge

Summary of Contents for American Dynamics VideoEdge

  • Page 1 Installation and User Guide VideoEdge™ 4-Channel IP Encoder Version 1.02 Part Number 8200-0806-00 C0...
  • Page 2 San Diego, CA 92121-2903 U.S.A. Customer Service Thank you for using American Dynamics products. We support our products through an extensive worldwide network of dealers. The dealer through whom you originally purchased this product is your point of contact if you need service or support.

  • Page 3: Rack Mounting

    Warnings To Reduce Risk of electric shock, do not remove cover. no user serviceable parts inside. refer servicing to qualified service personnel. Do not expose this appliance to rain or moisture. Do not install this product in hazardous areas where highly combustible or explosive products are stored or used.

  • Page 4: License Information

    License Information READ THIS LICENSE AGREEMENT BEFORE OPENING THE DISK PACKAGE, INSTALLING THE SOFTWARE, OR USING YOUR SYSTEM. THIS LICENSE AGREEMENT DEFINES YOUR RIGHTS AND OBLIGATIONS. BY BREAKING THE SEAL ON THIS PACKAGE, INSTALLING THE SOFTWARE, OR USING YOUR SYSTEM, YOU AGREE TO ALL OF THE TERMS AND CONDITIONS OF THIS AGREEMENT.
  • Page 5 the date of delivery to the first user. Sensormatic further warrants that for the same period, the software provided on the recording medium under this license will substantially perform as described in the user documentation provided with the product when used with the specified hardware. CUSTOMER REMEDIES Sensormatic's entire liability and your exclusive remedy under this warranty will be, at Sensormatic's option, to a).
  • Page 6 Installation and User Guide...

  • Page 7: Table Of Contents

    Event Input Configuration ........3-22 Saving the IP Encoder configuration ....... 3-24 Canceling configuration changes.
  • Page 8 Resetting the IP Encoder ......... . 4-1 Restoring factory defaults on the IP Encoder ......4-1 Technical specifications Rear panel connectors .
  • Page 9 List of Procedures Procedure 3-1 Logging in to the IP Encoder ......3-2 Procedure 3-2 Checking camera feeds using the Live Video function ..3-6 Procedure 3-3 Controlling dome cameras on the live video page .
  • Page 10 Table of Contents Installation and User Guide...

  • Page 11: Introduction

    Overview The VideoEdge™ IP Encoder (hereafter referred to as IP Encoder) offers high performance IP video streams for up to four analog video sources. The IP Encoder is specifically designed for security video which produces compressed video that is up to nine times more efficient than MPEG-4 and MJPEG products.

  • Page 12: Features

    Figure 1-2 Example of an IP Encoder in a full system installation Figure 1-2 shows an example system configuration where the IP Encoder is installed as part of a full Intellex IP Network. In this example the IP Encoder is connected to the Intellex through a network switch.

  • Page 13: Acc Compression

    Bandwidth Throttling The IP Encoder supports bandwidth throttling and is set on a individual camera and client basis. The maximum bandwidth is selectable between 30 kb/s and 4 Mb/s. The Bandwidth throttling is configured on the Intellex IP.

  • Page 14: Advanced Features

    • Philips/Bosch Auto Dome • Pelco Matrix • BBV StarCard • Cyberscan-I Web Configuration IP Encoder’s web configuration page allows you to configure settings and view live video. Refer to page 3-1, Web Configuration for more information. Installation and User Guide...

  • Page 15: Installation

    PoE networks that are connected to IP Encoders should not be routed to the exterior or outside of the installed plant location. The method of installing the IP Encoder will vary depending on the type of IP Encoder, i.e Power over Ethernet (PoE) or Power Supply (PS), and the network configuration of the installation environment.

  • Page 16: Installation Method A - Pre-Configuration

    PoE injector/splitter using a Connect power to the PoE injector/splitter Open a browser window and enter the IP address of the IP Encoder 192.168.1.80 Refer to Section 3, Web Configuration, and configure the following settings on the IP Encoder:...

