  • Page 1 Elite Smart Touch Treadmill User manual...
  • Page 2 19 - 20 TROUBLE SHOOTING TROUBLE SHOOTING 21 - 32 CONTROL PANEL CONTROL PANEL APP INSTRUCTIONS APP INSTRUCTIONS 34 - 35 EXPLODED DRAWING EXPLODED DRAWING 36 - 38 PARTS LIST PARTS LIST TRAINING INSTRUCTIONS TRAINING INSTRUCTIONS VirtuFit Elite Smart Touch Treadmill...

  • Page 3: Safety Instructions

    – Before using the device, check that the nuts and bolts are securely tightened. – The safety of the device can only be maintained if it is regularly examined for damage and/or wear and tear. VirtuFit Elite Smart Touch Treadmill...
  • Page 4 – Maintenance assembly and repair work not carried out by an official dealer. – In the event of improper use, neglect and / or poor maintenance. – Failure to maintain the device in accordance with the manufacturer’s instructions (see the enclosed manual). VirtuFit Elite Smart Touch Treadmill...
  • Page 5 Right cover inner cover Console Foam armrest Safety key Screw hole plug Standard power cord Armrest tube plug Lower cover console Left bottom shield Left column outer cover Right bottom shield Right cover outer cover Oil bottle VirtuFit Elite Smart Touch Treadmill...

  • Page 6: Assembly Tools

    CHECKLIST ASSEMBLY TOOLS Note: DO NOT plug in the power supply until the installation is complete. Installation Steps Unpacking VirtuFit Elite Smart Touch Treadmill...
  • Page 7 In this way you prevent the head of the socket head screw from being rotated. NOTE! Do not plug in the power cord until installation is complete. STEP 1 • Open the packaging and place the main frame (A) on the floor. VirtuFit Elite Smart Touch Treadmill...
  • Page 8 Install the left and right uprights (A03, A04). Lift it upright as shown in the picture. • Install the left and right uprights (A07, A08) to the main frame using the Allen key (B07) around the M8 * 15 bolt (E15) and the lock washer (E32) VirtuFit Elite Smart Touch Treadmill...
  • Page 9 • Use Allen key 5 (B07) and the M8 * 15 bolts (E15) to attach the support frame to the frame. • Use sealing plug (C14) to neatly close the bolts. VirtuFit Elite Smart Touch Treadmill...
  • Page 10 Install the instrument and install the middle and lower covers of the electronic watch. • Install the display (C) • Connect the cables from the display (C) to the cables from the support frame (B). VirtuFit Elite Smart Touch Treadmill...
  • Page 11 Place the protective cover (C05) under the support frame (B). • Attach the display (C) to the support frame (B). To do this, use Allen key 5 (B07) and the and M8 * 15 bolts (E15) with the corresponding lock washers (E32). VirtuFit Elite Smart Touch Treadmill...
  • Page 12 Place the left and right hand rests (C12) • Use Allen key 5 (B07) and the and M8 * 15 bolts (E15) to attach the palm rests to the support frame. • Close the bolts with the corresponding blanking plugs (C15) VirtuFit Elite Smart Touch Treadmill...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP 7 • Attach the upright cover (E24) • Use the Phillips screwdriver (B08) and the screws (E24) to attach the cover. VirtuFit Elite Smart Touch Treadmill...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP 8 Install the left and right bottom shields. • Attach the left and right guards. (C36, C37). VirtuFit Elite Smart Touch Treadmill...
  • Page 15 ASSEMBLY INSTRUCTIONS STEP 9 • Cut the packing strap (P). VirtuFit Elite Smart Touch Treadmill...
  • Page 16 After using the treadmill, turn off the power switch (on / off). In addition, do not use the emergency • stop unnecessary, only in an emergency. In this way, the circuit board is least loaded. VirtuFit Elite Smart Touch Treadmill...
  • Page 17 • Install the safety key in the console. • When you start walking, attach the safety key to your clothing. Pull at one emergency on the key safety lanyard and the treadmill will stop immediately. VirtuFit Elite Smart Touch Treadmill...

  • Page 18: Folding Instructions

    UNFOLDING Hold the treadmill by the end. Press against the gas spring with your foot. Press down on the walking platform and pull your foot away. The walking platform will then lower automatically. VirtuFit Elite Smart Touch Treadmill...

