3. POWER ON, CONTROLS AND INDICATORS

Do not turn the amplifier on for at least 2 hours after unpacking it in the room where it
will be used. Pay particular attention when you move it from a very cold into a warm
place - condensation is likely and this could result in damage to the high voltage circuits.
In such a case, wait at least 4 hours. A similar effect can occur after a rapid warming of
the operating room (for instance after switching on a powerful heater in a cold shack).
To avoid damage (not covered under warranty) carefully check that the voltage for
which the amplifier is set corresponds to your mains nominal voltage (see Section
Line Voltage Selection
After following all instructions in Section
the front panel (see

Figure 3-1 ACOM 1010 Display and Control

illuminate:
Note that the upper LED bar-graph always reads peak forward power, except for the
service functions (see Section
Note also that levels below 50W may be not detected.
August 2020
D A N G E R
W A R N I N G
and
Table 2-1 ACOM 1010 Individual Data
2 INSTALLATION
Figure 3-1 ACOM 1010 Display and Control
N O T E
5.5 Service Functions
S e c t i o n POWER ON, CONTROLS AND INDICATORS | Page 15 of 32
).
, you may now turn ON the main power switch on
). The green LED indicator above the switch will
). The 800W-scale resolution is 50W.
2.2