  • Page 17: Installation Method B- Post Installation-Configuration

    Using the Intellex Setup and User Manuals, configure any other required advanced features. Note When using installation method B only 1 IP Encoder, with the default settings, should be powered up and added to the network at a time. Note: If Video feeds are available...
  • Page 18 Installation Installation and User Guide...

  • Page 19: Web Configuration

    This section details how to configure the Intellex IP Video Encoder using the built in Web Configuration feature. The Web Configuration configures the IP Encoder as a standalone device before it has been connected to the Ethernet network or Intellex IP. It can also be accessed using the Intellex IP and a Network Client.

  • Page 20: Login To The Ip Encoder

    The main Login page will be displayed as shown in Figure 3-1. Note If any alarms or warnings are present on the IP Encoder then these will also be displayed on the login page, an example is shown in Figure 3-2.
  • Page 21 3 Enter the appropriate User Login Name and Password, then select Login. Depending on the access rights of the user, the IP Encoder will display either the Administrator or the User front page. Both options are described on the following pages.

  • Page 22: User Front Page

    The options available to the User are: • Live Video — Allows the testing of the attached Analog cameras by viewing live video; • Refresh — Provides a method of updating the System Status of the IP Encoder; • Logout.

  • Page 23: Administrator's Front Page

    • Live Video — Allows the testing of the attached Analog cameras by viewing live video; • Configuration — Configures the IP Encoder; • Backup Config — Allows the IP Encoder configuration to be saved to a data file; • Update Firmware — Allows the IP Encoder firmware to be updated;...

  • Page 24: Checking Camera Feeds Using Live Video Function

    Procedure 3-2 Checking camera feeds using the Live Video function 1 Login to the IP Encoder using an appropriate username and password, for more details refer to Login to the IP Encoder on page 3-2. 2 Select Live Video from the IP Encoder Front Page.

  • Page 25: Controlling Dome Cameras On The Live Video Page

    Live Video page. Changing these settings does not affect the video being sent by the IP Encoder to the Intellex IP. 7 Select Front Page to return to the IP Encoder Front Page or Logout to exit the screen. Controlling dome cameras on the Live Video page Dome cameras may be controlled using the on screen controls in the video windows once the Video Inputs and camera Control Configuration settings have been completed.

  • Page 26: Procedure 3-3 Controlling Dome Cameras On The Live Video Page

    Web Configuration Procedure 3-3 Controlling dome cameras on the live video page 1 Click in the camera’s pane. 2 Click the control item on the overlay. Pan/Tilt control Zoom Iris Iris Zoom Focus Pan/Tilt Movement Flips the camera 180° Closes the dome control overlay (Exit) Opens the dome configuration menu...

  • Page 27: Pattern And Preset Camera Controls

    Controlling the Pan-Tilt Control via Mouse Procedure 3-4 Controlling dome Pan-Tilt via a mouse using the Live Video page 1 Select in the camera’s pane. 2 Float the cursor over the center of the video pane. The Cursor Origin Mark 3 Click and drag the cursor to set the direction and speed, then release.

  • Page 28: Procedure 3-6 Selecting A Dome Pattern Using The Live Video Page

    Web Configuration Selecting a Pattern Procedure 3-6 Selecting a dome pattern using the Live Video page 1 Click to open the Primary Camera Control menu. 2 Click Pattern for the pattern menu: 3 Select a pattern number. 4 Click to run the pattern once or 5 Click Exit to close the Pattern menu.

  • Page 29: Configuring A Dome Camera

    4 Click to move the camera to the preset position. 5 Click to close the Preset menu. 6 Click to close the Primary Camera Control menu. Defining a Preset Procedure 3-9 Defining a dome preset using the Live Video page 1 Click to open the Primary Camera Control menu.

  • Page 30: Configuring The Ip Encoder

    Web Configuration Configuring the IP Encoder The main configuration page of the IP Encoder contains all the settings necessary to configure the IP Encoder. The configured items are: • System • Security • TCP/IP Network • Video Inputs • Serial Ports •...

  • Page 31: Figure 3-6 Configuration Main Page

    Web Configuration Figure 3-6 Configuration Main page 3-13...

  • Page 32: System (Changing The Default Language Selection)

    The language will only change once the configuration has been saved and a new browser session opened. 5 If all the required changes have been made to the IP Encoder configuration then select Save Config to ensure all changes have been saved. Refer to Procedure 3-19 for more information on saving configuration changes.

  • Page 33: Security (Adding Or Editing User Accounts)

    Security (adding or editing user accounts) The Security settings in the IP Encoder allow for the addition of new users and the editing or deletion of existing users. The two levels of user access available are Administrator and View Video Only.

  • Page 34: Figure 3-9 Add/Edit User Page

    The default setting is Disabled for new user accounts. 7 Select Done to return to the main security detail page, as shown in Figure 3-8 8 If all users have been added or updated then select Done to return to the IP Encoder Main Configuration page.

  • Page 35: Configuring The Tcp/Ip Settings

    Figure 3-10 TCP/IP configuration page 3 The Server Name is the network name given to the IP Encoder on the TCP/IP network. The default Server Name is the product name, e.g. ADIPE4-, followed by the last 6 digits of the MAC address.

  • Page 36: Configuring The Serial Ports

    9 Select Done to return to the IP Encoder Main Configuration page. 10 If all the required changes have been made to the IP Encoder configuration then select Save Config to ensure all changes have been saved. Refer to Procedure 3-19 for more information on saving configuration changes.

  • Page 37: Figure 3-11 Serial Port Detail Page

    Procedure 3-15 Configuring the serial ports 1 Ensure that the browser is displaying the Configuration page (if not refer to Procedure 3-11). 2 From within the Serial Port section select the Edit button of the first serial port to be configured. A Serial Port detail page is displayed, as shown in Figure 3-11.

  • Page 38: Configuring Sensornet

    There can be only one Master device on the Sensornet network. Note If the IP Encoder is the first or last device on the Sensornet network the Sensornet terminator switch, located on the back of the IP Encoder, must be set to ON.

  • Page 39: Configuring The Video Inputs

    Configuring the Video Inputs The Video Input Detail page allows the configuration of the video format and the camera control protocol for each attached camera. When using 4 CIF the video is automatically deinterlaced to give a better quality on motion. The Serial ports and Sensornet configurations should be completed before the Video Input configuration, as detailed in Procedure 3-17.

  • Page 40: Event Input Configuration

    Event Input Configuration The Event Input feature is used to set triggers on the IP Encoder which are activated by a change in state of the attached device. An example of an Event Input could be the use of a door sensor, which, when the door is opened, triggers an event on the IP Encoder which in turn can be monitored by the Intellex IP to start recording on the associated video input at a higher rate.
  • Page 41 8 Once all the Event Inputs have been configured and all the required changes have been made to the IP Encoder configuration then select Save Config to ensure all changes have been saved. Refer to Procedure 3-19 for more information on saving configuration changes.

  • Page 42: Saving The Ip Encoder Configuration

    Saving the IP Encoder configuration If any of the IP Encoder configuration settings have been changed, the IP Encoder configuration must be saved. Once the configuration has been saved the IP Encoder should be restarted to use the saved settings.

  • Page 43: Canceling Configuration Changes

    You can cancel your configuration changes before they are saved (as shown in Procedure 3-19). Canceling your changes will revert the IP Encoder to the last saved configuration. Procedure 3-20 details the steps required to cancel any changes to the configuration.
  • Page 44 Web Configuration 3 Select Discard Changes to cancel the changes to the configuration and return to the IP Encoder Front page. Note Selecting Return To Config will keep the changes to the configuration and display the Main Configuration Page. 3-26 Installation and User Guide...

  • Page 45: Backing Up The Configuration

    Backing up the configuration The configuration settings of the IP Encoder can be backed up to a data file. The data file can be saved to a specified location and used to restore the IP Encoder configuration. Procedure 3-21 details the steps required to Backup the configuration to a data file.

  • Page 46: Restoring Configuration From A Data File

    Web Configuration Restoring configuration from a data file The IP Encoder has the ability to Restore its configuration from a previously saved configuration file. Procedure 3-22 details steps required to complete loading the configuration from a saved file. Procedure 3-22 Restoring configuration from a data file 1 Ensure that the browser is displaying the Main Configuration page (if not refer to Procedure 3- 11).

