Table 10: Expansion Connector "A" Pin Definitions (J3) - pandaboard OMAP 4 Series System Reference Manual

J3 OMAP
Pin #
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
OMAP
Primary Function
Ball #
--- VIO_1V8
--- DC_5V
B16 GPMC_AD7
AH23 MCSPI1_CS3
A16 GPMC_AD6
AH19 UART4_TX
D15 GPMC_AD5
AG20 UART4_RX
C15 GPMC_AD4
AF23 MCSPI1_CS1
D13 GPMC_AD3
AG22 MCSPI1_SIMO
C13 GPMC_AD2
AG23 MCSPI1_CS2
D12 GPMC_AD1
AE23 MCSPI1_CS0
C12 GPMC_AD0
AE22 MCSPI1_SOMI
B12 GPMC_NWE
AF22 MCSPI1_CLK
B11 GPMC_NOE
D19 GPMC_AD15
AH22 I2C4_SDA
AG21 I2C4_SCL
--- REGEN1
E7 SYS_NRESPWRON
--- DGND
--- DGND

Table 10: Expansion Connector "A" Pin Definitions (J3)

TM
4 PandaBoard System
Reference Manual
Secondary
Function
--- 1.8V I/O Power
--- 5Vdc Input Power
SDMMC2_DAT7 GPMC Address/Data Bit 7
GPIO_140 SPI1 Chip Select 3 (also UART1_RTS)
SDMMC2_DAT6 GPMC Address/Data Bit 6
GPIO_156 UART4 Transmit Data
SDMMC2_DAT5 GPMC Address/Data Bit 5
GPIO_155 UART4 Receive Data
SDMMC2_DAT4 GPMC Address/Data Bit 4
GPIO_138 SPI1 Chip Select 1 (also UART1_RX)
SDMMC2_DAT3 GPMC Address/Data Bit 3
GPIO_136 SPI1 Slave In Master Out
SDMMC2_DAT2 GPMC Address/Data Bit 2
GPIO_139 SPI1 Chip Select 2 (also UART1_CTS)
SDMMC2_DAT1 GPMC Address/Data Bit 1
GPIO_137 SPI1 Chip Select 0
SDMMC2_DAT0 GPMC Address/Data Bit 0
GPIO_135 SPI1 Slave Out Master In
SDMMC2_CMD GPMC Write Enable
GPIO_134 SPI1 Clock Out
SDMMC2_CLK GPMC Output Enable
GPIO_39 GPMC Address/Data Bit 15
GPIO_133 I2C4 Serial Data
GPIO_132 I2C4 Serial Clock
--- TWL6030 REGEN1
--- Power On Reset
--- Digital Ground
--- Digital Ground
Revision 0.4
September 22, 2010
DOC-21010
Description of PandaBoard Usage
Page 43 of 83
