Page 1 78 Ft Diameter Bin Models: 2.66 IN. CORRUGATION 40–SERIES BIN Construction Manual PNEG-4078-O15 Version 1.2 Date: 12-18-20 PNEG-4078-O15...
Page 2 All information, illustrations, photos, and specifications in this manual are based on the latest information available at the time of publication. The right is reserved to make changes at any time without notice. Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 3: Table Of Contents
Table of Contents Contents Chapter 1 Safety Precautions ........................7 Safety Guidelines ........................7 Cautionary Symbols ........................9 Safety Decals..........................10 Safety Sign-off Sheet .........................13 Chapter 2 General Overview ........................15 General Information........................15 Anchor Bolt Charts ........................15 Tools Required for Construction....................17 Guidelines for Proper Storage of Grain Bin Materials Prior to Construction ........17 Overview for a Typical Bin Installation ..................18 Guidelines for Construction Procedures and Lifting Jack Usage ............19 Guidelines for Placement of the Decal Sidewall Sheet ..............20...
Page 4 Table of Contents Close-Punch Connection for a Two-Ring Top Stiffener to a Two-Ring Stiffener (16 Ga)....51 Two-Ring Stiffener (15-16 Ga) to a Two-Ring Stiffener (15–16 Ga) Connection .......51 Close-Punch Connection for a Two-Ring Stiffener (16 Ga) to a Two-Ring Stiffener (16 Ga) ....52 Two-Ring Stiffener (0–14 Ga) to a Two-Ring Stiffener (0–14 Ga) Connection ........52 Close-Punch Connection for a Two-Ring Stiffener (0–14 Ga) to a Two-Ring Stiffener (0–14 Ga) ..........................53...
Page 5 Installing the Sidedraw Baffle Chute (Three Post Stiffener)............147 Installing the Sidedraw Discharge Chute ................... 149 Wind Ring Requirements ......................156 Installing Wind Rings ....................... 158 Assembling Weather Cover for Roller Valve................160 GSI Group, LLC Limited Warranty..................161 Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 6 NOTES Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 7: Chapter 1 Safety Precautions
Safety Precautions Topics Covered in this Chapter ▪ Safety Guidelines ▪ Cautionary Symbols ▪ Safety Decals ▪ Safety Sign-off Sheet Safety Guidelines Safety guidelines are general-to-specific safety rules that must be respected at all times in the grain stor- age environment. Our foremost concern is your safety and the safety of others associated with grain handling equipment.
Page 8 Chapter 1: Safety Precautions Follow Safety Instructions — Read and Understand Manual • Carefully read all safety messages in this manual and safety signs on your machine. Keep signs in good condition. Replace missing or damaged safety signs. Be sure new equipment components and repair parts include the current safety signs.
Page 9: Cautionary Symbols
Chapter 1: Safety Precautions • Wear gloves to protect your hands from sharp edges on Gloves plastic or steel parts. • Wear steel-toed boots to help protect your feet from falling Steel-Toed Boots debris. Tuck in any loose or dangling shoestrings. •...
Page 10: Safety Decals
Chapter 1: Safety Precautions Table 1-1 Description of the different cautionary symbols (cont'd.) Symbol Description This symbol indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. This symbol indicates a potentially hazardous situation which, if not avoided, may result in property damage.
Page 11 (61 cm) porthole door cover and the roof manway cover. If a decal has been damaged or is missing in any of these locations, contact the manufacturer for a free replacement decal. GSI Decals 1004 E. Illinois Street Assumption, IL 62510 Phone: 1–217–226–4421...
Page 12 (61 cm) porthole door cover and the roof manway cover. If a decal has been damaged or is missing in any of these locations, contact the manufacturer for a free replacement decal. GSI Decals 1004 E. Illinois Street Assumption, IL 62510 Phone: 1–217–226–4421...
Page 13: Safety Sign-Off Sheet
Chapter 1: Safety Precautions Safety Sign-off Sheet Sign-off sheet verifying that all personnel have read and understood the safety instructions. As a requirement of O.S.H.A., it is necessary for the employer to train the employee in the safe operating and safety procedures for this equipment. This sign-off sheet is provided for your convenience and per- sonal record keeping.
Page 14 NOTES Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 15: Chapter 2 General Overview
These include, but may not be limited to: • A stiffener and sidewall gauge layout chart. If such a chart is not included with this manual, contact GSI. • Roof instructions must be followed. Roof instructions are included in this manual.
Page 16 Chapter 2: General Overview Figure 2-1 Anchor bolt chords for 78 diameter 3–post bin Bolt Radius (B) Anchor Quantity ft and in 39 – 2-5/16 11.946 Length Length Chord (A) Chord (A) ft and in ft and in 33 – 7-1/4 10.243 3 –...
Page 17: Tools Required For Construction
Chapter 2: General Overview Tools Required for Construction General tools needed to perform this construction: • Combination wrench set 7/16 in. to 1 in. • Alignment punches 12 in. long • 1/2 in. Drive socket set and ratchet • Nail aprons or tool pouches to hold supplies •...
Page 18: Overview For A Typical Bin Installation
Chapter 2: General Overview Overview for a Typical Bin Installation These are the typical steps one would perform when constructing a grain bin. Procedures may vary depending on the different site requirements. Pre-Assembly Activities • Sorting and grouping parts • Assemble A-frames •...
Page 19: Guidelines For Construction Procedures And Lifting Jack Usage
12.At the completion of the tank, set stiffeners over the anchor bolts and measure the tank to ensure it is in a round condition. Consult with GSI for questions on tolerances. NOTE: For 2 ring doors or vehicle traffic doors, special placement issues may apply. Consult the special instructions provided with two ring doors or vehicle traffic doors for these options.
Page 20: Guidelines For Placement Of The Decal Sidewall Sheet
Chapter 2: General Overview Guidelines for Placement of the Decal Sidewall Sheet Use the following as a general guideline for the proper placement of the decal sheet. NOTE: Refer to the stiffener to sidewall attachment detail and specific gauge sheet for the bin. The decal sheets are located in the third ring from the top.
Page 21 Chapter 2: General Overview Figure 2-3 Sample Gauge Sheet for a 3-Post 78 Diameter Bin Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 22 Chapter 2: General Overview All information, illustrations, photos, and specifications in this manual are based on the latest information available at the time of publication. The right is reserved to make changes at any time without notice. Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 23: Chapter 3 Hardware Requirements
Hardware Requirements Topics Covered in this Chapter ▪ Bolt and Nut Pairings ▪ Hardware for 3–Post Sidewall Sheets on bins that are 18 to 90 Ft in Diameter and 105 Ft Bins that are 27 Rings and Shorter ▪ Bolt Torque Specifications ▪...
Page 24 Chapter 3: Hardware Requirements Table 3-1 Hardware for 3-Post Sidewall Sheets on 18 to 90 ft. bins and 105 ft Diameter Bins that are 27 Rings and shorter (cont'd.) Horizontal Seam Vertical Seam Bolt Stiffener to Sidewall Overlap Seam Bolt Gauge Bolt Size (Quantity) Size (Quantity)
Page 25: Bolt Torque Specifications
CAUTION Grade 2 Bolts Grade 2 bolts are designated with a plain head and are not used in GSI grain bins. Grade 5 Bolts Grade 5 bolts are designated by three slash marks on the head. All 5/16 inch diameter bolts are to be grade 5 or higher.
Page 26: Color Chart For Bin Hardware Bucket Lids
Chapter 3: Hardware Requirements Color Chart for Bin Hardware Bucket Lids For ease of identification, hardware is separated and identified by buckets with color coded lids. Use the following chart to help identify the correct hardware. JS Part YDP Part Bucket Description Color...
Page 27: Bolt Identification
Chapter 3: Hardware Requirements Bolt Identification Use the following information to identify the bolts and where each must be used during installation. Bolt S-275 An S–275 is a 5/16 x 3/4 in. YDP bolt that is pre-assembled with a sealing washer. Bolt (S-275) is used in the following locations: •...
Page 28: Bolt S-7485
Chapter 3: Hardware Requirements Bolt S-7485 An S–7485 is a 3/8 x 1 in. JS hex bolt with flanged head and without a sealing washer. Bolt (S-7485) is used in the following locations: • Use to splice the stiffeners together on the flanges. (A flange nut is used on the nut side of the connection.) •...
Page 29: Bolt S-7488
Chapter 3: Hardware Requirements Bolt S-7488 An S–7488 is a 3/8 x 1-1/2 in. JS bolt that is pre-assembled with a sealing washer. Bolt (S-7488) is used in the following locations: • Use in all stiffener to sidewall and overlap connections where the sidewall is 9 gauge or thicker.
