Page 1 36 Ft Diameter Bin Models: 2.66 IN. CORRUGATION 40–SERIES BIN WITH 10000 LB. PEAK LOAD ROOF Construction Manual PNEG-4036-10 Version 1.2 Date: 11-17-20 PNEG-4036-10...
Page 2 All information, illustrations, photos, and specifications in this manual are based on the latest information available at the time of publication. The right is reserved to make changes at any time without notice. Pneg-4036-10 36 Ft Diameter Bin with 10K Roof...
Page 3: Table Of Contents
Contents Chapter 1 Safety Precautions ........................7 Safety Guidelines for Bins ......................8 Cautionary Symbol Definitions......................9 Safety Cautions.........................10 Safety Decals ...........................12 Safety Sign-off Sheet.........................14 Chapter 2 General Overview ........................15 General Information........................15 Anchor Bolt Charts ........................16 Tools Required for Construction....................18 Guidelines for Proper Storage of Grain Bin Materials Prior to Construction........18 Overview for a Typical Bin Installation ..................19 Guidelines for Construction Procedures and Lifting Jack Usage............20 Guidelines for Placement of the Decal Sidewall Sheet..............21...
Page 4 Close-Punch Connection for a One-Ring Top Stiffener (10 – 14 Ga) and a Two-Ring Stiffener (8 – 14 Ga) ........................53 Close-Punch Connection for a One-Ring Top Stiffener (10 – 14 Ga) and a Two-Ring Stiffener (15 – 16 Ga) .........................54 Two-Ring Top Stiffener (15 –...
Page 5 Installing the Sidedraw Baffle Chute (Three Post Stiffener) ............126 Installing the Sidedraw Discharge Chute ................... 128 Installing Wind Rings ....................... 134 Assembling Weather Cover for Roller Valve ................136 GSI Group, LLC Limited Warranty ..................137 Pneg-4036-10 36 Ft Diameter Bin with 10K Roof...
Page 6 NOTES Pneg-4036-10 36 Ft Diameter Bin with 10K Roof...
Page 7: Chapter 1 Safety Precautions
Safety Precautions Topics Covered in this Chapter ▪ Safety Guidelines for Bins ▪ Cautionary Symbol Definitions ▪ Safety Cautions ▪ Safety Decals ▪ Safety Sign-off Sheet Pneg-4036-10 36 Ft Diameter Bin with 10K Roof...
Page 8: Safety Guidelines For Bins
Chapter 1: Safety Precautions Safety Guidelines for Bins Safety guidelines must be followed at all times. This manual is written to help you understand safe operat- ing procedures and problems that can be encountered by the operator and other personnel when using this equipment.
Page 9: Cautionary Symbol Definitions
Chapter 1: Safety Precautions Cautionary Symbol Definitions Cautionary symbols appear in this manual and on product decals. The symbols alert the user of potential safety hazards, prohibited activities and mandatory actions. To help you recognize this information, we use the symbols that are defined below. Table 1-1 Description of the different cautionary symbols Symbol Description...
Page 10: Safety Cautions
Chapter 1: Safety Precautions Safety Cautions Use Personal Protective Equipment • Use appropriate personal protective equipment: Respiratory Foot Protection Protection Protection Hearing Head Fall Protection Protection Protection Hand Protection • Wear clothing appropriate to the job. • Remove all jewelry. •...
Page 11 Chapter 1: Safety Precautions Maintain Equipment and Work Area • Understand service procedures before doing work. Keep area clean and dry • Never service equipment while it is operating. Keep hands, feet, and clothing away from moving parts • Keep your equipment in proper working condition. Replace worn or broken parts immediately ST-0003–1 Prevent Roof Damage Due to Vacuum Pressure...
Page 12: Safety Decals
The safety decals on your equipment are safety indicators which must be carefully read and understood by all personnel involved in the installation, operation, service and maintenance of the equipment. To replace a damaged of missing decal, contact us to receive a free replacement. GSI Decals 1004 E. Illinois Street Assumption, IL 62510 Phone: 1–217–226–4421...
Page 13 Chapter 1: Safety Precautions Location Decal No. Decal Description Danger Keep Clear of On bin door DC-GBC-1A Augers covers On bin door Warning Unload Instructions DC-GBC-2A covers Pneg-4036-10 36 Ft Diameter Bin with 10K Roof...
Page 14: Safety Sign-Off Sheet
Chapter 1: Safety Precautions Safety Sign-off Sheet Below is a sign-off sheet that can be used to verify that all personnel have read and understood the safety instructions. This sign-off sheet is provided for your convenience and personal record keeping. Date Employee Name Supervisor Name...
Page 15: Chapter 2 General Overview
These include, but may not be limited to: • A stiffener and sidewall gauge layout chart. If such a chart is not included with this manual, contact GSI. • Roof instructions must be followed. Roof instructions are included in this manual.
Page 16: Anchor Bolt Charts
Chapter 2: General Overview Anchor Bolt Charts Prior to setting any anchor bolts, you must be sure to have the correct anchor bolt placement. This is very critical for stiffener alignment during bin erection. NOTE: Refer to the proper chart to find the anchor chord dimensions that correspond to the bin that is being built.
Page 17 Chapter 2: General Overview Figure 2-2 Anchor bolt chords for 36 diameter 3–post bin Radius Location of Bolt (B) Anchor Bolt Quantity ft and in 18 – 3-5/8 5.578 Length Chord (A) ft and in 3 – 2-5/16 0.973 6 – 4-5/16 1.938 9 –...
Page 18: Tools Required For Construction
Chapter 2: General Overview Tools Required for Construction General tools needed to perform this construction: • Combination wrench set 7/16 in. to 1 in. • Alignment punches 12 in. long • 1/2 in. Drive socket set and ratchet • Nail aprons or tool pouches to hold supplies •...
Page 19: Overview For A Typical Bin Installation
Chapter 2: General Overview Overview for a Typical Bin Installation These are the typical steps one would perform when constructing a grain bin. Procedures may vary depending on the different site requirements. Pre-Assembly Activities • Sorting and grouping parts • Assemble A-frames •...
Page 20: Guidelines For Construction Procedures And Lifting Jack Usage
12.At the completion of the tank, set stiffeners over the anchor bolts and measure the tank to ensure it is in a round condition. Consult with GSI for questions on tolerances. NOTE: For 2 ring doors or vehicle traffic doors, special placement issues may apply. Consult the special instructions provided with two ring doors or vehicle traffic doors for these options.
Page 21: Guidelines For Placement Of The Decal Sidewall Sheet
Chapter 2: General Overview Guidelines for Placement of the Decal Sidewall Sheet Use the following as a general guideline for the proper placement of the decal sheet. NOTE: Refer to the stiffener to sidewall attachment detail and specific gauge sheet for the bin. The decal sheets are located in the third ring from the top.
Page 22 NOTES Pneg-4036-10 36 Ft Diameter Bin with 10K Roof...
Page 23: Chapter 3 Hardware Requirements
Hardware Requirements Topics Covered in this Chapter ▪ Bolt and Nut Pairings ▪ Hardware for 2–Post Sidewall Sheets on Bins 18 to 60 Ft in Diameter ▪ Hardware for 3–Post Sidewall Sheets on bins that are 18 to 90 Ft in Diameter and 105 Ft Bins that are 27 Rings and Shorter ▪...
Page 24: Hardware For 2-Post Sidewall Sheets On Bins 18 To 60 Ft In Diameter
Chapter 3: Hardware Requirements Hardware for 2–Post Sidewall Sheets on Bins 18 to 60 Ft in Diameter Reference the chart for hardware requirements for 2–post sidewall sheet connections on bins 18 to 60 ft. in diameter. Table 3-1 Hardware for 2–Post Sidewall Sheets on Bins 18 to 60 ft in Diameter Horizontal Seam Vertical Seam Bolt Stiffener to Sidewall...
Page 25: Bolt Torque Specifications
Chapter 3: Hardware Requirements Table 3-2 Hardware for 3-Post Sidewall Sheets on 18 to 90 ft. bins and 105 ft Diameter Bins that are 27 Rings and shorter (cont'd.) Horizontal Seam Vertical Seam Bolt Stiffener to Sidewall Overlap Seam Bolt Gauge Bolt Size (Quantity) Size (Quantity)
Page 26: Identifying Bolt Grades
Grade 2 bolts are designated with a plain head and are not used in GSI grain bins. Grade 5 Bolts Grade 5 bolts are designated by three slash marks on the head and are not used in GSI grain bins.
Page 27: Color Chart For Bin Hardware Bucket Lids
Chapter 3: Hardware Requirements Color Chart for Bin Hardware Bucket Lids For ease of identification, hardware is separated and identified by buckets with color coded lids. Use the following chart to help identify the correct hardware. JS Part YDP Part Bucket Description Color...
Page 28: Bolt Identification
Chapter 3: Hardware Requirements Bolt Identification Use the following information to identify the bolts and where each must be used during installation. Bolt S-10260 An S–10260 is a 5/16 x 1 in. JS bolt that is pre-assembled with a sealing washer. Bolt (S-10260) is used in the following locations: •...
Page 29: Bolt S-7485
Chapter 3: Hardware Requirements Bolt S-7485 An S–7485 is a 3/8 x 1 in. JS hex bolt with flanged head and without a sealing washer. Bolt (S-7485) is used in the following locations: • Use to splice the stiffeners together on the flanges. (A flange nut is used on the nut side of the connection.) •...
Page 30: Bolt S-7488
Chapter 3: Hardware Requirements Bolt S-7488 An S–7488 is a 3/8 x 1-1/2 in. JS bolt that is pre-assembled with a sealing washer. Bolt (S-7488) is used in the following locations: • Use in all stiffener to sidewall and overlap connections where the sidewall is 9 gauge to 10 gauge laminated.
Page 31: Bolt S-10250
Chapter 3: Hardware Requirements Bolt S-10250 An S–10250 is a 7/16 x 1-1/4 in. JS bolt. Bolt (S-10250) is used in the following locations: • Use in 10,000 lb. peak load roof and Z-tek roof bins 36 ft to 60 ft in diameter.
Page 32 NOTES Pneg-4036-10 36 Ft Diameter Bin with 10K Roof...
Page 33: Chapter 4 Assembling Sidewall Sheets
Assembling Sidewall Sheets Topics Covered in this Chapter ▪ Color Codes for Sidewall Gauge Identification ▪ Orientation Detail for Top Sidewall Sheets ▪ Caulking Detail for Standard (Non-Laminated) Sheets ▪ Caulking Detail for Laminated Quad Pattern Sheets Color Codes for Sidewall Gauge Identification Use this chart to interpret the color code painted on the corners of the sidewall sheets.
Page 34: Orientation Detail For Top Sidewall Sheets
Chapter 4: Assembling Sidewall Sheets Orientation Detail for Top Sidewall Sheets To avoid the misalignment of the holes, it is necessary to use the correct orientation of the sidewall sheet during installation. NOTE: Always assemble the top sidewall sheets with the orientation shown. Figure 4-1 2–Post top sidewall sheet orientation Top of the top sidewall sheet Bottom of the top sidewall sheet...
Page 35: Caulking Detail For Standard (Non-Laminated) Sheets
Chapter 4: Assembling Sidewall Sheets Caulking Detail for Standard (Non-Laminated) Sheets To keep out moisture from overlapping the sheets, apply caulk to each sidewall sheet prior to installation. NOTE: Always assemble the sidewall sheets with the overlap in the same direction. •...
Page 36 Chapter 4: Assembling Sidewall Sheets 10 in. (25.4 cm) Strip of caulk 10 in. (25.4 cm) Strip of caulk • Use the supplied tube caulk to fill the larger gaps that occur with heavier gauges and laminated gauges. See Caulking Detail for Laminated Quad Pattern Sheets, page 37 for details about caulk laminated sidewall sheets.
Page 37: Caulking Detail For Laminated Quad Pattern Sheets
Chapter 4: Assembling Sidewall Sheets Caulking Detail for Laminated Quad Pattern Sheets To keep out moisture from overlapping the sheets, it is necessary to apply caulk to each sheet prior to installing. Caulking and Assembling the Individual Sidewall Sheets Each sidewall sheet must be layered and caulked prior to assembling sidewall sheet seams together. Figure 4-4 Laminated quad punched sidewall panel view from outside of the bin Strip of caulking 12 in.
Page 38 Chapter 4: Assembling Sidewall Sheets • When assembling two assembled laminated sheets to each other, apply a strip of caulk (A) near the outside edge of the outer sheet, between the outer two (2) rows of bolts and outside the last row of bolts.
Page 39: Chapter 5 Base Angle Installation
Base Angle Installation Topics Covered in this Chapter ▪ Installing the Base Angle ▪ Anchor Bolt Detail ▪ Installing the Base Angle Shims ▪ Anchor Bolt Washer Installation Installing the Base Angle Installing the base angle ring will help reinforce and seal the final ring. What You Should Know The base angle overlap should be offset two holes from the stiffener.
Page 40 Chapter 5: Base Angle Installation Figure 5-1 Exploded view of base angle (view from the inside of the bin) Final ring assembly 3/8 in. nut (S-9426) Base angle (B-7031) Base angle offset example 3/8 x 1 in. bolt (S-7487) Optional mastic sealer (or equivalent) Pneg-4036-10 36 Ft Diameter Bin with 10K Roof...
Page 41: Anchor Bolt Detail
Chapter 5: Base Angle Installation Anchor Bolt Detail The following is the minimum requirement for anchoring a standard bin. Refer to sidedraw instructions for special anchoring details. • 5/8 in. diameter anchor bolt (A) is the minimum allowed, 3/4 in. diameter anchor bolt (A) is the mini- mum with side draw flume system.
Page 42: Installing The Base Angle Shims
Chapter 5: Base Angle Installation Installing the Base Angle Shims A section of the base boot plate will rest on top of the base angle, therefore causing the base boot to rest unevenly on the foundation. To offset this, base angle shims are required to ensure the base boot sets evenly on the foundation.
Page 43: Anchor Bolt Washer Installation
Chapter 5: Base Angle Installation Anchor Bolt Washer Installation Anchor bolt washers help to cover the oversized hole in the base plate. Before You Begin Anchor bolts are secured, and base plates installed. 1. Place a square plate washer (B) onto the anchor bolt (A). NOTE: A square plate washer (provided) must be installed between the base boot (C) and washer (D).
Page 44 NOTES Pneg-4036-10 36 Ft Diameter Bin with 10K Roof...
Page 45: Chapter 6 Stiffeners
Stiffeners Topics Covered in this Chapter ▪ Stiffener Part Number Description ▪ Color Codes for Stiffener Gauge Identification ▪ Standard Stiffeners ▪ Top Stiffeners ▪ Stiffeners Splice ▪ Base Stiffeners ▪ Base Boots ▪ Close-Punch Connection for a One-Ring Top Stiffener (15 – 16 Ga) and a Two-Ring Stiffener (15 –...
Page 46 Chapter 6: Stiffeners ▪ Close-Punch Two-Ring Stiffener (2 – 6 Ga) to a Laminated Stiffener (2 Ga) with an Insert (10 – 12 Ga) ▪ Close-Punch Two-Ring Stiffener (2 – 6 Ga) to a Laminated Stiffener (2 Ga) with an Insert (10 –...
Page 47: Stiffener Part Number Description
Chapter 6: Stiffeners Stiffener Part Number Description Part numbers are printed on the end of each stiffener with the last two numbers designating the gauge of the material. Example: CTS-216514 will be printed on a 14 gauge, standard two-ring stiffener. If the stiffener was 8 gauge, it would change the part number to CTS-216508.
Page 48: Standard Stiffeners
Chapter 6: Stiffeners Standard Stiffeners Use the following information to determine the differences between the types of standard two-ring stiffeners. Figure 6-1 Standard stiffeners Call Out Part Number Description Length Available Gauges CTS-2165XX Two-ring stiffener 63.969 in. (162.5 cm) 8 – 14 CTS-2161XX Two-ring stiffener 63.969 in.
Page 49: Top Stiffeners
Chapter 6: Stiffeners Top Stiffeners Use the following information to determine the differences between the types of top stiffeners. Figure 6-2 Images of the top stiffeners Call Part Number Description Length Available Gauges CTS-2069XX Inside stiffener (for roof) 23.938 in. (61 cm) 2 –...
Page 50: Stiffeners Splice
Chapter 6: Stiffeners Stiffeners Splice Use the following information to determine the gauge of the stiffener splice needed to connect the stiffeners. Figure 6-3 Stiffener splice Call Out Part Number Description Length Available Gauges CTS-2177XX Stiffener long 15.906 in. (40.4 splice CTS-2164XX Stiffener splice...
Page 51: Base Stiffeners
Chapter 6: Stiffeners Base Stiffeners Use the following information to determine the differences between the base stiffeners. Figure 6-4 Images of the base stiffeners Call Out Part Number Description Length Available Gauges CTS-2189XX Base stiffener 72.110 in. (183 cm) 2 – 6 CTS-2207XX Base stiffener 72.110 in.
Page 52: Base Boots
Chapter 6: Stiffeners Base Boots Use the following information to determine the differences between the base boots. Figure 6-5 Images of the base boots Part Number Description Height Call Out Base Plate Size CTS-2121XX Base boot weldment for 16 11.391 in. 6 x 9 x 3/8 in.
Page 53: Close-Punch Connection For A One-Ring Top Stiffener (15 - 16 Ga) And A Two-Ring Stiffener (15 - 16 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a One-Ring Top Stiffener (15 – 16 Ga) and a Two-Ring Stiffener (15 – 16 Ga) Reference the following information for a close-punch connection of a one-ring top stiffener (CTS- 2185XX) to a two-ring stiffener (CTS-2163XX). Figure 6-6 One-Ring Top Stiffener (15 –...
Page 54: Close-Punch Connection For A One-Ring Top Stiffener (10 - 14 Ga) And A Two-Ring Stiffener (15 - 16 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a One-Ring Top Stiffener (10 – 14 Ga) and a Two-Ring Stiffener (15 – 16 Ga) Reference the following information for a close-punch connection of a one-ring top stiffener (CTS- 2202XX) to a two-ring stiffener (CTS-2161XX). Figure 6-8 One-Ring Top Stiffener (10 –...
Page 55: Two-Ring Top Stiffener (8 - 14 Ga) To A Two-Ring Stiffener (15 - 16 Ga) Connection
Chapter 6: Stiffeners Two-Ring Top Stiffener (8 – 14 Ga) to a Two-Ring Stiffener (15 – 16 Ga) Connection Reference the following information when connecting a two-ring top stiffener (CTS-2169XX) to a two-ring stiffener (CTS-2161XX). Figure 6-10 Two-Ring Top Stiffener (8 – 14 Ga) to a Two-Ring Stiffener (15 – 16 Ga) Connection Two-ring top stiffener (CTS-2193XX) Two-ring stiffener (CTS-2161XX) Splice (CTS-2164XX)
Page 56: Close-Punch Connection For A Two-Ring Top Stiffener (16 Ga) To A Two-Ring Stiffener (16 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Top Stiffener (16 Ga) to a Two-Ring Stiffener (16 Ga) Reference the following information for a close-punch connection of a two-ring top stiffener (CTS- 2182XX) to a two-ring stiffener (CTS-2163XX). Figure 6-12 Two-Ring Top Stiffener (16 Ga) to a Two-Ring Stiffener (16 Ga) Close-Punch Connection Two-ring top stiffener (CTS-2182XX) Two-ring stiffener (CTS-2163XX) Splice (CTS-2164XX)
Page 57: Two-Ring Stiffener (15 - 16 Ga) To A Two-Ring Stiffener (15 - 16 Ga) Connection
Chapter 6: Stiffeners Two-Ring Stiffener (15 – 16 Ga) to a Two-Ring Stiffener (15 – 16 Ga) Connection Reference the following information when connecting a two-ring stiffener (CTS-2161XX) to a two-ring stiff- ener (CTS-2161XX). Figure 6-14 Two-Ring Stiffener (15 – 16 Ga) to a Two-Ring Stiffener (15 –16 Ga) Connection Two-ring stiffener (CTS-2161XX) Two-ring stiffener (CTS-2161XX) Splice (CTS-2164XX)
Page 58: Two-Ring Stiffener (8 - 14 Ga) To A Two-Ring Stiffener (8 - 14 Ga) Connection
Chapter 6: Stiffeners Two-Ring Stiffener (8 – 14 Ga) to a Two-Ring Stiffener (8 – 14 Ga) Connection Reference the following information when connecting a two-ring stiffener (CTS-2165XX) to a two-ring stiff- ener (CTS-2165XX). Figure 6-16 Two-Ring Stiffener (8 – 14 Ga) to a Two-Ring Stiffener (8 – 14 Ga) Connection Two-ring stiffener (CTS-2165XX) Two-ring stiffener (CTS-2165XX) Splice (CTS-2164XX)
Page 59: Close-Punch Connection For A Two-Ring Stiffener (2 - 6 Ga) To A Two-Ring Stiffener
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Stiffener (2 – 6 Ga) to a Two-Ring Stiffener (2 – 6 Ga) Reference the following information for a close-punch connection of a two-ring stiffener (CTS-2162XX) to a two-ring stiffener (CTS-2162XX). Figure 6-18 Two-Ring Stiffener (2 – 6 Ga) to a Two-Ring Stiffener (2 – 6 Ga) Close-Punch Connection Two-ring stiffener (CTS-2162XX) Two-ring stiffener (CTS-2162XX) Splice (CTS-2177XX)
Page 60: Two-Ring Stiffener (8 - 14 Ga) To A Close-Punch Base Stiffener (8 Ga) Connection
Chapter 6: Stiffeners Two-Ring Stiffener (8 – 14 Ga) to a Close-Punch Base Stiffener (8 Ga) Connection Reference the following information when connecting a two-ring stiffener (CTS-2165XX) to a close-punch two-ring stiffener (CTS-2220XX). Figure 6-20 Two-Ring Stiffener (8 – 14 Ga) to a Close-Punch Two-Ring Stiffener (8 Ga) Connection Two-ring stiffener (CTS-2165XX) Close-punch two-ring stiffener (CTS-2220XX) Splice (CTS-2164XX)
Page 61: Two-Ring Stiffener (8 - 14 Ga) To A Close-Punch Base Stiffener (2 - 6 Ga) Connection
Chapter 6: Stiffeners Two-Ring Stiffener (8 – 14 Ga) to a Close-Punch Base Stiffener (2 – 6 Ga) Connection Reference the following information when connecting a two-ring stiffener (CTS-2165XX) to a close-punch two-ring stiffener (CTS-2219XX). Figure 6-22 Two-Ring Stiffener (8 – 14 Ga) to a Close-Punch Two-Ring Stiffener (2 – 6 Ga) Connection Two-ring stiffener (CTS-2165XX) Close-punch two-ring stiffener (CTS-2219XX) Splice (CTS-2177XX)
Page 62: Close-Punch Connection For A Two-Ring Stiffener (8 - 14 Ga) To A Base Stiffener (8 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Stiffener (8 – 14 Ga) to a Base Stiffener (8 Ga) Reference the following information when connecting a two-ring stiffener (CTS-2166XX) to a base stiff- ener (CTS-2220XX). Figure 6-24 Two-Ring Stiffener (8 – 14 Ga) to a Two-Ring Base Stiffener (8 Ga) Close-Punch Connection Close-punch two-ring stiffener (CTS-2166XX) Close-punch base stiffener (CTS-2220XX) Splice (CTS-2164XX)
Page 63: Close-Punch Connection For A Two-Ring Stiffener (2 - 6 Ga) To A Base Stiffener (2 - 6 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Stiffener (2 – 6 Ga) to a Base Stiffener (2 – 6 Ga) Reference the following information when connecting a two-ring stiffener (CTS-2162XX) to a base stiff- ener (CTS-2219XX). Figure 6-26 Two-Ring Stiffener (2 – 6 Ga) to a Two-Ring Base Stiffener (6 Ga) Close-Punch Connection Close-punch two-ring stiffener (CTS-2162XX) Close-punch base stiffener (CTS-2219XX) Splice (CTS-2177XX)
Page 64: Two-Ring Stiffener (8 - 14 Ga) To A Base Stiffener (10 - 14 Ga) Connection
Chapter 6: Stiffeners Two-Ring Stiffener (8 – 14 Ga) to a Base Stiffener (10 – 14 Ga) Connection Reference the following information for a close-punch connection of a two-ring stiffener (CTS-2166XX) to a base stiffener (CTS-2188XX). Figure 6-28 Two-Ring Stiffener (8 – 14 Ga) to a Base Stiffener (10 – 14 Ga) Close-Punch Connection Close-punch two-ring stiffener (CTS-2166XX) Close-punch base stiffener (CTS-2188XX) Splice (CTS-2164XX)
Page 65: Close-Punch Connection For A Two-Ring Stiffener (15 - 16 Ga) To A Base Stiffener
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Stiffener (15 – 16 Ga) to a Base Stiffener (10 – 14 Ga) Reference the following information for a close-punch connection of a two-ring stiffener (CTS-2163XX) to a base stiffener (CTS-2188XX). Figure 6-30 Two-Ring Stiffener (15 – 16 Ga) to a Base Stiffener (10 – 14 Ga) Close-Punch Connection Close-punch two-ring stiffener (CTS-2163XX) Close-punch base stiffener (CTS-2188XX)
Page 66: Close-Punch Two-Ring Stiffener (2 - 6 Ga) To A Laminated Stiffener (2 Ga) With An Insert (10 - 12 Ga)
Chapter 6: Stiffeners Close-Punch Two-Ring Stiffener (2 – 6 Ga) to a Laminated Stiffener (2 Ga) with an Insert (10 – 12 Ga) Reference the following information for a close-punch connection with a two-ring stiffener (CTS-2162XX) to a laminated stiffener (CTS-2229XX) and insert (CTS-2228XX). Figure 6-32 Close-Punch Two-Ring Stiffener to a Laminated Stiffener with an Insert Close-punch two-ring stiffener (CTS-2162XX) Close-punch laminated stiffener...
Page 67: Close-Punch Laminated Stiffener (2 Ga) With An Insert (10 - 12 Ga) To A Laminated Base Stiffener (2 Ga) With A Base Insert (10 - 12 Ga)
Chapter 6: Stiffeners Close-Punch Laminated Stiffener (2 Ga) with an Insert (10 – 12 Ga) to a Laminated Base Stiffener (2 Ga) with a Base Insert (10 – 12 Ga) Reference the following information for a close-punch connection of a two-ring stiffener (CTS-2228XX and CTS-2229XX) to a laminated base stiffener and insert (CTS-2210XX and CTS-2211XX).
Page 68: Close-Punch Connection For A Base Stiffener (10 - 14 Ga) To A Base Boot
Chapter 6: Stiffeners Close-Punch Connection for a Base Stiffener (10 – 14 Ga) to a Base Boot Reference the following information for a close-punch connection for a base stiffener (CTS-2188XX) to a base boot (CTS-2121XX). Figure 6-36 Base Stiffener (10 – 14 Ga) to a Base Boot Close-Punch Connection Close-punch base stiffener (CTS-2188XX) Close-punch base boot (CTS-2121XX) 3/8 x 1 Bolt (S-7485)
Page 69: Close-Punch Connection For A Base Stiffener (2 - 6 Ga) To A Base Boot
Chapter 6: Stiffeners Close-Punch Connection for a Base Stiffener (2 – 6 Ga) to a Base Boot Reference the following information for a close-punch connection for a base stiffener (CTS-2189XX) to a base boot (CTS-2110XX). Figure 6-38 Base Stiffener (2 – 6 Ga) to a Base Boot Close-Punch Connection Close-punch base stiffener (CTS-2189XX) Close-punch base Boot (CTS-2110XX) 3/8 x 1 Bolt (S-7485)
Page 70: Close-Punch Connection For A Base Stiffener (8 Ga) To A Base Boot
Chapter 6: Stiffeners Close-Punch Connection for a Base Stiffener (8 Ga) to a Base Boot Reference the following information for a close-punch connection for a base stiffener (CTS-2220XX) to a base boot (CTS-2131X). Figure 6-40 Base Stiffener (8 Ga) to a Base Boot Close-Punch Connection Close-punch base stiffener (CTS-2220XX) Close-punch base Boot (CTS-2131XX) 3/8 x 1 Bolt (S-7485)
Page 71: Close-Punch Standard Stiffener To A 12-Bolt Pattern Laminated Stiffener With Insert
Chapter 6: Stiffeners Close-Punch Standard Stiffener to a 12–Bolt Pattern Laminated Stiffener with Insert Reference the following information for a close-punch connection of a standard stiffener (CTS-2162) to a 12–bolt pattern laminated stiffener (CTS-2183XX) with insert (CTS-2184XX). Figure 6-42 Close-Punch Standard Stiffener to a 12–Bolt Pattern Laminated Stiffener with Insert Close punch standard stiffener (CTS-2162XX) Close-punch laminated stiffener (CTS-2183XX) Close-punch insert (CTS-2184XX)
Page 72: Close-Punch 12-Bolt Pattern Laminated Stiffener To Laminated Base Stiffener With An Inserts To A Base Boot
Chapter 6: Stiffeners Close-Punch 12–Bolt Pattern Laminated Stiffener to Laminated Base Stiffener with an Inserts to a Base Boot Reference the following information for a close-punch connection of a 12–bolt pattern laminated stiffener (CTS-2183) to a laminated base stiffener (CTS-2196XX) with a inserts (CTS-2184XX and CTS-2196XX) to a base boot (CTS-2131XX).
Page 73: Close-Punch 12-Bolt Pattern Laminated Stiffener To Laminated Base Stiffener With An Inserts To A Base Boot
Chapter 6: Stiffeners Close-Punch 12–Bolt Pattern Laminated Stiffener to Laminated Base Stiffener with an Inserts to a Base Boot Reference the following information for a close-punch connection of a 12–bolt pattern laminated stiffener (CTS-2183) to a laminated base stiffener (CTS-2194XX) with a inserts (CTS-2184XX and CTS-2195XX) to a base boot (CTS-2109XX or CTS-2110XX).
Page 74 NOTES Pneg-4036-10 36 Ft Diameter Bin with 10K Roof...
Page 75: Chapter 7 Roof Assembly
Roof Assembly Topics Covered in this Chapter ▪ Installing the Roof Rafter Bracket to the Top Outside Stiffener ▪ Installing the Eave clip and Intermediate Eave Angle to the Sidewall Sheet ▪ Attaching the Center Collar Rafter Clips to the Rafter ▪...
Page 76: Installing The Roof Rafter Bracket To The Top Outside Stiffener
Chapter 7: Roof Assembly Installing the Roof Rafter Bracket to the Top Outside Stiffener The roof rafter bracket is the vertical member which supports the rafter. It is installed to the inside perime- ter of the sidewall sheet at the same time as the top outside stiffener. What You Should Know NOTE: Do not tighten the nuts (C) until all hardware has been installed attaching the rafter bracket, to the sidewall and the outside stiffener.
Page 77: Installing The Eave Clip And Intermediate Eave Angle To The Sidewall Sheet
Chapter 7: Roof Assembly Installing the Eave clip and Intermediate Eave Angle to the Sidewall Sheet The eave clips and intermediate eave angles are installed onto the sidewall sheet to assemble the roof panels. 1. Install the eave clips (B) to the sidewall sheet (A) with flange bolts (C) and flange nuts (D). NOTE: Make sure to install the eave clips to the inside of the sidewall sheet.
Page 78: Attaching The Center Collar Rafter Clips To The Rafter
Chapter 7: Roof Assembly Attaching the Center Collar Rafter Clips to the Rafter Center collar rafter clips secure the rafters to the center collar. What You Should Know Each roof rafter receives two center collar rafter clips, identified as the left center collar rafter clip (D) and the right center collar rafter clip (E).
Page 79: Assembling The Mounting Brackets To The Center Collar
Chapter 7: Roof Assembly Assembling the Mounting Brackets to the Center Collar There are six mounting brackets that may need to be assembled to the center collar before it is lifted onto the roof with the center pole. The center cap plate will me mounted to the mounting brackets assembled to the center collar.
Page 80: Center Collar Placement
Chapter 7: Roof Assembly Center Collar Placement The following figure gives the approximate height needed to install the center collar. With two sidewall rings in place, position the center collar at the height specified, measuring from the bottom of the center collar to the foundation as shown. If additional rings are required for construction pur- poses, add 32 in.
Page 81: Assembling The Rafters
Chapter 7: Roof Assembly Assembling the Rafters What You Should Know Each rafter will consist of a two piece design and will need to be spliced together for assembling the rafter onto the roof. 1. Position an upper rafter (A) in line with a lower rafter (B), and attach a rafter splice (C) to the outside mating surface of the two rafters.
Page 82 Chapter 7: Roof Assembly Figure 7-6 Rafter assembly exploded view Upper rafter (CTR-1340) 3/8 in. x 1-1/2 in. flange bolt (S-7486) Lower rafter (CTR-1341) 3/8 in. flange nut (S-9426) Roof stiffener splice (PR-1874) 3/8 in. x 1 in. flange bolt (S-7485) Purlin clip (CRP-6211) 3/8 in.
Page 83: Attaching The Rafter Assembly To Roof Rafter Bracket
Chapter 7: Roof Assembly Attaching the Rafter assembly to Roof rafter Bracket Install the lower portion of the rafter assembly to the roof rafter bracket. 1. Position and align the lower portion of the rafter assembly (outside surface) (A) to the roof rafter bracket (B).
Page 84: Attaching The Rafter Assembly To Center Collar
Chapter 7: Roof Assembly Attaching the Rafter Assembly to Center Collar The rafter assembly must be installed to support the center collar and main roof structure. Before You Begin The center collar should be assembled and secured to the support pole, and the rafter assembly should be assembled.
Page 85: Assembling Purlin Number 2
Chapter 7: Roof Assembly Assembling Purlin Number 2 Purlins are horizontal members between the rafters that give support to the roof structure. The length of the purlin determines its location on the rafter assembly. Before You Begin All roof rafter assemblies must be installed and secured to both the center collar and roof truss stiffener brackets.
Page 86: Assembling Purlin Number 1
Chapter 7: Roof Assembly Assembling Purlin Number 1 Purlins are horizontal members between the rafters that give support to the roof structure. The length of the purlin determines its location on the rafter assembly. Before You Begin All roof rafter assemblies must be installed and secured to both the center collar and roof truss stiffener brackets.
Page 87: Installing The Tension Rods
Chapter 7: Roof Assembly Installing the Tension Rods Tension rods connect to the rafter brackets through the rafter and are installed around the inside of the bin. Before You Begin Make sure all the rafters are installed before proceeding the installation of tension rods. What You Should Know 1.
Page 88: Installing The Roof Panel Clip And Roof Panel Clip Bracket
Chapter 7: Roof Assembly Installing the Roof Panel Clip and Roof panel clip bracket The roof panel clips are located at the top of the roof rafters nearest to the center collar rafter clips. Before You Begin All rafter assemblies should be fully assembled and installed to the center collar and the roof truss brackets.
Page 89: Installing The Temperature Cable Support Brackets (Optional)
GSI is not responsible for the effectiveness or performance of any tem- perature cable monitoring system or layout.
Page 90 Chapter 7: Roof Assembly 4. Install a quick link (C) to each cable bracket to support the temperature cables. IMPORTANT: Do not attach weights to the temperature cables; secure the bottom of cables to the floor with light twine. No support channel shall support more than one cable. Figure 7-14 Supplier quick link Temperature cable hanging bracket (CRP- Supplier quick link...
Page 91: Installing The Roof Panels
Chapter 7: Roof Assembly Installing the Roof Panels Roof panels overlap the previous roof panel, giving protection from outside elements. Rafters and rib sup- port clips will support to hold the roof panels. Before You Begin Ensure all roof rafter assemblies and purlins are installed and properly tightened. Pre determine the manway access location.
Page 92 Chapter 7: Roof Assembly 2. Install the flange bolts (G) and flange nuts (H) securing the top portion of roof panel (A) to the roof panel clips (D). NOTE: Do not tighten bolts until the roof is completely assembled. 3. Secure the roof panel ribs to the rafter (C) with the flange bolts (G) and flange nuts (H) . 4.
Page 93 Chapter 7: Roof Assembly IMPORTANT: Tuck the last roof panel per gap under the previously installed roof panel by slightly lifting the side rib and allowing the new adjacent roof panel to be tucked under the previously installed roof panel. 6.
Page 94: Installing The Roof Flashing
Chapter 7: Roof Assembly Installing the Roof Flashing The roof flashing will seal the area between the center collar and the roof panels. What You Should Know Each roof flashing section overlaps and bolts together with the previously installed roof flashing section. 1.
Page 95 Chapter 7: Roof Assembly 6. Install flange bolts (B) and flange nuts (C), securing the roof flashing section (A) to the roof panel ribs. 7. Continue installing the remaining flashing until the gap between the center collar and roof panels is covered.
Page 96: Installing The Center Cap Plate
Chapter 7: Roof Assembly Installing the Center Cap Plate Center cap plate will need to be installed on top of the roof flashings. 1. Place a continuous strip of caulk (A) on the mating surface of the roof flashing (B). 2.
Page 97: Installing The Stand-Off Plates
Chapter 7: Roof Assembly Installing the Stand-off Plates Four stand-off plates are attached to the roof flashing and center cap plate as a standard option. If catwalk system has to be installed, replace the stand-off plates with the conveyor support brackets. 1.
Page 98 NOTES Pneg-4036-10 36 Ft Diameter Bin with 10K Roof...
Page 99: Chapter 8 Accessories
Accessories Topics Covered in this Chapter ▪ Installing Roof Ladder Steps ▪ Roof Ring Placement (Optional) ▪ Installing a Roof Ring ▪ Installation of Peak–To– Exhauster Ladder Kit ▪ Preparation for Roof Exhauster Installation ▪ Assembly of Roof Exhauster ▪ Installing Roof Exhauster Assembly ▪...
Page 100: Installing Roof Ladder Steps
Chapter 8: Accessories Installing Roof Ladder Steps Roof ladder steps will allow access to roof and manway access. What You Should Know Each eave-to-peak ladder step differs with the diameter of each bin. When installing the ladder steps, always start from the eave and work up toward the peak, installing the longest step first and the shortest step last.
Page 101 Chapter 8: Accessories Use the following table as a guide to the location of each ladder step (rung). Table 8-1 Ladder Rung Placement Chart Bin Diameter Location 36 ft. 42 ft. 48 ft. 54 ft. 60 ft. 66 ft. ↑ LS-260-3 LS-260-4 Bin Peak...
Page 102: Roof Ring Placement (Optional)
Chapter 8: Accessories Roof Ring Placement (Optional) The roof ring is a tubular ring bolted to the exterior of the roof. The placement location and quantity of roof ring kits vary with the size of each bin. The roof support ring (A) on the 36 ft bin will be installed in the fourth (4 ) roof panel rib hole from the eave.
Page 103: Installing A Roof Ring
Chapter 8: Accessories Installing a Roof Ring Quantity and part numbers of roof ring kits vary with the location placement and with the size of each bin. The following procedure will be similar for each kit. What You Should Know The roof ring and threaded stud may become dislocated from each other during high winds or when the inside pressure of the bin is too great.
Page 104 Chapter 8: Accessories 5. Locate a threaded stud (F) and install stud nuts (G) evenly and to the center of the threaded stud (F). 6. Install the threaded stud (F) with stud nuts (G) to the end of the roof ring section (B). NOTE: Install the threaded stud (F) to the side where the next roof ring section will be installed.
Page 105: Installation Of Peak-To- Exhauster Ladder Kit
Chapter 8: Accessories Installation of Peak–To– Exhauster Ladder Kit Before installing the roof exhauster, the peak-to-exhauster ladder kit may be installed onto the roof to have access to the roof exhauster. Before You Begin Determine the location of the roof exhauster. What You Should Know This procedure is to install the peak to exhauster ladder kit onto the roof .
Page 106 Chapter 8: Accessories Table 8-2 Peak-to-Exhauster Ladder Rung Kit Bin Diameter Location 36 ft 42 ft 48 ft 54 ft 60 ft 66 ft LS-260–3 LS-260-4 ↑ Bin Peak LS-260-2 LS-260-4 LS-260-5 LS-260-1 LS-260-3 LS-260-5 LS-260-6 LS-260-3 LS-260-5 LS-260-6 LS-260-7 LS-260-2 LS-260-4 LS-260-6...
Page 107: Preparation For Roof Exhauster Installation
Chapter 8: Accessories Preparation for Roof Exhauster Installation Before installing the roof exhauster, some preparation is required, utilizing the roof exhauster mounting plate and the roof panels that span the roof exhauster mounting plate. Before You Begin Determine the location of the roof exhauster and set aside the roof panels that the roof exhauster mount- ing plate will span.
Page 108 Chapter 8: Accessories 4. Bend the tabs (J) downward approximately 90 degrees on the roof exhauster mounting plate (F) to conform with the roof panel. NOTE: Bend the tabs on the ground and adjust as necessary once on the roof. 5.
Page 109: Assembly Of Roof Exhauster
Chapter 8: Accessories Assembly of Roof Exhauster Assembly of the roof exhauster is done prior to installing onto the roof. 1. Apply a strip of tube caulk (C) along the mating surface of the roof exhauster hood (B) and the exhauster mounting plate (E).
Page 110: Installing Roof Exhauster Assembly
Chapter 8: Accessories Installing Roof Exhauster Assembly The roof exhauster assembly replaces one of the roof flashing panels and allows for the roof exhauster to be installed. Before You Begin IMPORTANT: Determine the location of the roof exhauster and remove the existing roof flashing panel at this location.
Page 111 Chapter 8: Accessories Figure 8-9 Installing roof exhauster Roof exhauster flashing (CTR-0898) 5/16 flange nut (S-3611) 5/16 x 1 in. flange bolt with sealing washer Sealing caulk (S-10260) 5/16 x 1 in. flange bolt with sealing washer Sealing caulk (S-10260) Roof exhauster assembly 7.
Page 112 Chapter 8: Accessories Figure 8-10 Sealing caulk location Roof exhauster assembly Sealing caulk Pneg-4036-10 36 Ft Diameter Bin with 10K Roof...
Page 113: Installing The Conveyor Support Brackets (Optional)
Chapter 8: Accessories Installing the Conveyor Support Brackets (Optional) Four conveyor support brackets are attached to the roof flashing and center cap plate as an option, if cat- walk system has to be installed. 1. Locate the four sets of four holes in the center cap plate (B), place the gaskets (A) around the sets of four holes where the conveyor support brackets (C) will be installed.
Page 114: Installing The Manway Cover
Chapter 8: Accessories Installing the Manway Cover Installation of a manway cover is necessary if a manway hole is present. Round manway cover details for bins 60 ft. and smaller. 1. Apply caulking to the underside of the moisture diverter (N), and install to the manway roof panel (L).
Page 115 Chapter 8: Accessories Figure 8-12 Manway cover Hinge base (ACD-4506) 5/16 in. nut (S-3611) Hinge leaf (ACD-4505) Latch (ACD-4514) 5/16 x 1 in. flange bolt with sealing #10–24 lock nut (S-2010) washer (S-10260) #10–24 x 5/8 in. long bolt (S-2009) 5/16 x 1 in.
Page 116: Ladder Section Assembly
Chapter 8: Accessories Ladder Section Assembly The inside ladder package consists of the ladder, starter brackets, standoff brackets, reinforcement straps, and ending bracket. The ladder should to be assembled before installing it to the bin structure. What You Should Know When assembling ladder sections, ensure all slip resistant ladder rungs are oriented in the same direction.
Page 117: Inside Ladder Placement
Chapter 8: Accessories Inside Ladder Placement The inside ladder provides manway access from inside the bin. What You Should Know Begin by temporarily positioning the ladder (B) directly under the manway roof panel (A) for the correct placement location. Mark or scribe this location where each side of the ladder’s vertical channels meet the sidewall.
Page 118 Chapter 8: Accessories 5. Working down from the starter brackets (C and K), and in alignment, install a ladder standoff bracket (H) at every horizontal seam or 32 in. from the previous installed bracket. Install a flange bolt (D) and a flange nut (G), securing each ladder standoff bracket (H) to the sidewall. NOTE: Installing a plumb line to the starter bracket will help keep each bracket aligned evenly.
