- Page 1 xChargeIn A-series, X-series, S-series Firmware Update Instructions V 1.01...
- Page 2 EATON Firmware Update Instructions V1.01 of A-, X-, S- series Table of contents Introduction ......................... 3 Representation of safety instructions ................3 Update via USB........................7 EATON Firmware Update Instructions V1.01 of A-, X-, S- series © EATON 2019...
-
Page 3: Representation Of Safety Instructions
EATON Firmware Update Instructions V1.01 of A-, X-, S- series Introduction This manual is valid for xChargeIn A-series, X-series and S-series. Representation of safety instructions At various points in this manual, you will see notes and precautionary warnings regarding possible hazards. The symbols used have the following meaning:... -
Page 4: Purpose Of The Document
EATON Firmware Update Instructions V1.01 of A-, X-, S- series Purpose of the document This document describes how to perform a firmware update at xChargeIn A-series, X- series and S-series. The firmware update can be installed on the charging station via USB. -
Page 5: Determining The Firmware Version
EATON Firmware Update Instructions V1.01 of A-, X-, S- series Determining the firmware version There are several ways to determine the firmware version currently installed on the charging station: ● The current firmware version is visible in the simplified web interface. - Page 6 EATON Firmware Update Instructions V1.01 of A-, X-, S- series Determining the subversion EATON Firmware Update Instructions V1.01 of A-, X-, S- series © EATON 2019...
-
Page 7: Update Via Usb
EATON Firmware Update Instructions V1.01 of A-, X-, S- series Update via USB The following steps are necessary for an update via USB: • Remove covers • Perform update • Mount covers Remove covers The USB interface is located in the connection panel. To make the USB interface accessible, the housing cover and the connection panel cover must be removed. - Page 8 EATON Firmware Update Instructions V1.01 of A-, X-, S- series Perform update Proceed as follows to perform the firmware update: Prepare USB stick 1) Extract the file USB_xChargeIn_A-X-S-Series_xxx.zip. The following files are required for the update: − firmware.bin − firmware.chk 2) Format the USB stick with FAT32.
- Page 9 EATON Firmware Update Instructions V1.01 of A-, X-, S- series 1) Insert connection panel cover and tighten with 4 screws with 2 Nm. The tabs on the connection panel cover must be flush with the enclosing housing. Only then will the device be properly sealed.