Page 30: Bolt S-10261
Chapter 3: Hardware Requirements Bolt S-10261 An S–10261 is a 7/16 x 3-1/4 in. JS bolt that is pre-assembled with a sealing washer. Bolt (S-10261) is used in the following locations: • Use in wind ring splice and over pipe connections. •...
Page 31: Chapter 4 Assembling Sidewall Sheets
Assembling Sidewall Sheets Topics Covered in this Chapter ▪ Color Codes for Sidewall Gauge Identification ▪ Orientation Detail for Top Sidewall Sheets ▪ Caulking Detail for Standard (Non-Laminated) Sheets ▪ Caulking Detail for Laminated Quad Pattern Sheets Color Codes for Sidewall Gauge Identification Use this chart to interpret the color code painted on the corners of the sidewall sheets.
Page 32: Caulking Detail For Standard (Non-Laminated) Sheets
Chapter 4: Assembling Sidewall Sheets Figure 4-1 3–Post top sidewall sheet orientation Top of the top sidewall sheet Bottom of the top sidewall sheet Caulking Detail for Standard (Non-Laminated) Sheets To keep out moisture from overlapping the sheets, apply caulk to each sidewall sheet prior to installion. NOTE: Always assemble the sidewall sheets with the overlap in the same direction.
Page 33 Chapter 4: Assembling Sidewall Sheets Figure 4-2 Standard and quad punched sidewall sheets as viewed from the outside Vertical strip of caulk 10 in. (25.4 cm) Horizontal strip of caulk • Before bolting the next ring into place, apply one 10 in. strip of caulk (C) on the front of the under- lapped sheet at each joint.
Page 34 Chapter 4: Assembling Sidewall Sheets Figure 4-3 Caulking detail as viewed from inside of the bin 10 in. (25.4 cm) Strip of caulk 10 in. (25.4 cm) Strip of caulk • Use the supplied tube caulk to fill the larger gaps that occur with heavier gauges and laminated gauges.
Page 35: Caulking Detail For Laminated Quad Pattern Sheets
Chapter 4: Assembling Sidewall Sheets Caulking Detail for Laminated Quad Pattern Sheets To keep out moisture from overlapping the sheets, it is necessary to apply caulk to each sheet prior to installing. Caulking and Assembling the Individual Sidewall Sheets Each sidewall sheet must be layered and caulked prior to assembling sidewall sheet seams together. Figure 4-4 Laminated quad punched sidewall panel view from outside of the bin Strip of caulking 12 in.
Page 36 Chapter 4: Assembling Sidewall Sheets • When assembling two assembled laminated sheets to each other, apply a strip of caulk (A) near the outside edge of the outer sheet, between the outer two (2) rows of bolts and outside the last row of bolts.
Page 37: Chapter 5 Base Angle Installation
Base Angle Installation Topics Covered in this Chapter ▪ Installing the Base Angle ▪ Anchor Bolt Detail ▪ Installing the Base Angle Shims ▪ Anchor Bolt Washer Installation Installing the Base Angle Installing the base angle ring will help reinforce and seal the final ring. What You Should Know The base angle overlap should be offset two holes from the stiffener.
Page 38 Chapter 5: Base Angle Installation Figure 5-1 Exploded view of base angle (view from the inside of the bin) Final ring assembly 3/8 in. nut (S-9426) Base angle (B-6753) Base angle offset example 3/8 x 1 in. bolt (S-7487) Optional mastic sealer (or equivalent) Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 39: Anchor Bolt Detail
Chapter 5: Base Angle Installation Anchor Bolt Detail The following is the minimum requirement for anchoring a standard bin. Refer to sidedraw instructions for special anchoring details. • 3/4 in. diameter anchor bolt (A) is the minimum allowed • Exposed anchor bolt thread height (B), 3 in. (7.62 cm) •...
Page 40: Installing The Base Angle Shims
Chapter 5: Base Angle Installation Installing the Base Angle Shims A section of the base boot plate will rest on top of the base angle, therefore causing the base boot to rest unevenly on the foundation. To offset this, base angle shims are required to ensure the base boot sets evenly on the foundation.
