  • Page 1 Assembly Instructions Item# L-GZ501PST GARDENIA GAZEBO...
  • Page 2 IMPORTANT: Please read and follow all safety statements, warnings, assembly instructions, use and care directions before attempting to assemble. 1. When installing and assembling your gazebo, it is recommended that 2 or more adults are involved. 2. Do not use the unit during an electrical storm, as there is a remote chance of getting struck by lightning.
  • Page 3 Parts List Top Connector Top bar Connector Beam Pole 1 Pole 2 Pole 3 Pole 4 Pole 5 Stake Connector 1 Stake Connector 2 Stake Connector 3 Sun shade frame Sun shade panel Connector Space part Fence Shelf Shelf support Shelf support Small Canopy Big canopy...
  • Page 4 Hardware Pack 1 M5x15 Bolt 44PCS M5 Washer 44 PCS Fig.1: Insert the plug of Fence (L) into the hole of Pole (E & F), then pull downward the Fence (L), assemble other Fences (L) same way with Pole (E1/ F1/G). Fig.2: Use bolt (AA) &...
  • Page 5 Hardware Pack 2 M5 x15 Bolt 6 PCS M5 Washer 8 PCS M6 x 35 Bolt 6 PCS M6 Nut 8 PCS M6 Washer 14PCS M5 x 45 Bolt 2 PCS Ф8 x 180 Stake 8 PCS Fig.6: Use bolt (CC), washer (GG) & nut (DD) to connect Top bar (B) with Top Connector (A).
  • Page 6 Fig.9: Use bolt (AA) & Washer (BB) to tighten Shelf support (N1) to Shelf (M). Fig.9-1: Use bolt（AA）and Washer（BB）tighten Shelf support（N2）to Shelf（M）. Fig.10: Follow the arrow direction to stick Sun Shade Canopy (Q) to Sun shade frame (J). Fig.10-1:Use bolt（EE）and Washer（BB）go through Space part（K1）to fix Sun shade panel to Pole 1 （E）Pole 1 &...
  • Page 7 3. Warranty does not cover damage due to extreme weather conditions. CUSTOMER SERVICE Sunjoy Industries warrants to the original purchaser that this item is free from defects in workmanship and materials of your item provided the item was factory-sealed at the time of purchase and is maintained with care and used only for personal, residential purposes.
