GSi 40 Series Construction Manual

18' diameter bin - beta, 2.66" corrugation bin, 6000 lb. peak load roof
Hide thumbs Also See for 40 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
18' Diameter Bin - Beta
40-Series 2.66" Corrugation Bin
6000 lb. Peak Load Roof
Construction Manual
PNEG-4018B
Version: 1.2
Date: 11-17-20
PNEG-4018B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 40 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GSi 40 Series

Summary of Contents for GSi 40 Series

  • Page 1 18' Diameter Bin - Beta 40-Series 2.66" Corrugation Bin 6000 lb. Peak Load Roof Construction Manual PNEG-4018B Version: 1.2 Date: 11-17-20 PNEG-4018B...
  • Page 2 All information, illustrations, photos, and specifications in this manual are based on the latest information available at the time of publication. The right is reserved to make changes at any time without notice. PNEG-4018B 40-Series 2.66" Corrugation 18' Diameter Bin - Beta...

  • Page 3: Table Of Contents

    Table of Contents Contents Chapter 1 Safety ..............................5 Safety Guidelines ..........................5 Cautionary Symbols Definitions ......................6 Safety Cautions ............................. 7 Safety Sign-Off Sheet ......................... 11 Chapter 2 Decals ..............................12 Overfill Warning ........................... 14 Chapter 3 General Overview ..........................15 General Information ..........................
  • Page 4 Table of Contents 2 Ring Stiffener (8-14 Gauge) to a 2 Ring Stiffener (8-14 Gauge) Connection ........50 Close-Punch Connection for a 2 Ring Stiffener (8-14 Gauge) to a 2 Ring Stiffener (8-14 Gauge) ..51 Close-Punch Connection for a 2 Ring Stiffener (2-6 Gauge) to a 2 Ring Stiffener (2-6 Gauge) ..51 2 Ring Stiffener (8-14 Gauge) to a Close-Punch Base Stiffener (8 Gauge) Connection ....

  • Page 5: Chapter 1 Safety

    1. Safety Safety Guidelines Safety guidelines are general-to-specific safety rules that must be followed at all times. This manual is written to help you understand safe operating procedures and problems that can be encountered by the operator and other personnel when using this equipment. Save these safety guidelines for future reference.

  • Page 6: Cautionary Symbols Definitions

    1. Safety Cautionary Symbols Definitions Cautionary symbols appear in this manual and on product decals. The symbols alert the user of potential safety hazards, prohibited activities and mandatory actions. To help you recognize this information, we use the symbols that are defined below. This symbol indicates an imminently hazardous situation DANGER which, if not avoided, will result in serious injury or death.

  • Page 7: Safety Cautions

    1. Safety Safety Cautions Use Personal Protective Equipment • Use appropriate personal protective equipment: Foot Respiratory Protection Protection Protection Head Fall Hearing Protection Protection Protection Hand Protection • Wear clothing appropriate to the job. • Remove all jewelry. ST-0004-1 • Tie long hair up and back.
  • Page 8 1. Safety Prevent Roof Damage Due to Vacuum Pressure • Roof damage can result from excessive vacuum or internal pressure from fans or other air moving systems. The manufacturer does not warrant this type of roof damage. • Adequate ventilation or “makeup air” devices must be provided for all powered air handling systems.
  • Page 9 1. Safety Rotating Auger Hazard • Keep clear of rotating augers and moving parts. • Do not remove or modify guards or covers. • Lock-out power source before making adjustments, cleaning, or maintaining equipment. • Failure to follow these precautions will result in serious injury or death.
  • Page 10 1. Safety Stay Clear of Hoisted Equipment • Always use proper lifting or hoisting equipment when assembling or disassembling equipment. • Do not walk or stand under hoisted equipment. • Always use sturdy and stable supports when needed for installation. Not following these safety precautions creates the risk of falling equipment, which can crush personnel and cause serious injury or death.

  • Page 11: Safety Sign-Off Sheet

    1. Safety Safety Sign-Off Sheet Below is a sign-off sheet that can be used to verify that all personnel have read and understood the safety instructions. This sign-off sheet is provided for your convenience and personal record keeping. Date Employee Name Supervisor Name ST-0007 PNEG-4018B 40-Series 2.66"...

  • Page 12: Chapter 2 Decals

    Make sure all roof vents are open and unobstructed. Start roof fans when supply fans are started. Do not operate when conditions exist that may cause roof vent icing. GSI Group, Inc. 217-226-4421 DC-969 PNEG-4018B 40-Series 2.66" Corrugation 18' Diameter Bin - Beta...
  • Page 13 4. Avoid the center of the bin. 5. Wear proper breathing equipment or respirator. Failure to heed these warnings will result in serious injury or death. DC-GBC-1A GSI GROUP, INC. 217-226-4421 WARNING On bin door Warning Unload DC-GBC-2A covers Instructions UNLOADING INSTRUCTIONS: 1.

  • Page 14: Overfill Warning

    2. Decals Overfill Warning DO NOT OVERFILL BIN. Stored grain, although heaped in the center, should be no higher than the roof eaves at the outer edge. (See Figure 2A.) Filling the bin above this point creates excessive internal pressure and may cause swelling and eventual roof failure.

  • Page 15: Chapter 3 General Overview

    These include, but may not be limited to: 1. A stiffener and sidewall gauge layout chart. If such a chart is not included with this manual, contact GSI. 2. Roof instructions must be followed. Roof instructions are included in this manual.
  • Page 16 3. General Overview Figure 3A Anchor Bolt Chords for 18' Diameter 2 Post Bin Diameter # of Anchors Bolt Radius 9' - 4-3/16" Chord 1 4' - 10-1/8" Chord 2 9' - 4-1/4" Chord 3 13' - 2-3/4" PNEG-4018B 40-Series 2.66" Corrugation 18' Diameter Bin - Beta...

  • Page 17: Tools Required For Construction

    3. General Overview Tools Required for Construction General tools needed to perform this construction. 1. Combination wrench set 7/16" to 1" 2. Alignment punches 12" long 3. 1/2" Drive socket set and ratchet 4. Nail aprons or tool pouches to hold supplies 5.

  • Page 18: Guidelines For Construction Procedures And Lifting Jack Usage

    11. At the completion of the tank, set stiffeners over the anchor bolts and measure the tank to ensure it is in a round condition. Consult with GSI for questions on tolerances. NOTE: For 2 ring doors or vehicle traffic doors, special placement issues may apply. Consult the special instructions provided with 2 ring doors or vehicle traffic doors for these options.

  • Page 19: Instructions For Stirring Devices

    3. General Overview Instructions for Stirring Devices Bins are offered in more than one structural series for specific uses. To maintain the warranty, the appropriate “series” grain bin must be used. Consult the sales catalog or contact the Engineering Department for current recommendations. Note that the use of any stirring device with three (3) or more vertical screws may require a heavier than “standard”...

  • Page 20: Guidelines For Placement Of The Decal Sidewall Sheet

    3. General Overview Guidelines for Placement of the Decal Sidewall Sheet Use the following as a general guideline the proper decal sheet placement. NOTE: Refer to the stiffener to sidewall attachment detail and specific gauge sheet for the bin. The decal sheets are located in the third ring from the top.

  • Page 21: Chapter 4 Bolt And Nut Usage

    4. Bolt and Nut Usage Hardware Requirements for Sidewalls and Stiffeners Bolt and Nut Pairings This chart lists the correct nut to use with each size of bolt. Nut Part # Nut Size Type Hex or Flanged Bolt Size Bolt Part # 5/16"...
  • Page 22 4. Bolt and Nut Usage Hardware for 3 Post Sidewall Sheets on Bins that are 18' to 90' Diameter and 105' Bins that are 27 Rings and Shorter Refer to the chart for the hardware requirements for 3 post sidewall sheet connections. Horizontal Seam Vertical Seam Bolt Stiffener to Sidewall...
  • Page 23 CAUTION Grade 2 Bolts Grade 2 bolts are designated with a plain head and are not used in GSI grain bins. Grade 5 Bolts Grade 5 bolts are designated by three (3) slash marks on the head. All 5/16" diameter bolts are to be grade 5 or higher.

  • Page 24: Bolt Identification

    4. Bolt and Nut Usage Bolt Identification Use the following information to identify the bolts and where each must be used during installation. Bolt (S-10260) An S-10260 is a 5/16" x 1" JS bolt that is pre-assembled with a sealing washer. Bolt (S-10260) is used in the following locations: 1.
  • Page 25 4. Bolt and Nut Usage Bolt (S-7485) An S-7485 is a 3/8" x 1" JS hex bolt with flanged head and without a sealing washer. Bolt (S-7485) is used in the following locations: 1. Use to splice the stiffeners together on the flanges. (A flange nut is used on the nut side of the connection.) 2.
  • Page 26 4. Bolt and Nut Usage Bolt (S-7488) An S-7488 is a 3/8" x 1-1/2" JS bolt that is pre-assembled with a sealing washer. Bolt (S-7488) is used in the following locations: 1. Use in all stiffener to sidewall and overlap connections where the sidewall is 9 gauge or thicker.
  • Page 27 4. Bolt and Nut Usage Bolt (S-10250) An S-10250 is a 7/16" x 1-1/4" JS bolt that is pre-assembled with a sealing washer. Bolt (S-10250) is used in the following locations: 1. Use in bins 54' and 60' in diameter. 2.

  • Page 28: Color Chart For Bin Hardware Bucket Lids

    4. Bolt and Nut Usage Color Chart for Bin Hardware Bucket Lids For ease of identification, hardware is separated and identified by buckets with color coded lids. Use the following chart to help identify the correct hardware. Bucket Color Lid Color Description Part # Part #...

  • Page 29: Chapter 5 Assembling Sidewall Sheets

    5. Assembling Sidewall Sheets Color Codes for Sidewall Gauge Identification Use this chart to interpret the color code painted on the corners of the sidewall sheets. Color Codes for Sidewall Gauges Stripe Colors for Special Sidewall Characteristics Sidewall Gauge Color Code Type of Sidewall Stripe Color Blue...

  • Page 30: Caulking Detail For Standard (Non-Laminated) Sheets

    5. Assembling Sidewall Sheets Caulking Detail for Standard (Non-Laminated) Sheets To keep out moisture from overlapping the sheets, it is necessary to apply caulk to each sheet prior to installing. NOTE: Always assemble the sidewall sheets with the overlap in the same direction. 1.
  • Page 31 5. Assembling Sidewall Sheets Figure 5B Caulking Detail as Viewed from Inside of the Bin Ref # Description 10" (25.4 cm) Strip of Caulk 10" (25.4 cm) Strip of Caulk 4. Use the supplied tube caulk to fill the larger gaps that occur with heavier gauges and laminated gauges.

  • Page 32: Caulking Detail For Laminated Quad Pattern Sheets

    5. Assembling Sidewall Sheets Caulking Detail for Laminated Quad Pattern Sheets To keep out moisture from overlapping the sheets, it is necessary to apply caulk to each sheet prior to installing. Caulking and Assembling the Individual Sidewall Sheets Each sidewall sheet must be layered and caulked prior to assembling sidewall sheet seams together. Figure 5C Laminated Quad Punched Sidewall Panel View from Outside of the Bin Ref # Description...
  • Page 33 5. Assembling Sidewall Sheets Figure 5D Laminated Figurate Punched Sidewall Sheets View from Outside of the Bin Ref # Description Strip of Caulking 12" (30.4 cm) Horizontal Strip of Caulking Figure 5E Caulking Between Laminated Figurate Pattern Sheets Ref # Description 12"...
  • Page 34 5. Assembling Sidewall Sheets 1. When assembling two (2) assembled laminated sheets to each other, apply a strip of caulk (A) near the outside edge of the outer sheet, between the outer two (2) rows of bolts and outside the last row of bolts.

  • Page 35: Chapter 6 Base Angle Installation

    6. Base Angle Installation Installing the Base Angle Installing the base angle ring will help reinforce and seal the final ring. What You Should Know The base angle overlap should be offset two (2) holes from the stiffener. Do not place overlap in line with the stiffener.

  • Page 36: Anchor Bolt Detail

    6. Base Angle Installation Anchor Bolt Detail The following is the minimum requirement for anchoring of standard tanks. Refer to sidedraw instructions for special anchoring details. 1. 5/8" Diameter anchor bolt (A) is the minimum allowed, 3/4" diameter anchor bolt (A) is the minimum with sidedraw flume system.

  • Page 37: Installing The Base Angle Shims

    6. Base Angle Installation Installing the Base Angle Shims A section of the base boot plate will rest on top of the base angle, therefore causing the base boot to rest unevenly on the foundation. To offset this, base angle shims are required to ensure the base boot sets evenly on the foundation.

  • Page 38: Anchor Bolt Washer Installation

    6. Base Angle Installation Anchor Bolt Washer Installation Anchor bolt washers help to cover the oversized hole in the base plate. Before You Begin Anchor bolts are secured and base plates installed. 1. Place a square plate washer (B) onto the anchor bolt (A). NOTE: A square plate washer (provided) must be installed between the base stiffener (C) and washer (D).

  • Page 39: Chapter 7 Stiffeners

    7. Stiffeners Stiffener Part Number Description Part numbers are printed on the end of each stiffener with the last two (2) numbers designating the gauge of the material. Example: CTS-216514 will be printed on a 14 gauge, standard 2 ring stiffener. If the stiffener was 8 gauge, it would change the part # to CTS-216508.

  • Page 40: Outside Stiffened Laminated Stiffener To Sidewall (10 Gauge Laminated And Thicker Only)

    7. Stiffeners Outside Stiffened Laminated Stiffener to Sidewall (10 Gauge Laminated and Thicker Only) Use the following information to attach the outside stiffened laminated stiffener to the sidewall. Place a sealing washer (C) between the stiffener and the sidewall sheet on the first stiffener to sidewall bolt down from the horizontal seam (laminated, 10 gauge and thicker only).

  • Page 41: Standard Stiffeners

    7. Stiffeners Standard Stiffeners Use the following information to determine the differences between the types of standard 2 ring stiffeners. (See Figure 7B.) Figure 7B Standard Stiffeners Ref # Part # Description Length Available Gauges CTS-2165XX 2 Ring Stiffener 63.969" (162.5 cm) 8-14 CTS-2161XX 2 Ring Stiffener...

  • Page 42: Top Stiffeners

    7. Stiffeners Top Stiffeners Use the following information to determine the differences between the types of top stiffeners. (See Figure 7C.) Figure 7C Top Stiffeners Ref # Part # Description Length Available Gauges CTS-2069XX Inside Stiffener (For Roof) 23.938" (61 cm) 2-14 CTS-2185XX 1 Ring Top Stiffener (Close-Punch)

  • Page 43: Stiffeners Splice

    7. Stiffeners Stiffeners Splice Use the following information to determine the gauge of the splice needed to connect the stiffeners. (See Figure 7D.) Figure 7D Stiffener Splice Ref # Part # Description Length Available Gauges CTS-2177XX Stiffener Long Splice 15.906" (40.4 cm) CTS-2164XX Stiffener Splice (Close Punch) 9.906"...

  • Page 44: Base Stiffeners

    7. Stiffeners Base Stiffeners Use the following information to determine the differences between the base stiffeners. (See Figure 7E.) Figure 7E Base Stiffeners Ref # Part # Description Length Available Gauges CTS-2189XX Base Stiffener 72.110" (183 cm) CTS-2207XX Base Stiffener 72.110"...

  • Page 45: Base Boots

    7. Stiffeners Base Boots Use the following information to determine the differences between the base boots. (See Figure 7F.) Figure 7F Base Boots Ref # Part # Description Height Base Plate Size Base boot weldment for CTS-2121XX 16 gauge through 9 gauge 11.391"...

  • Page 46: Close-Punch Connection For A 1 Ring Top Stiffener (10-14 Gauge) And A 2 Ring Stiffener (8-14 Gauge)

    7. Stiffeners Close-Punch Connection for a 1 Ring Top Stiffener (10-14 Gauge) and a 2 Ring Stiffener (8-14 Gauge) Refer to following information for a close-punch connection of a 1 ring top stiffener (CTS-2202XX) to a 2 ring stiffener (CTS-2165XX). (See Figure 7H.) Ref # Part #...

  • Page 47: Ring Top Stiffener (15-16 Gauge) To A 2 Ring Stiffener (15-16 Gauge) Connection

    7. Stiffeners 2 Ring Top Stiffener (15-16 Gauge) to a 2 Ring Stiffener (15-16 Gauge) Connection Refer to following information when connecting a 2 ring top stiffener (CTS-2169XX) to a 2 ring stiffener (CTS-2161XX). (See Figure 7J.) Ref # Part # Description CTS-2169XX 2 Ring Top Stiffener...

  • Page 48: Ring Top Stiffener (8-14 Gauge) To A 2 Ring Stiffener (8-14 Gauge) Connection

    7. Stiffeners 2 Ring Top Stiffener (8-14 Gauge) to a 2 Ring Stiffener (8-14 Gauge) Connection Refer to following information when connecting a 2 ring top stiffener (CTS-2193XX) to a 2 ring stiffener (CTS-2165XX). (See Figure 7L.) Ref # Part # Description CTS-2193XX 2 Ring Top Stiffener...

  • Page 49: Close-Punch Connection For A 2 Ring Top Stiffener (16 Gauge) To A 2 Ring Stiffener (8-14 Gauge)

    7. Stiffeners Close-Punch Connection for a 2 Ring Top Stiffener (16 Gauge) to a 2 Ring Stiffener (8-14 Gauge) Refer to following information for a close-punch connection of a 2 ring top stiffener (CTS-2182XX) to a 2 ring stiffener (CTS-2166XX). (See Figure 7N.) Ref # Part #...

  • Page 50: Close-Punch Connection For A 2 Ring Stiffener (16 Gauge) To A 2 Ring Stiffener (16 Gauge)

    7. Stiffeners Close-Punch Connection for a 2 Ring Stiffener (16 Gauge) to a 2 Ring Stiffener (16 Gauge) Refer to following information for a close-punch connection of a 2 ring stiffener (CTS-2163XX) to a 2 ring stiffener (CTS-2163XX). (See Figure 7P.) Ref # Part # Description...

  • Page 51: Close-Punch Connection For A 2 Ring Stiffener (8-14 Gauge) To A 2 Ring Stiffener (8-14 Gauge)

    7. Stiffeners Close-Punch Connection for a 2 Ring Stiffener (8-14 Gauge) to a 2 Ring Stiffener (8-14 Gauge) Refer to following information for a close-punch connection of a 2 ring stiffener (CTS-2166XX) to a 2 ring stiffener (CTS-2166XX). (See Figure 7R.) Ref # Part # Description...

  • Page 52: Ring Stiffener (8-14 Gauge) To A Close-Punch Base Stiffener (8 Gauge) Connection

    7. Stiffeners 2 Ring Stiffener (8-14 Gauge) to a Close-Punch Base Stiffener (8 Gauge) Connection Refer to following information when connecting a 2 ring stiffener (CTS-2165XX) to a close-punch 2 ring stiffener (CTS-2207XX). (See Figure 7T.) Ref # Part # Description CTS-2165XX 2 Ring Stiffener...

  • Page 53: Ring Stiffener (8-14 Gauge) To A Close-Punch Base Stiffener (2-6 Gauge) Connection

    7. Stiffeners 2 Ring Stiffener (8-14 Gauge) to a Close-Punch Base Stiffener (2-6 Gauge) Connection Refer to following information when connecting a 2 ring stiffener (CTS-2165XX) to a close-punch 2 ring stiffener (CTS-2189XX). (See Figure 7V.) Ref # Part # Description CTS-2165XX 2 Ring Stiffener...

  • Page 54: Close-Punch Connection For A 2 Ring Stiffener (8-14 Gauge) To A Base Stiffener (8 Gauge)

    7. Stiffeners Close-Punch Connection for a 2 Ring Stiffener (8-14 Gauge) to a Base Stiffener (8 Gauge) Refer to following information when connecting a 2 ring stiffener (CTS-2166XX) to a base stiffener (CTS-2207XX). (See Figure 7X.) Ref # Part # Description CTS-2166XX Close-Punch 2 Ring Stiffener...

  • Page 55: Close-Punch Connection For A 2 Ring Stiffener (2-6 Gauge) To A Base Stiffener (2-6 Gauge)

    7. Stiffeners Close-Punch Connection for a 2 Ring Stiffener (2-6 Gauge) to a Base Stiffener (2-6 Gauge) Refer to following information when connecting a 2 ring stiffener (CTS-2162XX) to a base stiffener (CTS-2189XX). (See Figure 7Z.) Ref # Part # Description CTS-2162XX Close-Punch 2 Ring Stiffener...

  • Page 56: Ring Stiffener (8-14 Gauge) To A Base Stiffener (10-14 Gauge) Connection

    7. Stiffeners 2 Ring Stiffener (8-14 Gauge) to a Base Stiffener (10-14 Gauge) Connection Refer to following information when connecting a 2 ring stiffener (CTS-2165XX) to a base stiffener (CTS-2200XX). (See Figure 7AB.) Ref # Part # Description CTS-2165XX 2 Ring Stiffener CTS-2200XX Base Stiffener CTS-2164XX...

  • Page 57: Ring Stiffener (15-16 Gauge) To A Base Stiffener (10-14 Gauge) Connection

    7. Stiffeners 2 Ring Stiffener (15-16 Gauge) to a Base Stiffener (10-14 Gauge) Connection Refer to following information when connecting a 2 ring stiffener (CTS-2161XX) to a base stiffener (CTS-2200XX). (See Figure 7AD.) Ref # Part # Description CTS-2161XX 2 Ring Stiffener CTS-2200XX Base Stiffener CTS-2164XX...

  • Page 58: Close-Punch 2 Ring Stiffener (2-6 Gauge) To A Laminated Stiffener (2 Gauge) With An Insert (10-12 Gauge)

    7. Stiffeners Close-Punch 2 Ring Stiffener (2-6 Gauge) to a Laminated Stiffener (2 Gauge) with an Insert (10-12 Gauge) Refer to following information for a close-punch connection with a 2 ring stiffener (CTS-2162XX) to a laminated stiffener (CTS-2210XX) and insert (CTS-2211XX). (See Figure 7AF.) Ref # Part #...

  • Page 59: Close-Punch Laminated Stiffeners (2 Gauge) With An Inserts (10-12 Gauge)

    7. Stiffeners Close-Punch Laminated Stiffeners (2 Gauge) with an Inserts (10-12 Gauge) Refer to following information for a close-punch connection of a laminated stiffener (CTS-2228XX) to a laminated stiffener (CTS-2229XX). (See Figure 7AH.) Ref # Part # Description CTS-2228XX Close-Punch Laminated Stiffener CTS-2229XX Close-Punch Insert S-7485...

  • Page 60: Base Stiffener (10-14 Gauge) To A Base Boot Connection

    7. Stiffeners Base Stiffener (10-14 Gauge) to a Base Boot Connection Refer to following information when connecting a base stiffener (CTS-2200XX) to a base boot (CTS-2121XX). (See Figure 7AJ.) Ref # Part # Description CTS-2200XX Base Stiffener CTS-2121XX Base Boot S-7485 3/8"...

  • Page 61: Close-Punch Connection For A Base Stiffener (8 Gauge) To A Base Boot

    7. Stiffeners Close-Punch Connection for a Base Stiffener (8 Gauge) to a Base Boot Refer to following information for a close-punch connection for a base stiffener (CTS-2207XX) to a base boot (CTS-2110XX). (See Figure 7AL.) Ref # Part # Description CTS-2207XX Close-Punch Base Stiffener CTS-2110XX...

  • Page 62: Close-Punch Connection For A Base Stiffener (2-6 Gauge) To A Base Boot

    7. Stiffeners Close-Punch Connection for a Base Stiffener (2-6 Gauge) to a Base Boot Refer to following information for a close-punch connection for a base stiffener (CTS-2219XX) to a base boot (CTS-2131XX). (See Figure 7AN.) Ref # Part # Description CTS-2219XX Close-Punch Base Stiffener CTS-2131XX...

  • Page 63: Close-Punch Laminated Base Stiffener (2 Gauge) With Insert (10-12 Gauge) To A Base Boot

    7. Stiffeners Close-Punch Laminated Base Stiffener (2 Gauge) with Insert (10-12 Gauge) to a Base Boot Refer to following information when connecting a close-punch laminated base stiffener (CTS-2210XX) with insert (10-12 Gauge) (CTS-2211XX) to a base boot (CTS-2109XX or CTS-2110XX). (See Figure 7AP.) Ref # Part #...

  • Page 64: 12-Bolt Pattern Close-Punch Laminated Stiffeners With Insert

    7. Stiffeners 12-Bolt Pattern Close-Punch Laminated Stiffeners with Insert Refer to following information for a close-punch connection of two (2) 12-bolt pattern laminated stiffeners (CTS-2183XX) with an inserts (CTS-2184XX). (See Figure 7AR.) Ref # Part # Description CTS-2183XX Close-Punch Laminated Stiffener CTS-2184XX Close-Punch Insert S-7485...

  • Page 65: Close-Punch 12-Bolt Pattern Laminated Stiffener To Laminated Base Stiffener With An Inserts To A Base Boot

    7. Stiffeners Close-Punch 12-Bolt Pattern Laminated Stiffener to Laminated Base Stiffener with an Inserts to a Base Boot Refer to following information for a close-punch connection of a 12-bolt pattern laminated stiffener (CTS-2183XX) to a laminated base stiffener (CTS-2194XX) with a inserts (CTS-2184XX and CTS-2195XX) to a base boot (CTS-2109XX or CTS-2110XX).

  • Page 66: Chapter 8 Roof Assembly

    8. Roof Assembly Installing the Roof Rafter Bracket to the Top Outside Stiffener The roof rafter bracket is the vertical member which supports the rafter. It is installed to the inside perimeter of the sidewall sheet at the same time as the top outside stiffener. What You Should Know NOTE: Do not tighten the nuts (C) until all hardware has been installed attaching the rafter bracket, to the sidewall and the outside stiffener.

  • Page 67: Installing The Eave Clip And Intermediate Eave Angle To The Sidewall Sheet

    8. Roof Assembly Installing the Eave Clip and Intermediate Eave Angle to the Sidewall Sheet The eave clips and intermediate eave angles are installed onto the sidewall sheet to assemble the roof panels. 1. Install the eave clips (B) to the sidewall sheet (E) with flange bolts (C) and flange nuts (D). NOTE: Make sure to install the eave clips (B) to the inside of the sidewall sheet (E).

  • Page 68: Attaching The Peak Ring Attach Clips To The Rafter

    8. Roof Assembly Attaching the Peak Ring Attach Clips to the Rafter Peak ring attach clips secure the rafter to the peak ring weldment. What You Should Know Each roof rafter receives two (2) peak ring attach clips. 1. Determine the correct orientation of each rafter (A) by identifying the roof panel holes (E) located near the end of each rafter (A).

  • Page 69: Attaching The Center Collar To Peak Ring Weldment

    8. Roof Assembly Attaching the Center Collar to Peak Ring Weldment The center collar assembly is a three (3) piece design and attaches to the peak ring weldment using the Z-collar support clips (D). 1. Position the Z-collar center collar support clips (D) on to the peak ring weldment as shown in Figure 8D.

  • Page 70: Peak Ring/Center Collar Placement

    8. Roof Assembly Peak Ring/Center Collar Placement Figure 8F gives the approximate height needed to install the center collar. With one sidewall ring in place, position the center collar at the height specified, measuring from the bottom of the center collar to the foundation as shown in Figure 8F.

  • Page 71: Attaching The Rafter Assembly To Roof Rafter Bracket

    8. Roof Assembly Attaching the Rafter assembly to Roof Rafter Bracket Install the lower portion of the rafter assembly to the roof rafter bracket. 1. Position and align the lower portion of the rafter assembly (outside surface) (A) to the roof rafter bracket (B).

  • Page 72: Attaching The Rafter Assembly To Peak Ring Weldment

    8. Roof Assembly Attaching the Rafter Assembly to Peak Ring Weldment The rafter assembly must be installed to support the peak ring weldment and main roof structure. Before You Begin The center collar and peak ring weldment should be assembled and secured to the support pole and the rafter assembly should be assembled.

  • Page 73: Assembling The Purlin

    8. Roof Assembly Assembling the Purlin Purlins are horizontal members between the rafters that give support to the roof structure. The length of the purlin determines its location on the rafter assembly. Before You Begin All roof rafter assemblies must be installed and secured to both the peak ring weldment and roof rafter brackets.
  • Page 74 8. Roof Assembly Figure 8J Assembling the Purlin Ref # Part # Description Ref # Part # Description CRP-7334 Roof Rafter S-7488 3/8" x 1-1/2" Flange Bolt CRP-7334 Roof Rafter S-9426 3/8" Flange Nut CRP-7335 Purlin S-7485 3/8" x 1" Flange Bolt CRP-7340 Right Purlin Clip S-9426...

  • Page 75: Installation Of The Roof Panel Support Clips

    8. Roof Assembly Installation of the Roof Panel Support Clips Roof panel support clips will support the roof panel. What You Should Know Roof panel support clips must be installed on each purlin of the roof assembly. 1. Install the roof panel support clip (A) to the outer surface of the purlin (B) using the flange bolts (C) and flange nuts (D).

  • Page 76: Attaching The Roof Panels

    8. Roof Assembly Attaching the Roof Panels Roof panels overlap the previous roof panel, giving protection from outside elements. Rafters and roof panel support clips will support to hold the roof panels. Before You Begin Ensure all roof rafter assemblies and purlins are installed and properly tightened. Pre-determine the manway access location.
  • Page 77 8. Roof Assembly 1. With assistance, position a roof panel (A) onto the roof rafter (D) and install a flange bolt (G) and flange nut (H) securing the upper portion of the roof panel (A). 2. Install five (5) flange bolts with sealing washers (G) and flange nuts (H), into the lower portion of the roof panel (A), securing the panel to the intermediate eave angle (F).
  • Page 78 8. Roof Assembly Figure 8N Installing Roof Panels into Exposed Gaps Ref # Part # Description CTR-0380 Roof Panel Exposed Gap S-10260 5/16" x 1" Flange Bolt with Sealing Washer S-3611 5/16" Flange Nut Upper Rib Lower Rib 5. When all roof panels within a group are in place, install the remaining flange bolts (G) and flange nuts (H) along the roof ribs and tighten.

  • Page 79: Installing The Roof Flashing

    8. Roof Assembly Figure 8O Field Drill Holes Ref # Part # Description Ref # Part # Description CTR-0380 Roof Panel CRP-7338 Roof Panel Support Clip Roof Panel Holes (Drilled through roof panel CRP-7334 Roof Rafter (Under roof panel) support clips.) (Three (3) per roof panel.) 5/16"...
  • Page 80 8. Roof Assembly Figure 8P Installation of the First Roof Flashing Section Ref # Part # Description Ref # Part # Description CTR-0639 Roof Flashing S-3611 5/16" Flange Nut CTR-0380 Roof Panel S-7485 3/8" x 1" Flange Bolt CRP-4608 Center Collar S-9426 3/8"...

  • Page 81: Roof Ring Location (Optional)

    8. Roof Assembly Roof Ring Location (Optional) To determine the location of the roof rings, start at the wide or eave of the roof panel and count up each hole. Having counted up the required distance, as described in the table below, install the appropriate brackets.

  • Page 82: Installing A Roof Ring

    8. Roof Assembly Installing a Roof Ring Quantity and part numbers of roof ring kits vary with the location placement and with the size of each bin. The following procedure will be similar for each kit. 1. Determine the quantity of roof ring clips (C) needed for the roof ring section (B) being installed. NOTE: Each roof panel rib must have a roof ring clip installed.
  • Page 83 8. Roof Assembly Installing a Roof Ring (Continued) 5. Locate a threaded stud (F) and install stud nuts (G) evenly and to the center of the threaded stud (F). 6. Install the threaded stud (F) with stud nuts (G) to the end of the roof ring section (B). NOTE: Install the threaded stud (F) to the side where the next roof ring section will be installed.

  • Page 84: Chapter 9 Accessories

    9. Accessories Wind Ring Requirements Wind rings give additional strength against high winds and uneven loads. The quantities and placement of wind rings will depend on the size of bin being constructed. R1 (0.5) R3 (0.00) R4 (0.5) R6 (0.00) R8 (0.25) R10 (0.5) R13 (0.5)

  • Page 85: Installing Wind Rings

    9. Accessories Wind Ring Requirements (Continued) NOTE: Ensure the wind rings are installed in relation to the ladder rungs as shown to meet O.S.H.A. specifications. Figure 9B Ref # Description 1-1/2" (3.81 cm) 4-1/2" (11.43 cm) Installing Wind Rings Installation of wind rings is similar for a 2 and a 3 post bin design, although hardware quantities may vary. What You Should Know Before installing, determine the bin size, sidewall gauge thickness and height.
  • Page 86 9. Accessories Installing Wind Rings (Continued) 1. Install a wind ring bracket (B) to each stiffener (C) using flange bolts (A) and flange nuts (D). NOTE: When installing the wind ring bracket to a 2.66" close punched stiffener, use the bolt holes marked 1, 2, 4 and 5 as shown.
  • Page 87 9. Accessories Installing Wind Rings (Continued) Figure 9D Exploded View of Wind Ring Installed at Upper Portion of Stiffener Ref # Part # Description Varies Flange Bolt with Sealing Washer CTS-1005 Wind Ring Bracket Varies Stiffener Varies Flange Nut CTS-1004-XX (or) Wind Ring Section CTS-1002–XX S-10261...
  • Page 88 NOTES PNEG-4018B 40-Series 2.66" Corrugation 18' Diameter Bin - Beta...

  • Page 89: Chapter 10 Warranty

    12 months from the date of shipment (or, if shipped by vessel, 14 months from the date of arrival at the port of discharge). If, in GSI’s sole judgment, a product is found to have a defect in materials and/or workmanship, GSI will, at its own option and expense, repair or replace the product or refund the purchase price.
  • Page 90 Authorities having jurisdiction should be consulted before installations are made. 1004 E. Illinois St. Assumption, IL 62510-0020 Phone: 1-217-226-4421 Fax: 1-217-226-4420 www.gsiag.com GSI is a worldwide brand of AGCO Corporation. Copyright © 2016 by The GSI Group, LLC Printed in the USA CN-325313...
