Table 6: Lcd Expansion Connector "A" Pin Definitions (J1) - pandaboard OMAP 4 Series System Reference Manual

Pin#
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
OMAP
Signal
1 DC_5V
2 DC_5V
3 EXP_DSS_DAT1
4 EXP_DSS_DAT0
5 EXP_DSS_DAT3
6 EXP_DSS_DAT2
7 EXP_DSS_DAT5
8 EXP_DSS_DAT4
9 EXP_DSS_DAT12
10 EXP_DSS_DAT10
11 EXP_DSS_DAT23
12 EXP_DSS_DAT14
13 EXP_DSS_DAT19
14 EXP_DSS_DAT22
15 H_I2C2_SDA
16 EXP_DSS_DAT11
17 EXP_DSS_VSYNC
18 H_DPM_EMU2
19 GND
20 GND

Table 6: LCD Expansion Connector "A" Pin Definitions (J1)

Pin# Signal
1 VDD_VAUX2
2 VIO_1V8
3 DVI_DATA20
4 DVI_DATA21
5 DVI_DATA17
6 DVI_DATA18
7 DVI_DATA15
8 DVI_DATA16
9 DVI_DATA7
10 DVI_DATA13
11 DVI_DATA8
12 NUSB_PWR
13 DVI_DATA9
14 I2C2_SCL
TM
4 PandaBoard System
Reference Manual
I/O
PWR DC rail from the Main DC supply
PWR DC rail from the Main DC supply
I LCD Pixel Data bit 1
I LCD Pixel Data bit 0
I LCD Pixel Data bit 3
I LCD Pixel Data bit 2
I LCD Pixel Data bit 5
I LCD Pixel Data bit 4
I LCD Pixel Data bit 12
I LCD Pixel Data bit 10
I LCD Pixel Data bit 23
I LCD Pixel Data bit 14
I LCD Pixel Data bit 19
I LCD Pixel Data bit 22
I/O I2C2 Serial Data
I LCD Pixel Data bit 11
I LCD Vertical Sync Signal
I DPM_EMU2/GPIO_13
PWR Ground bus
PWR Ground bus
I/O Description
PWR Power rail (adjustable from 1.2V to 2.8V)
PWR 1.8V system I/O voltage
I LCD Pixel Data bit 20
I LCD Pixel Data bit 21
I LCD Pixel Data bit 17
I LCD Pixel Data bit 18
I LCD Pixel Data bit 15
I LCD Pixel Data bit 16
I LCD Pixel Data bit 7
I LCD Pixel Data bit 13
I LCD Pixel Data bit 8
O No connect
I LCD Pixel Data bit 9
I I2C2 Serial Clock
Revision 0.4
September 22, 2010
DOC-21010
Description
Page 34 of 83
