ESAB Eye-Tech 10-12 Select Instructions page 2

2
1
Spare Parts List
1 - Front Lens Frame ..................................... 15F05
2 - Front Cover Lens (10 pcs) ........................ 15F09
3 - Shade Cartridge ....................................... 15F21
4 - Rear Cover Lens (20 pcs) ........................ 15F10
5 - Eccentric Knob ......................................... 15F08
6 - Head Band ............................................... 15F03
7 - Sweat Band .............................................. 14F04
8 - Helmet (without shade cartridge) .............. 15F01
9 - Helmet Complete ...................................... 15F20
To remove front lens frame
grasp bottom and pull upward; to
replace, reverse process.
After removing frames, insert front
cover lens into frame.
Use only P/N 15F09 front cover
lens. Replace front lens frame.
To replace shade cartridge, push
shade cartridge outwards from
the upper inside rim. To put back,
reverse process.
F-15-432 12/97
4
3
Part
Number
A two-year warranty from the date of manufacture is given against
defects arising from faulty workmanship or materials. No war-
ranty is given against defects arising from misuse, unauthorized
interference with parts or use of the appliance which was not
intended by the manufacturer.
Printed in U.S.A.
5
9 8
Magnifying Lens
- Diopter +0 ........................................................ 15F11
- Diopter +1.5 .................................................... 15F12
- Diopter +2.0 .................................................... 15F13
- Diopter +2.5 .................................................... 15F14
To replace rear cover
lens, place a small
screwdriver in groove
and pull out lens.
To adjust angle of
helmet, turn
Eccentric knob.
To adjust headband, set
upper adjusting strap as
low as possible.
Warranty
7
ACCESSORIES
Push in knob (at back of
headband) and turn. It
will then click into
position.
Loosen locking-nuts and
adjust distance from eyes.
Adjust both sides at the same
time. Make sure helmet
remains straight.
The sweatband for the
forehead is removable
and washable.
