List of Defined Protocols allows for selecting a test
protocol for the current test session (refer to the Additional
Information document for more details about protocols).
Temporary setup allows for making temporary changes to
the selected protocol. The changes will be valid for the
current session only. After making the changes and returning
to the main screen, the name of the protocol will be followed
by an asterisk (*).
List of historical sessions accesses historical sessions for
review or the Current Session.
The historical session box can be expanded by dragging
downwards with the mouse or minimized/maximized by
clicking on the arrow button.
The session highlighted in orange, is the selected session
displayed on screen. Check the checkbox next to the session
date to overlay historic sessions on the graph.
Go to current session takes you back to the current
session.
Probe status is shown by a colored bar with description next
to it.
When the probe status is Out of ear it will show the color of
the selected ear (blue for left and red for right). When the
probe is detected to be In ear the color is green. When
Blocked, Leaking or Too Noisy the colored bar is amber.
When No probe is detected the status bar is grey.
Forced Start can be used to force an OAE measurement to
start if the probe status is not indicating 'in ear', e.g. when
testing patients with PE tubes. Forced Start is activated by
pressing the icon or by long pressing the Start / Spacebar /
button on shoulder box for 3 seconds.
Note: when using forced start, the stimulus level is based on
the probe's calibration values in a 711 coupler and not on the
individual ear's volume.
Summary view toggles between displaying result graph or
result graph with test summary tables.
Monaural/Binaural view toggles between showing the
results of a single ear or both ears.
Report editor button opens a separate window for adding
and saving notes to the current or historic session.
Checking the Acceptable noise level Off box disables the
rejection of any recording even when there is too much noise
in the recording.
The Acceptable noise level slider allows setting the
acceptable noise level limit between -30 and +30 dB SPL
above which recordings are considered to be too noisy. The
VU meter indicates the current noise level and becomes
amber in color when exceeding the set level.
