METAL IONIZATION VACUUM GAUGE
MODEL GI-D7 / GI-N8
IONIZATION VACUUM GAUGE
INSTRUCTION MANUAL
This manual is for the ion gauges of serial numbers.
Read this manual carefully before using this gauge and
keep it at your hand for immediate reference.
2500 Hagisono, Chigasaki City, Kanagawa Prefecture, Japan 253-8543
MODEL GI-M2
GI-M2 ： S/N 32000G ～
GI-D7 ： S/N 32001G ～
GI-N8 ： S/N 30001G ～
Components Division,
ULVAC , Inc.
http://www.ulvac.co.jp/
SK00-7723-EI-003-08
