REGENERATING
MAGNETIC RECUMBENT BIKE
ME-706
IMPORTANT:
Please read the Important Safety Notice and Assembly Information in
the Owner's manual before assembling this product.
Assembly Manual
190429

Advertisement

loading

Summary of Contents for Marcy ME-706

  • Page 1 REGENERATING MAGNETIC RECUMBENT BIKE ME-706 IMPORTANT: Please read the Important Safety Notice and Assembly Information in the Owner’s manual before assembling this product. Assembly Manual 190429...
  • Page 2 NO:1 NO:7 NO:32 NO:4 NO:34 NO:5L NO:2 NO:3 NO:97L/R NO:8 NO:19L/R NO:5R NO:37 NO:33 NO:23L/R NO:6 Part No. Description Q'ty Main frame Rear support tube Seat support bracket Front post Back cushion Front stabilizer Rear stabilizer Front post cover 19L/R Pedal (L&R) 97L/R Rear support tube Cover (L&R)
  • Page 3 STEP 1 Attach Front Stabilizer (#2) with Allen Bolt (#21), Locking washer (#98), and Curved washer (#15) to the Main Frame (#1). 98 15 ? " STEP 2 Attach the Rear Stabilizer (#3) with Allen Bolt (#21), Curved washer (#15) and Locking washer (#98) to the Rear Support tube (#7).
  • Page 4 STEP3 1.Connect Main Frame (#1) and Rear Support tube (#7) with Allen Bolt (#14) and Flat washer (#16). 2.Attach the Level Adjustment (#25). 16 25 STEP 4 1. Slide Front post cover (#8) onto Front post (#4). 2. Connect Middle computer wire (#9), Front extension hand pulse wire (#10) to Middle extension hand pulse wire (#17) and Lower computer wire (#18).
  • Page 5 STEP 5 Connect the computer sensor wire and the computer wire to the Front post connectors, and attach the computer (#6) to the Front Post with the pre-assembled Screws (#12). STEP 6 Secure the Handlebar (#5L, #5R) to the Front Post with Allen Bolts (#14). ©IMPEX INC.
  • Page 6 STEP 7 1. Slightly lift the Seat bracket (#94) as it slides into the Rear support tube (#7). 2. Thread in the Ball end cap (#35) into the Quick release handle (#29). STEP 8 Attach the Cover for Sliding tube (#23L, #23R) with Self-tapping screws (#26) and Screws (#28). ©IMPEX INC.
  • Page 7 STEP 9 1. Secure the Rear Handlebar (#37) to the Seat bracket (#94) with Curved washer (#15), Carriage bolt (#43) and Acorn nut (#44). 2. Connect Hand pulse wire (#42) and Rear extension hand pulse wire (#22). ©IMPEX INC. www.marcypro.com...
  • Page 8 STEP 10 Attach the Seat cushion (#33) to the Seat bracket (#94) with Allen Bolts (#14). STEP 11 Attach Back Cushion (#34) to the Seat bracket (#94) with Allen bolts (#14). ©IMPEX INC. www.marcypro.com...
  • Page 9 STEP 12 Attach the Rear support tube cover (#97L, #97R) with Self-Tapping screw STx5 ½ (#26) and Self-Tapping Screw ST5x ¾ (#55). STEP 13 Thread the Left Pedal (#19L) and Right Pedal (#19R) into the crank. ©IMPEX INC. www.marcypro.com...
  • Page 10 IMPEX INC. ® 2801 S. Towne Ave, Pomona, CA 91766 Tel: (800) 999-8899 Fax: (626) 961-9966 www.marcypro.com support@impex-fitness.com ©IMPEX INC. www.marcypro.com...
