CONTENTS
PAGE
1 Introduction
2 Warranty
2.1 Three Years Limited Warranty
2.2 Exclusions
2.3 Returning Product
2.4 Contacting us
3 Safety Information
4 Preparing for Operation
4.1 Unpacking the instrument
4.2 Discharged batteries
4.3 AC operation
5 Operation
5.1 Display and controls
5.2 Turning the instrument on and off
5.3 Setting the wavelength
5.4 Switching measurement mode
5.5 Setting reference level
5.6 Switching backlighting of the LCD on and off
5.7 Frequency detecting
5.8 The overflow of the measured power value
The storage of the current test value( For AD2A04 and AD2B04)
5.9.
Check the storage records( For AD2A04 and AD2B04)
5.10
6 Specifications
7 Maintenance
1 Introduction
The AD series are full featured palm sized optical power meters designed for use with an optical
laser source to perform optical loss measurements on optical fiber cables. The AD series are
lightweight and are controlled by microprocessor. Utilizing state-of-the-art SMT in its manufacture,
optical connections to the AD are made via the universal adapter interface on the top of the unit. The
instrument has 6 working wavelengths to totally satisfy your needs.
It can be extensively used in telecommunication projects and other situations where optical power of
wavelengths close to infrared ray needs to be measured.
2 Warranty
Three Years Limited Warranty
AD INSTRUMENTS products are warranted against the defective components and workmanship for a
period of three years from the date of delivery to the original customer. Any product found to be defective
within the warranty period would be returned to AD INSTRUMENTS authorized service center for repair,
replacement and calibration.
Exclusions
The warranty on your equipment shall not apply to defects resulting from the following:
