Page 2: Packing List
PACKING LIST PACKING LIST 1: PP F-4 fuselage x 1 pc 2: Carbon tube x 1 pc 3: Carbon strip x 2 pcs 4: Pull rod 1.2mm x 3 pcs 5: Motor mount x 1 pc 6: 2mm Quick rod adjuster x 3 pcs 7: Hinge x 3 pcs 8: Hook and loop tape x 1 pc 9: M3 screws x 4 pcs... - Page 3 Glue the aileron and elevator to the wing and horizontal tail respectively by using some foam safe glue. Notice: Do not use fiber tape or other kinds of tape for this purpose. In fact, the foam safe glue will make a good hinge material for the purpose. Insert a supplied carbon strip into the wing’s groove near the wing’s leading edge and insert the other carbon strip near the trailing edge of the wing.
- Page 4 Apply some foam safe glue on the wing as shown in the Then install the wing onto the fuselage. picture below. Apply foam glue to the rear top part of the fuselage as Then assemble the rear part of the top fuselage and shown.
- Page 5 Then hold the nose shape by using a clamp. Assemble the fuselage by using some clamps. Apply foam glue on Y board using foam glue as shown. Apply foam glue to the middle part of the horizontal tail and do it on both sides Assemble the Y board into fuselage.
- Page 6 Apply foam glue on the slot of the vertical tail and the centre part of the horizontal tail (both sides). Then insert the horizontal tail into the slot of the vertical tail. Ensure the fin and the stabiliser are perpendicular to After the glue thoroughly dried, you may remove all the each other and true to the wing, then wait for the glue to clamps at this moment.
- Page 7 When installing the servos, just to make sure that all the servo arms are perpendicular to the servo case. Install all the push rods on quick rod adjuster and servo arms as shown. Then trim the excessive push rod as shown. Anchor the servo lead on the wing by using some hot glue.
- Page 8 Insert the carbon rod through the hole under the canopy Stick the hook and loop tape into the cockpit by using by using some hot glue stick. some foam glue. Then install battery, ESC and receiver into the compartment. Total flying weight of the F-4 is about 415 grams.
- Page 9 C of G is behind 1cm of carbon strip’s peak as shown picture below.
