Mocka Maya Bookcase Assembly Instructions Manual page 7

Maya Bookcase
Assembly Instructions
11
Drawers (x2)
13
B
B
B
x8
Insert 4x bolts [A] into the back of panel [16]. Attach panel [16] to panel [13]
and [15] with 4x locking nut [B]. Tighten with a screwdriver.
mocka.co.nz | mocka.com.au
B
15
A
B
A
A
16
A
x8
12
Drawers (x2)
13
Attach 2x slide rails [H] to panels [13] and [15]. Screw with 4x small screw
[E]. Tighten with a screwdriver.vv
15
7
