- Page 1 INSTRUCTION MANUAL...
-
Page 2: Packing List
Packing list 1. PP Dolpin Fuselage 6. Plywood control horn x 4 pcs 2. Carbon Tube 5x x 940mm x 1pc 7. M3 self tapping screws x 4 pcs 8. Hook and loop double sided tape 3. Push rod x 4 pcs 4. - Page 3 1. Apply glue to the carbon tube and install it onto the 2. Apply glue to the carbon strip and install it to the slot wing. near the leading edge of the wing. 3. Apply glue to the carbon strip and install the it to the tail as shown. 4.
- Page 4 5. Glue the wing and the tail together by using hot glue. 6. Install the wing to the upper part of the fuselage and Ensure they are perfectly level to each other when bond at the same time, install and glue the bottom half of the together.
- Page 5 11. Assemble quick rod adjusters to the plywood control 12. Apply glue and install all the control horns to the horns. control surfaces as shown. 13. Prepare RC electronic components and install it onto the fuselage. 14. Install elevator and rudder servos onto the fuselage 14.
- Page 6 16. Install push rods onto the control horns, hook up to 17. Install push rod holder onto the fuselage. Align the the rod adjuster and tighten the grub screw when the hole on the holder in a straight line. Thread the elevator control surfaces are perfectly levelled.
- Page 7 21. Use the supplied hook and loop double side tape to secure the ESC onto the fuselage. 22. Tidy up all the servo leads by cable ties to ensure it wont catch by the spinning propeller. Keep all the wires and cables away from the spinning prop at all times.
- Page 8 Happy Flying!
