- Page 1 Communication unit for IP systems FA01401-EN MTMA/IP - MTMV/IP EN English PROGRAMMING MANUAL...
- Page 2 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • 1 - This device may not cause harmful interference. 2 - This device must accept any interference received, including interference that may cause undesired operation. MTMA/IP MTMV/IP ❷ ❷...
- Page 3 Confi guration and commissioning via WEB interface and PCS/XIP Assign your PC an address belonging to the same subnet as the device. The default IP address is 192.168.1.5 with netmask 255.255.255.0. Switch PoE 8 . 1 . 1 6 1 9 2 Device powered by PoE switch VAS/101 8 .
- Page 4 MODEL Date and Time SIP account status. MTMV/IP N.B. The MTMV/IP, MTMA/IP can be confi gured as Network MASTER from PCS/XIP for ‘Serverless’ systems. Only one MTMV/IP, MTMAIP can be confi gured as MASTER. 0X00801234...
- Page 5 Specify the default gateway for the home network. [DNS] Enter a valid DNS address if you want to enable the CAMEConnect connection (only on MTMV/IP, MTMA/IP confi gured as MASTER). To save changes made or reload the previous data, press the button that will appear at the bottom of the page.
- Page 6 Help Exit ACCOUNT TRUNKS FEATURES NODE STATE System [ACCOUNT] Date and Time For a NON MASTER device, only this section appears USERNAME Network 00800000001 [USERNAME]: SIP username assigned by PCS/XIP to PASSWORD the device. Credentials [PASSWORD]: (for future use). [NAME DISPLAYED]: username assigned by PCS/XIP NAME DISPLAYED Access Control to the device.
- Page 7 Exit List of system SIP VoIP devices and their registration ACCOUNT TRUNKS FEATURES NODE STATE System status in relation to the MTMV/IP, MTMA/IP MASTER Date and Time entry panel. Green: registered device Network NOTE TYPE Red: non-registered device. Under the heading [NOTE TYPE], you can fi lter the list of devices by type.
- Page 8 List of XIP type devices (SIP receivers), which do not re- System LICENSES XIP RECEIVERS XIP MOBILE GENERIC SIP quire a license and use the MTMV/IP, MTMA/IP MASTER entry panel as the registration server. Date and Time Network UNIT DESCRIPTION...
- Page 9 List of XIPMobile type devices, which require a license System LICENSES XIP RECEIVERS XIP MOBILE GENERIC SIP and use the MTMV/IP, MTMA/IP MASTER entry panel as the registration server. Date and Time NUMBER OF LICENSES Network [NUMBER OF LICENSES]: number of licenses still available.
- Page 10 Date and time MASTER [IP ADDRESS]: this is the MASTER device address. In the IP ADDRESS Network case of MTMV/IP, MTMA/IP MASTER, it is the address 192.168.61.19 of the device itself. CONCIERGE IP [IP PORT]: (default 20050) this is the MASTER device...
- Page 11 Device DEVICE Help Exit System AUDIO/LED MULTIMEDIA PARAMETERS [AUDIO/LED] Date and Time You can change the volume of the speaker, the mi- crophone (only if really needed, for example in special Network environmental conditions) and the backlighting of the entry panel keys. Credentials Access Control Device...
- Page 12 Maintenance Maintenance Exit Help System [INFO] to display the fi rmware version of the main SYSTEM INFO UPDATE CONFIGURATION module and connected accessories. Date and Time MAIN SW VERSION Network 1.1.0 MTM8C SW VERSION 1.2.0 MTMKB SW VERSION Credentials 1.0.0 MTMDY SW VERSION Access Control 2.0.0...
- Page 13 [SYSTEM CONFIGURATION] restore the default settings Maintenance Exit Help for the main module and connected accessories by System INFO UPDATE SYSTEM choosing [GLOBAL]. CONFIGURATION Date and Time Network RESET TO FACTORY DEFAULTS Credentials Global Access Control Device Maintenance Diagnostics Diagnostics Diagnostics Help Exit...
- Page 14 Operations on PCS/XIP The device is part of a system based on the Xip system. The system structure must be built using PCS/XIP software. Device view Unit view Devices XIP Multi server Server Server Main MTMV IP ETI/miniSER/Domo XIP Built-in buttons DVC IP DC IP MTM8C...
- Page 15 Device view Unit view Serverless IP plate Devices Main MTMV IP DVC IP Built-in buttons DC IP MTMA IP MTMV IP MTM8C Area Main MTMA IP Built-in buttons IP block IP sub block MTM8C ETI/miniSER/Domo XIP local IP block IP sub block Unit IP 1 MTMV IP properties Unit IP 2...
- Page 16 Regulatory references The product complies with the applicable reference directives. Dismantling and disposal. Dispose of the packaging and the device properly at the end of its life cycle, according to the regulations in force in the country where the product is used. The recyclable components bear the symbol and code for the material. THE DATA AND INFORMATION PROVIDED IN THIS MANUAL ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT PRIOR NOTICE.
