ENGLISH

CONTENTS
1
GENERAL DESCRIPTION ........................................................................................................................ 8
2
DESCRIPTION OF COMPONENTS .......................................................................................................... 9
3
INSTALLATION ....................................................................................................................................... 10
3.1 INSTALLATION METHOD ............................................................................................................. 10
3.2 DESCRIPTION OF TERMINALS, CONNECTORS AND JUMPERS ................................................ 11
4
WIRING INSTRUCTIONS ....................................................................................................................... 11
5
SPEAKER VOLUME ADJUSTMENT ....................................................................................................... 12
6
RESTART BUTTON ................................................................................................................................ 12
7
DDA FUNCTIONS SIGNALS................................................................................................................... 12
8
OPENING THE DOOR USING A PROXIMITY KEY ................................................................................. 12
9
KEY TO SYMBOLS ................................................................................................................................. 12
10 TECHNICAL SPECIFICATIONS .............................................................................................................. 12
11 SIMPLIFIED EU DECLARATION OF CONFORMITY .............................................................................. 13

1 GENERAL DESCRIPTION

The device Ref.1060/21 is the new IP door station dedicated to Ipercom systems, built on MIKRA2
mechanics with a single button. A LAN/POE connection is needed for correct operation.
Vandal-proof panel with weatherproof zama front.
Wide-angle colour camera on panel.
Subject lighting using white LEDs which can be excluded.
1 call button.
Name tag and backlit call button with white LEDs.
Signalling LED for DDA function.
Mifare proximity key reader.
Hall button input.
Door sensor input.
Door unit audio/video auto-on function.
LAN connection with dedicated connector (not RJ45) and POE power.
Terminals for external 48Vdc instead of POE.
The IP door unit will not work even if it is connected to the system and the name tag LEDs will
blink until the device is configured on the system.
8
DS1060-133A