Page 41: Anchor Bolt Washer Installation
Chapter 5: Base Angle Installation Anchor Bolt Washer Installation Anchor bolt washers help to cover the oversized hole in the base plate. Before You Begin Anchor bolts are secured, and base plates installed. 1. Place a square plate washer (B) onto the anchor bolt (A). NOTE: A square plate washer (provided) must be installed between the base boot (C) and washer (D).
Page 42 NOTES Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 43: Chapter 6 Stiffeners
Stiffeners Topics Covered in this Chapter ▪ Stiffener Part Number Description ▪ Color Codes for Stiffener Gauge Identification ▪ Standard Stiffeners ▪ Top Stiffeners ▪ Stiffeners Splice ▪ Base Stiffeners ▪ Base Boots ▪ Close-Punch Connection for a One-Ring Top Stiffener (16 Ga) and a Two-Ring Stiffener (16 ▪...
Page 44: Stiffener Part Number Description
Chapter 6: Stiffeners Stiffener Part Number Description Part numbers are printed on the end of each stiffener with the last two numbers designating the gauge of the material. Example: CTS-206314 will be printed on a 14 gauge, standard two-ring stiffener. If the stiffener was 8 gauge, it would change the part number to CTS-206308.
Page 45: Standard Stiffeners
Chapter 6: Stiffeners Standard Stiffeners Use the following information to determine the differences between the types of standard two-ring stiffeners. Figure 6-1 Standard stiffeners Call Part Number Description Length Available Gauges CTS-2063XX Two-ring stiffener 63.938 in. (162 cm) 10 – 14 CTS-2064XX Two-ring stiffener 63.938 in.
Page 46: Top Stiffeners
Chapter 6: Stiffeners Top Stiffeners Use the following information to determine the differences between the types of top stiffeners. Figure 6-2 Images of the top stiffeners Call Part Number Description Length Available Gauges CTS-2069XX Inside stiffener (for roof) 23.938 in. (56 cm) 2 –...
Page 47: Stiffeners Splice
Chapter 6: Stiffeners Stiffeners Splice Use the following information to determine the gauge of the stiffener splice needed to connect the stiffeners. Figure 6-3 Stiffener splice Call Out Part Number Description Length Available Gauges CTS–2091XX Stiffener splice 10 in. (25.4 cm) 8, 10, 12, 14 Use the following chart to determine the gauge of the splice, which is determined by the gauge of the stiff- eners that are being connected.
Page 48: Base Stiffeners
Chapter 6: Stiffeners Base Stiffeners Use the following information to determine the differences between the base stiffeners. Figure 6-4 Images of the base stiffeners Call Out Part Number Description Length Available Gauges CTS–2119XX Base stiffener 72.094 in. (183 cm) 2 – 8 CTS-2123XX Base stiffener 72.430 in.
Page 49: Base Boots
Chapter 6: Stiffeners Base Boots Use the following information to determine the differences between the base boots. Figure 6-5 Images of the base boots Call Out Part Number Description Height Base Plate Size CTS–2121XX Base boot weldment for 16 11.391 in. 6 x 9 x 3/8 in.
Page 50: Close-Punch Connection For A One-Ring Top Stiffener (16 Ga) And A Two-Ring Stiffener (16 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a One-Ring Top Stiffener (16 Ga) and a Two-Ring Stiffener (16 Ga) Reference the following information for a close-punch connection of a one-ring top stiffener (CTS-2118XX) to a two-ring stiffener (CTS-2075XX). Figure 6-6 One-Ring Top Stiffener (16 Ga) and a Two-Ring Stiffener (16 Ga) Close-Punch Connection One-ring top stiffener (CTS-2118XX) Two-ring stiffener (CTS-2075XX) Splice (CTS-2091XX)
Page 51: Close-Punch Connection For A Two-Ring Top Stiffener To A Two-Ring Stiffener (16 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Top Stiffener to a Two-Ring Stiffener (16 Ga) Reference the following information for a close-punch connection of a two-ring top stiffener (CTS-2116XX) to a two-ring stiffener (CTS-2075XX). Figure 6-8 Two-Ring Top Stiffener to a Two-Ring Stiffener (16 Ga) Close-Punch Connection Two-ring top stiffener (CTS-2116XX) Two-ring stiffener (CTS-2075XX) Splice (CTS-2091XX)
Page 52: Close-Punch Connection For A Two-Ring Stiffener (16 Ga) To A Two-Ring Stiffener (16 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Stiffener (16 Ga) to a Two-Ring Stiffener (16 Ga) Reference the following information for a close-punch connection of a two-ring stiffener (CTS-2075XX) to a two-ring stiffener (CTS-2075XX). Figure 6-10 Two-Ring Stiffener (16 Ga) to a Two-Ring Stiffener (16 Ga) Close-Punch Connection Two-ring stiffener (CTS-2075XX) Two-ring stiffener (CTS-2075XX) Splice (CTS-2091XX)
Page 53: Close-Punch Connection For A Two-Ring Stiffener (0-14 Ga) To A Two-Ring Stiffener (0-14 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Stiffener (0–14 Ga) to a Two-Ring Stiffener (0–14 Ga) Reference the following information for a close-punch connection of a two-ring stiffener (CTS-2073XX) to a two-ring stiffener (CTS-2073XX). Figure 6-12 Two-Ring Stiffener (0–14 Ga) to a Two-Ring Stiffener (0–14 Ga) Close-Punch Connection Two-ring stiffener (CTS-2073XX) Two-ring stiffener (CTS-2073XX) Splice (CTS-2091XX)
Page 54: Close-Punch Connection For A Two-Ring Stiffener (0-14 Ga) To A Base Stiffener (2-8 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Stiffener (0–14 Ga) to a Base Stiffener (2–8 Ga) Reference the following information when connecting a two-ring stiffener (CTS-2073XX) to a base stiffener (CTS-2119XX). Figure 6-14 Two-Ring Stiffener (0–14 Ga) to a Two-Ring Stiffener (2–8 Ga) Close-Punch Connection Close-punch two-ring stiffener (CTS-2073XX) Close-punch base stiffener (CTS-2119XX) Splice (CTS-2091XX)
Page 55: Two-Ring Stiffener (2-14 Ga) To A Base Stiffener (10-16 Ga) Connection
Chapter 6: Stiffeners Two-Ring Stiffener (2–14 Ga) to a Base Stiffener (10–16 Ga) Connection Reference the following information for a close-punch connection of a two-ring stiffener (CTS-2073XX) to a base stiffener (CTS-2115XX). Figure 6-16 Two-Ring Stiffener (2–14 Ga) to a Base Stiffener (10–16 Ga) Close-Punch Connection Close-punch two-ring stiffener (CTS-2073XX) Close-punch base stiffener (CTS-2115XX) Splice (CTS-2091XX)
Page 56: Close-Punch Connection For A Two-Ring Stiffener (16 Ga) To A Base Stiffener (10-16 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Stiffener (16 Ga) to a Base Stiffener (10–16 Ga) Reference the following information for a close-punch connection of a two-ring stiffener (CTS-2075XX) to a base stiffener (CTS-2115XX). Figure 6-18 Two-Ring Stiffener (16 Ga) to a Base Stiffener (10–16 Ga) Close-Punch Connection Close-punch two-ring stiffener (CTS-2075XX) Close-punch base stiffener (CTS-2115XX)
Page 57: Close-Punch Two-Ring Stiffener (2-14 Ga) To A Laminated Stiffener (2 Ga) With An Insert (10-14 Ga)
Chapter 6: Stiffeners Close-Punch Two-Ring Stiffener (2–14 Ga) to a Laminated Stiffener (2 Ga) with an Insert (10–14 Ga) Reference the following information for a close-punch connection with a two-ring stiffener (CTS-2073XX) to a laminated stiffener (CTS-2114XX) and insert (CTS-2113XX). Figure 6-19 Close-Punch Two-Ring Stiffener to a Laminated Stiffener with an Insert Close-punch two-ring stiffener (CTS-2073XX) Close-punch laminated stiffener...
Page 58: Close-Punch Laminated Stiffener (2 Ga) With An Insert (10-14 Ga) To A Laminated Base Stiffener (2-5 Ga) With A Base Insert (2-14 Ga)
Chapter 6: Stiffeners Close-Punch Laminated Stiffener (2 Ga) with an Insert (10–14 Ga) to a Laminated Base Stiffener (2–5 Ga) with a Base Insert (2–14 Ga) Reference the following information for a close-punch connection of a two-ring stiffener (CTS-2079XX and CTS-2081XX) to a laminated base stiffener and insert (CTS-2114XX and CTS-2113XX).
Page 59: Base Stiffener (10-16 Ga) To A Base Boot Connection
Chapter 6: Stiffeners Base Stiffener (10–16 Ga) to a Base Boot Connection Reference the following information when connecting a base stiffener (CTS-2123XX) to a base boot (CTS- 2121XX). Figure 6-22 Base Stiffener (10–16 Ga) to a Base Boot Connection Base stiffener (CTS-2123XX) Base boot (CTS-2121XX) 3/8 x 1 Bolt (S-7485) 3/8 Nut (S-9426)
Page 60: Close-Punch Connection For A Base Stiffener (2+2 Ga - 8 Ga) To A Base Boot
Chapter 6: Stiffeners Close-Punch Connection for a Base Stiffener (2+2 Ga – 8 Ga) to a Base Boot Reference the following information for a close-punch connection for a base stiffener (CTS-2119XX) to a base boot (CTS-2110XX). Figure 6-24 Base Stiffener (2+2 Ga – 8 Ga) to a Base Boot Close-Punch Connection Close-punch base stiffener (CTS-2119XX) Close-punch base Boot (CTS-2110XX) 3/8 x 1 Bolt (S-7485)
Page 61: Close-Punch Laminated Base Stiffener (2 Ga) With Insert (2+14 To 2+10 Ga) To A Base Boot
Chapter 6: Stiffeners Close-Punch Laminated Base Stiffener (2 Ga) with Insert (2+14 to 2+10 Ga) to a Base Boot Reference the following information when connecting a close-punch laminated base stiffener (CTS-2114XX) to a base boot (CTS-2109XX or CTS-2110XX). Figure 6-25 Close-Punch Laminated Base Stiffener to a Base Boot Close-punch laminated base stiffener (CTS- 2114XX) Close-punch base Insert (CTS-2113XX)
Page 62: 12-Bolt Pattern Close-Punch Laminated Stiffeners With Insert
Chapter 6: Stiffeners 12–Bolt Pattern Close-Punch Laminated Stiffeners with Insert Reference the following information for a close-punch connection of two 12–bolt pattern laminated stiff- eners (CTS-2137XX) with an inserts (CTS-2138XX). Figure 6-27 Close-Punch 12–Bolt Pattern Laminated Stiffeners with Insert Close-punch laminated stiffener (CTS-2137XX) Close-punch Insert (CTS-2138XX) 3/8 x 1 Bolt (S-7485) 3/8 Nut (S-9426)
Page 63: Close-Punch 12-Bolt Pattern Laminated Stiffener To Laminated Base Stiffener With An Inserts To A Base Boot
Chapter 6: Stiffeners Close-Punch 12–Bolt Pattern Laminated Stiffener to Laminated Base Stiffener with an Inserts to a Base Boot Reference the following information for a close-punch connection of a 12–bolt pattern laminated stiffener (CTS-2137) to a laminated base stiffener (CTS-2135XX) with a inserts (CTS-2138XX and CTS-2135XX) to a base boot (CTS-2131XX).
Page 64: Close-Punch 12-Bolt Pattern Laminated Stiffener To Laminated Base Stiffener With An Inserts To A Base Boot
Chapter 6: Stiffeners Close-Punch 12–Bolt Pattern Laminated Stiffener to Laminated Base Stiffener with an Inserts to a Base Boot Reference the following information for a close-punch connection of a 12–bolt pattern laminated stiffener (CTS-2137) to a laminated base stiffener (CTS-2133XX) with a inserts (CTS-2138XX and CTS-2134XX) to a base boot (CTS-2109XX or CTS-2110XX).
Page 65 Chapter 6: Stiffeners Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 66 NOTES Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 67: Chapter 7 Roof Assembly
Roof Assembly Topics Covered in this Chapter ▪ Attaching the Inside Stiffener to the Top Outside Stiffener ▪ Attaching the Eave Bracket to the Inside Stiffener ▪ Attaching the Eave Angle to the Sidewall Sheet ▪ Connecting the Tension Member to the Eave Bracket ▪...
Page 68 Chapter 7: Roof Assembly NOTE: Install the bolts from the inside to the outside of the bin, passing through the inside stiffener, corrugation spacer, sealing washer, sidewall sheet, and outside stiffener and flange nut. 2. On the inside perimeter, install a sealing washer (F), corrugation spacer (E), and inside stiffener (D). 3.
Page 69 Chapter 7: Roof Assembly Figure 7-2 Inside stiffener to the two-ring top stiffener for bins with an even number of rings Sidewall Corrugation spacer (S-7041) 3/8 x 1-1/2 in. flange bolt (S-7488) Sealing washer (S-3558) 3/8 in. flange nut (S-9426) Two-ring top stiffener (CTS-2111XX or CTS- 2116XX) Inside stiffener (CTS-2069XX)
Page 70: Attaching The Eave Bracket To The Inside Stiffener
Chapter 7: Roof Assembly Attaching the Eave Bracket to the Inside Stiffener Eave brackets secure the roof rafter to the sidewall. Before You Begin Install the inside stiffeners to the sidewalls before proceeding. 1. Attach the eave bracket (A) to the inside stiffener (C) and install flange bolts (D). 2.
Page 71: Attaching The Eave Angle To The Sidewall Sheet
Chapter 7: Roof Assembly Attaching the Eave Angle to the Sidewall Sheet The eave angle secures each lower portion of the roof panels. What You Should Know Eave angles are bolted to the inside portion of the sidewall and will overlap each section. 1.
Page 72 Chapter 7: Roof Assembly Figure 7-4 Exploded view of eave angle (four roof panels) First eave angle (CTR-0187) Eave bracket (CTR-0429) 5/16 in. flange nut (S-3611) Outside top stiffener Second eave angle (CTR-0187) Inside stiffener (CTS-2069XX) 5/16 x 1 in. flange bolt (S-10260) Top of the top sidewall sheet Upper sidewall Bottom of the top sidewall sheet...
Page 73: Connecting The Tension Member To The Eave Bracket
Chapter 7: Roof Assembly Connecting the Tension Member to the Eave Bracket Tension members connect to the eave brackets and are installed around the inside of the bin eave. Before You Begin Ensure all eave angles, inside stiffeners and eave brackets are installed before proceeding. What You Should Know IMPORTANT: Install bolts as shown, from the backside of the eave bracket.
Page 74: Attaching The Center Collar Rafter Clips To The Rafter
Chapter 7: Roof Assembly Attaching the Center Collar Rafter Clips to the Rafter Center collar rafter clips secure the A-frame rafter sections to the center collar. What You Should Know Each roof rafter receives two center collar rafter clips, identified as the left center collar rafter clip (D) and the right center collar rafter clip (E).
Page 75: About Temperature Cable Brackets And A-Frame Assemblies
GSI is not responsible for the effectiveness or performance of any tem- perature cable monitoring system or layout.
Page 76 Chapter 7: Roof Assembly Figure 7-7 A-frame installation sequence and temperature cable locations for 78 ft diameter bin 5 ft radius location (center collar) 28.6 ft radius location 14 ft radius location Table 7-1 A-frame installation sequence and temperature cable locations for 78 ft diameter bin Temp Cable Number A-frame number Rafter Number...
Page 77: Assembling The Temperature Cable Bracket
Chapter 7: Roof Assembly Table 7-1 A-frame installation sequence and temperature cable locations for 78 ft diameter bin (cont'd.) Temp Cable Number A-frame number Rafter Number Radius Location — — — — 14 ft 28.6 ft — — 28.6 ft 28.6 ft —...
Page 78 Chapter 7: Roof Assembly There are two different temperature cable brackets used (CTR-0013 and CTR-0973). For purlin location 2, use temperature cable bracket (CTR-0973) with four hole connection to the rafter. For purlin location 4, use temperature cable bracket (CTR-0013) with three hole rafter connection. NOTE: The temperature cable bracket must be installed at specific locations, see About Temperature Cable Brackets and A-Frame Assemblies, page...
Page 79 Chapter 7: Roof Assembly Figure 7-9 Supplier quick link Purlin Supplier quick link Temperature cable bracket (CTR-0013) 4. Locate the center collar temperature cable hole (D), and install a supplier quick link (C), allowing for the installation of a temperature cable at this location. Figure 7-10 Supplier quick link on the center collar (view from bottom side of center collar) Supplier quick link Center collar temperature cable hole...
Page 80: Attachment Locations Of Purlins To Rafters
Chapter 7: Roof Assembly Attachment Locations of Purlins to Rafters Purlins are horizontal members between the rafters that give support to the roof structure. The length of the purlin determines its location on the A-frame assembly. The following reference depicts a completely assembled A-frame roof rafter section with X-bracing installed.
