Source
Object
Object & Show Show
Save
Storage
When the type is Configure, the menu shows as following:
Configure
Save
Load
4.Advanced User Guidebook
CH1 Choose the waveform to be saved. (If
CH2 certain channel is off, the corresponding
Math menu item will be disabled.)
(Choose All to save all the waveforms that
All
are turned on. You can save into the
current internal object address, or into USB
storage as a single file.)
Choose the address which the waveform is
0 - 99
saved to or recall from.
Recall or close the waveform stored in the
current object address. When the show is
ON, if the current object address has been
ON used, the stored waveform will be
OFF shown, the
relevant
the top left of the screen; if the address
is empty, it will prompt "None is saved".
Close all the waveforms stored in the
Close All
object address.
Save the waveform of the source to the
selected address. Whatever the Type of
save menu is set, you can save the
waveform by just pressing the Copy panel
button in any user interface.
Select Type in the bottom menu, in the
right Format menu, you can select the
storage format.
Save to internal storage or USB storage.
When External is selected, save the
waveform according to the current record
Internal length (see "
External the file name is editable. The BIN
waveform file could be open by the
waveform analysis software (on the
supplied CD).
Setting0
.....
The setting address
Setting19
Save the current oscilloscope configure to
the internal storage
Recall the configure from the selected
address
67
address number
information will be displayed at
Record Length menu
and
" on P61);
