Operation And Testing - Timeguard MLB3000 Installation & Operating Instructions Manual

Mains Supply
Live (Brown or Red) to L
Neutral (Blue or Black) to N
A 'Loop Terminal' is provided
should a 3 core cable be used,
which is marked

7. Operation and Testing

Walk Test Procedure
• The adjustment knobs located beneath the sensor head (see diagram "G")
are factory set to "Walk Test Mode" i.e. LUX set to the 'Sun' symbol
and the Time set to the minimum.
• Turn the power to the unit ON. The lamp will illuminate for approximately
30 seconds. This indicates the unit is wired correctly and the unit
is in Test Mode.
5
• Adjust the sensor head to the desired direction for best coverage
(See diagram "B").
Test Mode – Three LED's Visible
• The lamp will now illuminate for approximately 2 seconds every time
movement is detected.
• Walk across the detection area approximately 5 metres from the unit.
Each time you are detected the lamp will illuminate. Now stand still until
the lamp extinguishes (this should take approx. 2 seconds)
• Start moving again, when you are detected again the lamp will illuminate.
• Repeat the above, walking at various angles and distances to the unit.
This will help you to establish the detection pattern.
• If the detection area is too small for your requirements, try angling
the sensor head up.
• Angling the head downwards will reduce the detection area should
a smaller range be required.
.
Load
Switch Live (Brown or Red) to L1
Neutral (Blue or Black) to N
A 'Loop Terminal' is provided
should a 3 core cable be used,
which is marked .
