Airflow Duplexvent MULTI-N Instruction Manual page 10

1. Place the unit so that the recommended manipulation area is observed.
Multi-N, MultiEco-N
* Only in units with integrated heater or chiller
Multi-N
1500 Multi-N
2500 Multi-N
3500 Multi-N
5000 Multi-N
6500 Multi-N
8000 Multi-N
2. Cut out the existing roofing and base layers; the dimensions should be about 40 mm larger than
those of the base frame. You will find approximate dimensions of the base frame in the
Duplexvent selection SW, tab Design, keep the option Base frame selected and click on AHU
Placement method. Please contact the manufacturer to confirm the dimensions.
3. Cut out holes for roof outlets according to the configuration of the unit. You will find the roof outlet
dimensions in the Duplexvent selection SW; tab Design > AHU Placement method.
Multi-N, MultiEco-N and Basic-N
Duplexvent Unit Type
MultiEco-N
1500 MultiEco-N
2500 MultiEco-N
3500 MultiEco-N
4500 MultiEco-N
5500 MultiEco-N
6500 MultiEco-N
T (mm) Basic-N
600 1400 Basic-N
700 2400 Basic-N
800 3400 Basic-N
1000 5400 Basic-N
1200 7100 Basic-N
1400 8100 Basic-N
10100 Basic-N
Basic-N
T (mm)
600
600
700
800
1000
1200
1400
10
