Smart programming of consecutive addresses

Make sure the button configuration (single/dual) is correct before proceeding with programming (see
"Configure button type
Take note of the DIP-switch
settings
1
ON
1 2 3 4
example:
code 1
4
= 2
+1
6
S1 S2
7
18
(single/dual)")
LL
2
Set the address of the
apartment you wish
5 6 7 8
to call (for example: 1)
using the DIP-
switches
(see "Addressing
table" )
= 3
+1
Reset the configuration of the
DIP-switches
8
3
=
5
= 4
+1
S1 S2
1
Press the button you
want to associate with
the call address set
using the DIP-switches
= 5
+1
Press the following
buttons to assign
consecutive
addresses.
When programming is
complete, make sure the
button configuration is
correct (single/dual), see
"Configure button type
(single/dual)")
