Groen TDB-20 Operator's Manual page 11

To order parts, contact your Authorized Service Agent. Supply the model designation, serial number, part description, part number, quantity, and when applicable,
voltage and phase.
Key Description
1 WATER FILL ASSEMBLY
2 SAFETY VALVE
3 CHECK VALVE
4 PRESSURE GAUGE
5 KNOB
6 HAND & BALL KNOB ASSEMBLY
7 KETTLE BODY ASSEMBLY, 20 QT
7a KETTLE BODY ASSEMBLY, 20 QT, 480V
7b KETTLE BODY ASSEMBLY, 24 QT
7c KETTLE BODY ASSEMBLY, 24 QT, 480V
7d KETTLE BODY ASSEMBLY, 40 QT
7e KETTLE BODY ASSEMBLY, 40 QT, 480V
7f KETTLE BODY ASSEMBLY, 48 QT
7g KETTLE BODY ASSEMBLY, 48 QT, 480V
8 BASE & PEDESTAL ASSEMBLY - 20/24QT HAND TILT
8a BASE & PEDESTAL ASSEMBLY - 40/48QT HAND TILT
8b BASE & PEDESTAL ASSEMBLY - 20/24QT CRANK TILT
8c BASE & PEDESTAL ASSEMBLY - 40/48QT CRANK TILT
9a LIGHT, AMBER
9b LIGHT, RED
10 POWER SWITCH
11A 2" ALUMINUM KNOB, CLASSIC CONTROL
11B 2" ALUMINUM KNOB, ADVANCED & C2T
12 NUT, ROTARY SHAFT SEAL(NOT SHOWN)
13 SIGHT GLASS
14 LIGHT MOUNT BRACKET(NOT SHOWN)
15 LIGHT MOUNT SPACER(NOT SHOWN)
16 HAND TILT MECHANISM ASSEMBLY
17 PEDESTAL WELDMENT - HAND TILT
- PEDESTAL WELDMENT - CRANK TILT
18 ELECTRICAL MOUNT ASSEMBLY(CRANK TILT) - 208/240V
18a ELECTRICAL MOUNT ASSEMBLY - 480V
19 ELECTRICAL MOUNT ASSEMBLY(HAND TILT) - 208/240V
19a ELECTRICAL MOUNT ASSEMBLY - 480V
20 TILT SWITCH
21 CONTACTOR
22 GROUND TERMINAL
23 TERMINAL BLOCK
24 FUSE HOLDER
25 FUSE, 3 AMP
26 TRANSFORMER, 208/240V
26a TRANSFORMER, 480V
11 OM-TDB(C) (C,A) (CE) INTERNATIONAL
Parts List
Key Description
Part No.
27 WATER LEVEL BOARD
137433
28 CONNECTOR
097005
29 CLASSIC CONTROL
096915
30A ADVANCED CONTROL
084208
30B C2T CONTROL
175095
31 RTD PROBE(NOT SHOWN)
012694
32 PRESSURE SWITCH
175062
33 ELECTRODE WATER LEVEL
175061
34 ELEMENT - 20/24 208/240V
175067
34a ELEMENT - 20/24 480V
175068
34b ELEMENT - 40/48 208/240V
175072
34c ELEMENT - 40/48 480V
175071
x CRANK TILT MECHANISM ASSEMBLY
175084
35 GEAR CARRIER ASSEMBLY
175085
36 HANDWHEEL SHAFT
174752
37 WORM GEAR
175362
38 HANDWHEEL ASSEMBLY
175358
39 KEY, 1/4 SG X 1"
175296
40 BEARING BACK ASSEMBLY
116384
41 ROLL PIN .25 X 1.25
116383
42 ROLL PIN .25 X 1.625
177910
43 PLUG PIPE
175095
44 FITTING, GREASE 90
174829
45 BRASS FITTING, 1/8 NPT
101145
46 WASHER, SPLIT LOCK 3/8
108554
47 SCREW, 3/8-16 X 1 HEX HEAD
175222
48 WASHER, FLAT 3/8
175221
49 GEAR SECTOR ASSEMBLY
137741
50 BEARING ROLLER
140321
51 RETAINING RING, 1.5"
174630
52 COVER ELEMENT HOUSING
175229
53 STATION COVER
175579
54 DECAL OPERATING INSTRUCTIONS - CLASSIC CTRL
175439
55 DECAL OPERATING INSTRUCTIONS - ADVANCED CTRL
175440
x HARNESS, HIGH VOLTAGE
002982
x HARNESS, CONTROL, TDB
148102
x HARNESS, ELEMENT
129714
x FERRITE BEAD (NOT SHOWN)
003888
x OVERLAY, C2T
077854
x CORE PROBE, TDB-20 & 24, C2T
77853
x CORE PROBE, TDB-40 & 48, C2T
137441
x BRACKET, CORE PROBE, TDB-20 & 24, C2T
137694
x BRACKET, CORE PROBE, TDB-40 & 48, C2T
x BRACKET ASSEMBLY, CORE PROBE STORAGE
x SOCKET, PANEL MOUNT ASSY, CORE PROBE, C2T
x CAP, SOCKET, PANEL MOUNT, CORE PROBE, C2T
x WIRE HARNESS, CONTROL, CORE PROBE, C2T
x HARNESS, CONTROL, TDB, C2T
x- Item not depicted/called out in drawing or photograph
Part No.
122192
140416
174843
174837
176895
175429
177794
015589
001706
010996
011094
011088
-
124741
122374
128001
124719
122371
128021
012614
128036
010286
012195
175231
005618
005612
005830
128028
002790
124764
003141
175237
175298
175610
149945
175289
148718
175836
176892
176677
176678
176658
176659
177091
176925
176927
176920
177262
