2.7.8. Roof assembly

The chapter is related to units 10000 and 11000 Multi-N, 7500 and 9000 MultiEco-N as well as 12100
and 15100 Basic-N.
1. Make sure that the unit is still levelled as described in the Chapter 2.7.1.
Protect the unit from adverse weather conditions until the roof assembly is finished.
2. Make sure that cables leading on the top of the unit are placed in a slot so that they are not
damaged during the roof assembly.
3. Put the roof blocks on the top side of unit casing. The length of roof blocks corresponds with the
length of unit blocks.
3
3
Roof blocks on the units 9000 MultiEco-N and 11000 Multi-N
2
1
2
1
23
