Konstantynowska 79/81 95-200 Pabianice
phone/fax: (+48 42) 215 23 83 / 227 09 71 POLAND
http://www.fif.com.pl e-mail: fif@fif.com.pl
WORKING TIME METER
WARRANTY. The F&F products are
covered by a warranty of the 24 months
from the date of purchase. Effective only
with proof of purchase. Contact your
dealer or directly with us. More informa-
tion how to make a compliant can be
found on the website:
5 9 0 8 3 1 2
www.fif.com.pl/reklamacje
Do not dispose of this device in the trash along with other waste! According
to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collection, as well as to store the
occasion of the purchase of new equipment (in accordance with the principle
of old-for-new, regardless of brand). Electro thrown in the trash or abandoned
in nature, pose a threat to the environment and human health.
Purpose
Operating time counter is used for counting the number of hours
of operation in automatic production processes or the operating
hours of devices that due to the safety requirements and effi-
ciency of operation have specified service life, which means
operational capacity, that must not be exceeded (for example
advanced powertrains, special radioactive lamps etc.)
Functioning
CLG-15T counter is a unidirectional electricity meter with cylinder
counter, enabling the counting of operating hours in the range of 0
to 99999.99 (five digits plus two digits after the decimal point),
meaning the unit hundredths (0.01 = 36 s). Upon reaching the
maximum result the counter starts counting from 0.
- 1 -

Installation

F&F Filipowski sp. j.
1. Disconnect the power supply.
2. Slide the mounting bracket off from the body of the counter.
CLG-15T
3. Put the counter into the mounting hole, insert the fastening
2 V 30
metal plate and tighten the nut.
4. Connect the (L/+; N/-) voltage, which is an indication of the
controlled device operation, to the terminals of the counting
input.
Technical data
5 9 0 2 0 0
power supply / counting node voltage
voltage tolerance
display
indications accuracy
working temperature
dimensions
mounting hole
protection level
Connection diagram
D160309
230V AC/DC
(-15% ÷ +10%)
7 characters / h= 5mm
0.01h (36 s)
-25÷50°C
48×24×60mm
32×22mm
IP20
+
L N
- 2 -