  • Page 19: Moving The Treadmill

    Hold the walking platform firmly, step on one of the wheels with your foot. Push the walking platform down until the transport wheels are both on the ground. From this moment on, the treadmill can be moved. VirtuFit Elite Smart Touch Treadmill...

  • Page 20: Leveling The Treadmill

    Repeat process until the belt becomes central. 03. Running belt jam: If the running belt is in dead condition, use the Allen key to turn the screw 1/2 a turn both left and right until the jam solved (see fig 3). VirtuFit Elite Smart Touch Treadmill...

  • Page 21: Daily Maintenance

    Be sure to clean the exposed area of the belt and the foot rails of the treadmill on both sides. In addition, wear clean shoes to reduce the risk of contamination of the treadmill. Remove the hood at least once a year to vacuum underneath. For more information: www.virtufit.nl/service/faq/#toggle-id-1 VirtuFit Elite Smart Touch Treadmill...
  • Page 22 • Use a dry cloth to clean the control panel and areas around the power switch. Use a soft clean cloth and cleanser to remove stubborn stains and dirt off the running belt. • Tighten the running belt once a month. • Keep your treadmill in a safe dry place away from heat and water. VirtuFit Elite Smart Touch Treadmill...
  • Page 23 Use a soft clean cloth and detergent to remove stubborn stains and dirt from the treadmill. • Tighten the treadmill once a month. • Keep your treadmill away from heat and water in a safe, dry place. Regular maintenance prolongs the life of your treadmill and prevents injury! VirtuFit Elite Smart Touch Treadmill...

  • Page 24: Troubleshooting

    Check transmission parts, add lubricating oil. • Replace the motor. • Replace the driver. Motor break • Ensure the motor wires are connected well. • Replace the motor. Storage fault • Check 24C02. • Replace the motor. VirtuFit Elite Smart Touch Treadmill...
  • Page 25 Put the treadmill horizontally. • Replace the driver. Moment overcurrent • Replace the motor. • Check transmission parts, add lubricating oil. Overvoltage • Stop use, check external wire. undervoltage • Stop use, check external wire. VirtuFit Elite Smart Touch Treadmill...

  • Page 26: Control Panel

    If it starts in manual mode, the STOP treadmill will start running at the lowest speed and lowest incline. BACK It can return to the previous screen. VirtuFit Elite Smart Touch Treadmill...
  • Page 27 Wi-Fi: This icon will be lighted ON when the device is connected to the Wi-Fi. Volume adjustment: Adjust the volume by scrolling. Settings. Current user name. User quick switch. Distance countdown. Time countdown. Calories countdown. VirtuFit Elite Smart Touch Treadmill...
  • Page 28 Steps countdown. Start up. Built-in HRC, Runway, Workout Programs. Built-in user information settings, My Reports, My Programs, My Test. Scene training mode. Local music, video file management and playing. Third-party APP. User’s manual. Return. Homepage. VirtuFit Elite Smart Touch Treadmill...