  • Page 47: Upgrading Or Downgrading The Firmware

    In order to achieve optimal system performance it is highly recommended that your Intellex IP is running the most recent version of software available on the American Dynamics product website. Procedure 3-23 details the steps required to change the firmware of the IP Encoder.

  • Page 48: Figure 3-19 Firmware Upgrade Page

    Web Configuration 4 Enter the name of the FUP (including network path) to be used, or select Browse and use the file browser to locate and select the FUP. 5 Select Update Firmware. The Firmware Update Process page is displayed, as shown in Figure 3-20. Figure 3-20 Firmware Updating Progress page 3-30 Figure 3-19 Firmware Upgrade page...

  • Page 49: Figure 3-21 Firmware Update Complete Page

    7 Once the IP Encoder has restarted complete Procedure 3-22 to restore the configuration from the configuration backup file. Note Upgrading the firmware will result in the IP Encoder’s IP address being reset to the factory default of 192.168.1.80 with the default login username Administrator and password MERLIN. Web Configuration...
  • Page 50 Web Configuration 3-32 Installation and User Guide...

  • Page 51: Restoring Factory Defaults

    Restoring the factory default will result in all saved configuration settings being removed and the IP Encoder will be restored with the factory settings. 1 Ensure that power is being applied to the IP Encoder, this can be from either a power supply or an ethernet cable using PoE.
  • Page 52 Restoring factory defaults Installation and User Guide...

  • Page 53: Technical Specifications

    This section details the pin assignments of the serial connectors, the environmental and operating specifications of the IP Encoder. Rear panel connectors Terminal block Figure 5-1 Rear panel connectors Front panel connectors & LEDs Ethernet Port Figure 5-2 Front panel connectors & LEDs Note 1: The Video/Alarm LED is not used in this release except during a firmware or configuration upgrade process and during the Power On Self Test (POST).

  • Page 54: Led Status Descriptions

    Technical specifications LED status descriptions Power LED • On with repeating slow short flashes off – Normal operation • Rapidly flashing – Invalid stored configuration / operating on factory defaults Client LED • On – operating normally with 1 or more clients connected •...

  • Page 55: Rs-232 Com Ports

    Table 5-1 — Terminal block connector pin assignments Description RS-422 Tx + / RS-485 Tx + RS-422 Tx - / RS-485 Tx - RS-422 Rx + RS-422 Rx - Sensornet + Sensornet - Event In 1 Event Out 1 Event In 2 RS-232 Com ports Figure 5-4 RS-232 Com ports 1 to 8 pin assignments Table 5-2 —...

  • Page 56: Technical Specifications

    Technical specifications Technical Specifications Table 5-3 — Technical Specifications Category Power Physical Network Serial Ports Video Events Specification Supply voltage 12VDC and Power over Ethernet Connector 2.5mm and POE on RJ45 Consumption 12W max. (1.0 A at 12 VDC) Environment Operating —...

  • Page 57: Certification And Regulations

    Certification and Regulations Table 5-4 — Certification and Regulations Category Safety Canada Europe Australia / New Zealand RoHS Complies with European directive 2002/95/EC Specification UL60950-1 CSA C22.2 No. 60950-1 EN60950-1 IEC60950-1 FCC Part 15 class A ICES-003/NMB-003 class A EN55022 class A EN50130-4 AS/NZS CISPR22 Technical specifications...
  • Page 58 Technical specifications Installation and User Guide...

  • Page 59: Index

    Administrator Front Page 3-5 Advanced Features 1-4 Backup configuration 3-27 Bandwidth Throttling 1-3 Camera Feeds 3-6 Canceling configuration changes 3-25 Compression 1-3 Configuration restoring 3-28 Configuration saving 3-24 Connections 1-2 Dome camera Focus functions 3-8 Iris functions 3-8 Pan/Tilt Movement functions 3-8 Zoom functions 3-8 Dome Configuration Menu 3-11 Features 1-2...
  • Page 60 Index Installation and User Guide...