Page 119 Chapter 8: Accessories Figure 8-15 Installing ladder brackets Ladder assembly 5/16 x 1 in. flange bolt with sealing washer (S- 10260) Starter bracket (RH LDR-4347) Starter bracket (LH LDR-4346) See sidewall hardware chart. 3/8 in. field drilled hole location Approximately 18-3/4 in. (47.62 mm) 5/16 x 1 in.
Page 120: Installing Inside Ladder Bottom Bracket
Chapter 8: Accessories Installing Inside Ladder Bottom Bracket The ladder bottom bracket keeps the lower portion of the ladder secure. What You Should Know The lower portion of the ladder may need to be cut to fit properly. Field drilling will be required to complete installation.
Page 121: Guidelines For Installing A Sidedraw System
90 degrees apart. Installation of multiple systems requires approval of GSI. • Sidedraw systems are intended for use with dry, flowable grain. Sidedraws are not to be used for poorly flowing products. This is not unique to GSI bins and flume systems, but is a general rule for such systems.
Page 122 Chapter 8: Accessories Figure 8-17 Two and three post stiffener examples Typical 24-ring bin Two post stiffener Typical 29-ring bin Three post stiffener Sidewall sheet Standard height of discharge chute 16 ft. 4 in. (5 NOTE: Use the following tables as a guide or reference for the proper placement of the sidedraw system. Table 8-3 Sidewall Instructions (Two Post Stiffener) Number of Rings on the Bin Chute Location Horizontal Starting Location...
Page 123 Chapter 8: Accessories Table 8-3 Sidewall Instructions (Two Post Stiffener) (cont'd.) Number of Rings on the Bin Chute Location Horizontal Starting Location Top bolt holes in chute to be located on 2nd corrugation of body sheet. 11, 12, 15, 17, 19, 21, and 23 Center chute over vertical seam.
Page 124: Installing The Sidedraw Baffle Chute (Two Post Stiffener)
Chapter 8: Accessories Installing the Sidedraw Baffle Chute (Two Post Stiffener) The sidedraw baffle chute helps direct the bin contents to the discharge chute. 1. Determine the sidedraw system location, and ensure the installation of baffle chutes (C) will not interfere with stiffeners (A).
Page 125 Chapter 8: Accessories Figure 8-18 First Chute Locations (Two Post Stiffener Only) and Spacing of each baffle chute Field drilled hole location (7/16 in. diameter hole) Stiffener’s center line Second ring from top of bin 3/8 x 1-1/2 in. flange bolt (S-7488) 3/8 in.
Page 126: Installing The Sidedraw Baffle Chute (Three Post Stiffener)
Chapter 8: Accessories Installing the Sidedraw Baffle Chute (Three Post Stiffener) The Sidedraw baffle chute helps direct the bin contents to the discharge chute. 1. Determine the sidedraw system location, and ensure the installation of baffle chutes (C) will not interfere with stiffeners (A).
Page 127 Chapter 8: Accessories Figure 8-19 First chute locations (three post stiffener only), and spacing of each baffle chute Field drilled hole location (7/16 in. diameter hole) Stiffener’s center line Second ring from top of bin 3/8 x 1-1/2 in. flange bolt (S-7488) 3/8 in.
Page 128: Installing The Sidedraw Discharge Chute
Chapter 8: Accessories Installing the Sidedraw Discharge Chute The following instructions discribe the installation of the sidedraw discharge chute. What You Should Know Field cutting is required to create the opening for the discharge chute. Cutting the opening will require two sidewall panels to be modified.
Page 129 Chapter 8: Accessories 3. Measure approximately 4 in. (16.16 cm) upward from the sidewall horizontal seam (E), and place a mark or scribe, creating a horizontal center line (G). 4. Place another mark or scribe where the vertical center line (D) and the horizontal center line (G) meet, creating the center of the discharge chute location (F).
Page 130 Chapter 8: Accessories 7. Measure approximately 8-1/2 in. (21.59 cm) on each side of the horizontal center line (G), and place a mark or scribe. 8. Using these marks, create an outline of the discharge chute hole to be cut. 9.
Page 131 Chapter 8: Accessories NOTE: To ensure proper watershed, the discharge chute assembly (H) is installed behind the upper sidewall panel (I) and in front of the lower sidewall panel (J). Figure 8-23 Discharge chute assembly (view form inside the bin) Discharge chute assembly Lower sidewall panel Upper sidewall panel...
Page 132 Chapter 8: Accessories Figure 8-24 Field drilling discharge chute assembly (view from inside the bin) Discharge chute assembly 3/8 x 1-1/2 in. flange bolt (S-7488) Upper sidewall panel 3/8 in. hex nut (S-456) Lower sidewall panel 14.Place the baffle chute (B) into place and field drill necessary holes, securing with flange bolts and flange nuts.
Page 133 Chapter 8: Accessories Figure 8-25 Reinstall baffle chute (view from inside the bin) Baffle chute Field drilled hole location 15.Tighten hardware to the recommended torque specifications. See Bolt Torque Specifications, page Pneg-4036-10 36 Ft Diameter Bin with 10K Roof...
Page 134: Installing Wind Rings
Chapter 8: Accessories Installing Wind Rings Installation of wind rings is similar for a two and a three post bin design, although hardware quantities may vary. What You Should Know Before installing, determine the bin size, sidewall gauge thickness, and height. Use the hardware chart to match the correct bolt length with the correct sidewall gauge thickness when installing the wind ring brack- ets to the stiffeners (Refer to hardware requirements chapter).
Page 135 Chapter 8: Accessories 7. Slide the wind ring coupling collar (K), aligning the three pre-drilled holes, and install flange bolts (F) and hex nuts (G). Field drill the remaining three holes (L) using the wind ring coupling collar (K) as a guide or template.
Page 136: Assembling Weather Cover For Roller Valve
Chapter 8: Accessories Assembling Weather Cover for Roller Valve The following instructions are for assembling the weather cover for the roller valve. 1. Install the weather cover kit after the gate has been installed. 2. Use bead caulking at all seams where the weather cover attaches to the gate. 3.
Page 137: Gsi Group, Llc Limited Warranty
12 months from the date of shipment (or, if shipped by vessel, 14 months from the date of arrival at the port of discharge). If, in GSI’s sole judgment, a product is found to have a defect in materials and/or workmanship, GSI will, at its own option and expense, repair or replace the product or refund the purchase price.
