NXR-ILM08C-EIT

Related Manuals

Manual
NXR-series
IO-Link Master Unit for
EtherNet/IP TM
User's Manual
NXR-series
IO-Link I/O Hub
User's Manual
NJ/NX-series CPU Unit
Built-in EtherNet/IP TM Port
User's Manual
CS/CJ-series
EtherNet/IP TM Units
Operation Manual
Sysmac Studio Version 1
Operation Manual
NJ/NX-series Instructions
Reference Manual
IO-Link Sensor Index List
Sysmac is a trademark or registered trademark of OMRON Corporation in Japan and other countries for OMRON factory automation products.
Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United Status and/or other countries.

EtherCAT is a registered trademark and patented technology, licensed by Beckhoff Automation GmbH, Germany.
EtherNet/IP TM is a trademark of ODVA.
Other company names and product names in this document are the trademarks or registered trademarks of their respective companies.
20
Cat. No Model
W619 NXR-ILM08C-EIT
W620 NXR-@@@@@@-IL@
NX701-@@@@
NJ501-@@@@
NJ301-@@@@
W506
NJ101-@@@@
NX102-@@@@
NX1P2-@@@@
CS1W-EIP21
CJ1W-EIP21
W465
CJ2H-CPU6@-EIP
CJ2M-CPU3@
W504 SYSMAC-SE2@@@
NX701-@@@@
NJ501-@@@@
NJ301-@@@@
W502
NJ101-@@@@
NX102-@@@@
NX1P2-@@@@
9541795-1 E3Z-@8@-IL@
9540292-0 E2E(Q)-@-IL@
9539397-1 E3S-DCP21-IL@
Application
Learning how to use an NXR-
series IO-Link Master Unit for
EtherNet/IP.
Learning how to use an NXR-
series IO-Link I/O Hub.
Using the built-in EtherNet/IP
port on an NJ/NX-series CPU
Unit.
Using the CS/CJ-series
EtherNet/IP Unit.
Learning about the operating
procedures and functions of the
Sysmac Studio.
Learning detailed specifications
on the basic instructions of an
NJ/NX-series CPU Unit.
Learning the vendor IDs, device
IDs, I/O data (process data),
and objects (service data).
Description
Describes the hardware, setup
methods, and functions of the NXR-
series IO-Link Master Unit for
EtherNet/IP.
Describes the hardware, setup
methods, and functions of the NXR-
series IO-Link I/O Hub.
Information on the built-in
EtherNet/IP port is provided.
Information is provided on the basic
setup, tag data links, and other
features.
Provides information on operating
and installing CS/CJ-series
EtherNet/IP Units, including details
on basic settings, tag data links,
and FINS communications.
Describes the operating
procedures of the Sysmac Studio.
The instructions in the instruction
set (IEC 61131-3 specifications)
are described.
Describes the following details for
OMRON's IO-Link sensors.
• IO-Link physical layer
• Device IDs
• Process data
• Service data
• Event functions