  • Page 29: Main Interface

    “SPEED + / SPEED –” to change the speed; click “INCLINE / INCLINE ” to change the incline.) • Click “PAUSE” to pause the exercise; click “STOP” to stop the exercise, and automatically display its related data records. VirtuFit Elite Smart Touch Treadmill...
  • Page 30 “SPEED + / SPEED –” to change the speed; click “INCLINE / INCLINE ” to change the incline.) • Click “PAUSE” to pause the exercise; click “STOP” to stop the exercise, and automatically display its related data records. VirtuFit Elite Smart Touch Treadmill...
  • Page 31 4. As required, click “SPEED + / SPEED –” to change the speed; click “INCLINE / INCLINE ” to change the incline. Click “PAUSE” to pause the exercise; click “STOP” to stop the exercise, and automatically display its related data records. STEP 1 STEP 2 STEP 3 - 4 VirtuFit Elite Smart Touch Treadmill...
  • Page 32 5. Click “PAUSE” to pause the exercise; click “STOP” to stop the exercise, and automatically display its related data records. STEP 1 STEP 2 - 3 STEP 4 - 5 Speed and Incline segmented change curves for P1-P36 programs. VirtuFit Elite Smart Touch Treadmill...
  • Page 33 5. As required, click “SPEED +/SPEED –” to change the speed; click “INCLINE / INCLINE ” to change the incline. 6. Click “PAUSE” to pause the exercise; click “STOP” to stop the exercise, and automatically display its related data records. VirtuFit Elite Smart Touch Treadmill...
  • Page 34 After the 15-minute test, automatically display the rating results of the current test. NOTE! During test, if clicking “STOP” to stop it, the test will not be completed, and there will be no rating results. STEP 1 STEP 2 STEP 3 VirtuFit Elite Smart Touch Treadmill...
  • Page 35 34≤V<38 38≤V<42 V≥42 40-49 V<29 29≤V<33 33≤V<36 36≤V<40 V≥40 Female 50-59 V<27 27≤V<30 30≤V<33 33≤V<37 V≥37 60-69 V<25 25≤V<27 27≤V<30 30≤V<33 V≥33 70-79 V<24 24≤V<26 26≤V<28 28≤V<31 V≥31 Class Fail Pass Good Great Excellent Result VirtuFit Elite Smart Touch Treadmill...
  • Page 36 ” at the bottom left to switch to full-screen mode, and click “ ” at the bottom right to switch to the original state. 4. Click “PAUSE” to pause the exercise; click “STOP” to stop the exercise, and automatically display its related data records. STEP 1 STEP 2 - 3 - 4 VirtuFit Elite Smart Touch Treadmill...
  • Page 37 7. After these operations are completed, click the compact window to switch to the interface of video playing. STEP 1 STEP 2 STEP 3 STEP 4 - 5 - 6 STEP 7 VirtuFit Elite Smart Touch Treadmill...
  • Page 38 7. After these operations are completed, click the compact window to switch to the interface of music playing. STEP 1 STEP 2 STEP 3 STEP 4 - 5 - 6 STEP 7 VirtuFit Elite Smart Touch Treadmill...
  • Page 39 Unit Change Switch between metric system and British system. Time Setting • Click to select the time zone that you are located in. Clear Cache • It is recommended that the cache be cleaned monthly. VirtuFit Elite Smart Touch Treadmill...

  • Page 40: Usb Charging

    3. If there is something wrong with the machine, please connect the retailer as soon as possible. It`s not allowed to repair the equipment by layperson. 4. You can pull off the plug from the socket anytime, and this will not do damage to the treadmill. VirtuFit Elite Smart Touch Treadmill...

  • Page 41: App Instructions

    ZWIFT APP STORE GOOGLE PLAY USER MANUAL ZWIFT ZWIFT ZWIFT FITSHOW APP STORE GOOGLE PLAY USER MANUAL FITSHOW FITSHOW FITSHOW VirtuFit Elite Smart Touch Treadmill...

  • Page 42: Exploded Drawing

    EXPLODED DRAWING VirtuFit Elite Smart Touch Treadmill...
  • Page 43 EXPLODED DRAWING VirtuFit Elite Smart Touch Treadmill...
  • Page 44 Left column outer cover Running belt Right column outer cover D01 Electronic watch Left column inner cover D02 Control circuit board Right column inner cover D03 Button board Foam armrest D04 EKG grip pulse upper line VirtuFit Elite Smart Touch Treadmill...
  • Page 45 Cross pan head self-drilling screw Hexagon socket flat round head screw G01 Horn exagon socket flat round head screw G02 Horn cable Hexagon socket head cap screw G03 MP3 cable Hexagon socket head cap screw VirtuFit Elite Smart Touch Treadmill...
  • Page 46 PARTS LIST DESCRIPTION Cross recessed pan head tapping screw Filter Reactor AC individeual line L350 blue Grounding wire L350, yellow-green Cross recessed pan head self-drilling tapping screw ST4.2*12 Wireless heart rate lower line POLAR wireless receiver VirtuFit Elite Smart Touch Treadmill...

  • Page 47: Training Instructions

    The purpose of cooling down is to return the body to its normal or near normal, resting state at the end of each exercise session. A proper cool-down slowly lowers your heart rate and allows blood to return to the heart. VirtuFit Elite Smart Touch Treadmill...
  • Page 48 For questions or missing parts please contact your dealer.
