7.3.6

MB1352_CN6 DisplayPort

Pin number
1
3
4
6
7
9
10
12
7.3.7

PORT1 MB1352_CN7 USB Type-C

Pin number
A1
A2
UM2783 - Rev 1
™

sink connector

Figure 28. MB1352_CN6 DisplayPort
Table 43. MB1352_CN6 DisplayPort
Description
LANE3_N
LANE3_P
LANE2_N
LANE2_P
LANE1_N
LANE1_P
LANE0_N
LANE0_P
®

connector

Figure 29. PORT1 MB1352_CN7 USB Type-C
Table 44. PORT1 MB1352_CN7 USB Type-C
Description
GND
TX1+
Connectors on UCPD daughterboard (MB1352)
™
sink connector (front view)
™
sink connector
Pin number
13 CONFIG1
14 CONFIG2
15 AUX_CH_P
17 AUX_CH_N
18 HPD (PB5)
19 RETURN
20 DP_PWR
2,5,8,11,16 GND
®
connector (front view)
®
connector
Pin number
B1 GND
B2 TX2+
UM2783
Description
Description
page 42/59
