Mb1351_Cn2 Smartcard Connector; Mb1351_Cn3 Hdmi Source Connector; Table 37. Mb1351_Cn2 Smartcard Connector; Figure 21. Mb1351_Cn2 Smartcard Connector (Top View) - ST STM32G0C1E-EV User Manual

7.2.2

MB1351_CN2 smartcard connector

Pin number
1
2
3
4
17
7.2.3

MB1351_CN3 HDMI source connector

UM2783 - Rev 1
Figure 21. MB1351_CN2 smartcard connector (top view)
1
5
Table 37. MB1351_CN2 smartcard connector
Description
VCC
RST
CLK
NC
Card presence detection pin
Figure 22. MB1351_CN3 HDMI source connector (front view)
Connectors on the legacy peripheral daughterboard (MB1351)
2 3 4
17 18
6 7 8
Pin number
5 GND
6 NC
7 I/O
8 NC
18 Card presence detection pin
UM2783
Description
page 38/59
