4.2.

Hygienic instructions for the appliance to comply with VDI 6022

Ü
Before commissioning the appliance must be thoroughly cleaned; in case of stricter hygienic
requirements wiping disinfection must be carried out.
Ü
After disinfecting make sure that no toxicologically suspicious or odour-active substances enter the
air to be supplied!
Ü
In case of stricter hygienic requirements the measurement of pathogen concentration must be
carried out.
Ü
The appliance must not be operated without air filters.
Ü
The permanent low-frequency noise level (10 to 100 Hz) generated by the appliance may not exceed
the audibility threshold. The value to be applied as guidance is that the low-frequency level of
acoustic pressure LCF should not exceed the value of acoustic pressure LAF by more than 20 dB
(see DIN 45680). In case of doubt a frequency analysis of the low-frequency value of acoustic
pressure must be carried out in order to make it possible to identify and suppress the source of the
narrow band of the faulty zone.
Ü
Suitably record the date of your appliance's commissioning, e.g. in the plant log!
5 . A c c e s s t o t h e u n i t u s i n g t h e i n t e r n e t
Ventilation units Multi-N, MultiEco-N and Basic-N equipped with control system RD5
controlled using a web browser. This allows the user to do the following, either from a local network on
site or through the Internet:
●
Change user setting of the unit;
●
Watch the unit's operational parameters including error messages;
●
Browse the unit's operational history;
●
Set e-mail notification with Alarm or Warning messages for up to three e-mail addresses.
You will find more information in the Guide on controlling ventilation units Duplexvent equipped
with regulation RD5.
6 . D i s p o s a l o f p a c k a g e a n d d i s u s e d u n i t
Materials marked with the symbol
order to be recycled.
PAP – corrugated cardboard
FOR – wood
Please leave materials marked with the
Disused ventilation unit sold on the EU market can be recycled in compliance with the
regulation 2012/19/EU. For further information please contact your distributor.
1)
Information regarding the control module your unit contains is shown on the unit's name plate on the
Controls / Specification line. The information is also included in the unit's Technical Specification.
are recyclable. Put these materials in the respective bins in
PE – polyethylene
PS – polystyrene
symbol at the community place used for waste disposal!
1)
can also be
PP – polypropylene
32
