- Page 1 BUNKER RAKE OPERATOR’S MANUAL SUPER STAR Model 42-000-D and 42-001-D SUPER RAKE Gas Model 13-550-D and 13-551-D Diesel Model 17-001-D November, 2003 ENGLISH SMITHCO PRODUCT SUPPORT 1-800-891-9435 Hwy SS and Poplar Avenue, Cameron WI 54822 E-mail: productsupport@smithco.com...
-
Page 2: Table Of Contents
CONTENTS Introduction ............ 1-13 Introduction ..................1 Symbols ..................2-3 Safe Practices ................. 4 Super Star Specifications ..............5 Super Rake Gas and Diesel Specifications ........6 Setup ....................7 Controls & Instruments Gas Super Rake ........8 Controls & Instruments Diesel Super Rake ........9 Controls &... -
Page 3: Introduction
INTRODUCTION Thank you for purchasing a product. Read this manual and all other manuals pertaining to the Bunker Rake carefully as they contain safety, operat- ing, assembly and maintenance instructions. Failure to do so could result in personal injury or equipment dam- age. -
Page 4: Symbols
SYMBOLS Read Operator’s Electrical Power No Electrical Manual Power Engine - Stop Engine - Start Engine - Run Temperature Water Engine Oil Light Temperature Gasoline Diesel Glow Plug - On Glow Plug - Off Glow Plug Hour Meter Hour Meter Fuse Hand Throttle Choke - Closed... - Page 5 SYMBOLS Up/Down Arrow Down/Lower Up/Raise Manual No Smoking Moving Parts Operation Step Hot Surface Pinch Point Hydraulic Fluid Lift Arm Tractor Penetration Engage Disengage Ground Speed Fast Slow Forward High Warning Danger Reverse Neutral Caution...
-
Page 6: Safe Practices
19. Stop engine before making repairs/adjustments or checking/adding oil to the crankcase. 20. Use parts and materials supplied by SMITHCO only. Do not modify any function or part. hese machines are intended for professional maintenance on golf courses, sports turf, and any other area maintained turf and related trails, paths and lots. -
Page 7: Super Star Specifications
SPECIFICATIONS SUPER STAR WEIGHTS AND DIMENSIONS Length 64" (163 cm) Width 57" (145 cm) Height 47" (119 cm) Wheel Base 41" (104 cm) Weight 950 lbs. ( 451 kg) SOUND LEVEL At Ear Level 85 dB At 3ft (.914 m) 83 dB At 30 ft (9.14 m) 73 dB... -
Page 8: Super Rake Gas And Diesel Specifications
SPECIFICATION GAS AND DIESEL SUPER RAKE WEIGHTS AND DIMENSIONS GAS SUPER RAKE DIESEL SUPER RAKE Length 85" (216 cm) 85" (216 cm) Width 73.5" (187 cm) 73.5" (187 cm) Height 45" (114 cm) 45" (114 cm) Wheel Base 47" (120 cm) 47"... -
Page 9: Setup
SETUP The Bunker Rakes arrive from with some assembly required before service. 1. Set park brake. Push the brake down past center and the park brake is engaged. 2. Rear wheel mounting. Block front tire. Jack up rear of machine being careful not to damage underside of machine. -
Page 10: Controls & Instruments Gas Super Rake
CONTROLS & INSTRUMENTS GAS SUPER RAKE INSTRUMENT PANEL Located on right fender. A. Ignition Switch: Three Position. Stop-Run-Start. B. Two Or Three Wheel Drive: Front wheel drive valve is located on front right fender. Push to engage front wheel drive and pull to disen- gage front wheel drive. -
Page 11: Controls & Instruments Diesel Super Rake
CONTROLS & INSTRUMENTS DIESEL SUPER RAKE INSTRUMENT PANEL Located on right fender. A. Ignition Switch: Four Position. Preheat-Stop-Run-Start. B. Hour Meter: THe hour meter indicates the hours of machine op- eration. It operates only when the ignition switch is on. THe volt meter indicates battery voltage. -
Page 12: Controls & Instruments Super Star
CONTROLS & INSTRUMENTS SUPER STAR INSTRUMENTS LOCATED ON THE CONTROL PANEL Electric On/Off Valve Switch - Toggle switch that turns 2 Wheel to 3 Wheel Drive. For 42-117 Optional Electric Valve Kit. Oil Light - The oil light should come on when ignition is on without engine operating. -
Page 13: Operation
OPERATION AND DAILY CHECK LIST STARTING ENGINE Before operating this machine, become familiar with all controls and functions of these units. Also complete all maintenance requirements and read all safety warnings. By knowing the machine thoroughly, how it operates and by doing the prescribed maintenance steps, you can expect relatively trouble-free operation for years to come. -
Page 14: Daily Checklist
DAILY CHECKLIST Use all procedures and parts prescribed by the manufacturer's. Read the engine manual before operation. The suggested maintenance checklist is not offered as a replacement for the manufacturer’s but as a supple- ment. You must adhere to guidelines established by manufacturer for warranty coverage. In adverse conditions such as dirt, mud or extreme temperatures, maintenance should be more frequent. -
Page 15: How To Rake A Sand Trap
HOW TO RAKE A SAND TRAP HOW TO RAKE A SAND TRAP View bunker to determine the most efficient pattern to follow so that rake pattern and configuration of bunker will flow in same general direction and look attractive. Enter bunker at its lowest point. Perhaps drain area or another point where “lip” of the trap is minimal. Operate at 2-4 m.p.h. -
Page 16: Service
BATTERY BATTERY Batteries normally produce explosive gases which can cause personal injury. Do not allow flames, sparks or any ig- nited object to come near the battery. When charging or working near battery, always shield your eyes and always pro- vide proper ventilation. -
Page 17: Other
Gas Super Rake 13-550-D/13-551-D Diesel Super Rake 17-001-D Super Star 42-000-D/42-001-D (Make, Model) to which this declaration relates corresponds to the relevant basic safety and health requirements of the Directive 89/392/EEC,... - Page 18 NOTES...
-
Page 19: Limited Warranty
Batteries. Wheels and tires. A copy of the warranty for the above items is furnished if necessary with each SMITHCO product. Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitations of incidental or consequential damages, so the above limitations or exclusions may not apply to you.