Page 81: Assembling Purlin Number 4
Chapter 7: Roof Assembly Assembling Purlin Number 4 Purlin number 4 is located at the top of the roof rafters nearest to the center collar rafter clips. Before You Begin Place two roof rafters on the ground with roof panel holes facing up. NOTE: Temperature cables may also be installed at this location, to determine if temperature cable brack- ets will be needed, see About Temperature Cable Brackets and A-Frame Assemblies, page...
Page 82 Chapter 7: Roof Assembly Figure 7-12 Purlin location 4 Left-hand roof rafter (CTR-0909) 1/2 x 1-3/4 in. flange bolt (S-10252) 1/2 x 1-3/4 in. flange bolt (S-10252) 1/2 in. flange nut (S-10253) Right-hand roof rafter (CTR-0909) Purlin (CTR-0254) Right purlin clip (CTR-0100) 1/2 in.
Page 83: Assembling Purlin Number 3
Chapter 7: Roof Assembly Assembling Purlin Number 3 Purlin number 3 is located third from the bottom of the rafters. Before You Begin Place two roof rafters on the ground with roof panel holes facing up. Several A-frame assemblies will have X-bracing installed and be placed periodically throughout the perimeter of the roof.
Page 84 Chapter 7: Roof Assembly Figure 7-13 Purlin location 3 Left-hand roof rafter (CTR-0909) Purlin (CTR-1066) 1/2 x 1-3/4 in. flange bolt (S-10252) 1/2 in. flange nut (S-10253) Right-hand roof rafter (CTR-0909) Top X-brace (CTR-0260) Right purlin clip (CTR-0100) Bottom X-brace (CTR-0260) Left purlin clip (CTR-0099) 1/2 x 1-3/4 in.
Page 85: Assembling Purlin Number 2
Chapter 7: Roof Assembly Assembling Purlin Number 2 Purlin number 2 is located second from the bottom of the rafters. Before You Begin Place two roof rafters on the ground with roof panel holes facing up. Several A-frame assemblies will have X-bracing installed and be placed periodically throughout the perimeter of the roof.
Page 86 Chapter 7: Roof Assembly Figure 7-14 Purlin location 2 Left-hand roof rafter (CTR-0909) Purlin (CTR-1065) 1/2 x 1-3/4 in. flange bolt (S-10252) 1/2 in. flange nut (S-10253) Right-hand roof rafter (CTR-0909) Top X-brace (CTR-0259) Right purlin clip (CTR-0950) Bottom X-brace (CTR-0259) Left purlin clip (CTR-0876) 1/2 x 1-3/4 in.
Page 87: Assembling Purlin Number 1
Chapter 7: Roof Assembly Assembling Purlin Number 1 Purlin number 1 is located closest to the bottom of the rafter. Before You Begin Place two roof rafters on the ground with roof panel holes facing up. Several A-frame assemblies will have X-bracing installed and be placed periodically throughout the perimeter of the roof.
Page 88 Chapter 7: Roof Assembly Figure 7-15 Purlin location 1 Left-hand roof rafter (CTR-0909) Purlin (CTR-1064) 1/2 x 1-3/4 in. flange bolt (S-10252) 1/2 in. flange nut (S-10253) Right-hand roof rafter (CTR-0909) Top X-brace (CTR-0258) Right purlin clip (CTR-0100) Bottom X-brace (CTR-0258) Left purlin clip (CTR-0099) 1/2 x 1-3/4 in.
Page 89: Assembling The Center Collar
Chapter 7: Roof Assembly Assembling the Center Collar The center collar assembles each A-frame roof rafter section together at the top. The center collar assem- bly is a two piece design and will need to be spliced together with splice plates. The center collar channels and the cap plates will also be assembled to the center collar on the ground to make sure all the parts align together.
Page 90 Chapter 7: Roof Assembly 4. Locate the column of three holes (J) that are not paired together on the inside radius of the center collar (A) and install the center collar channel clips (K) opposite to each other using the flange bolts (B) and the flange nuts (C).
Page 91 Chapter 7: Roof Assembly Figure 7-18 Assembling the short center collar channel with the center collar channel clip 1/2 x 1-3/4 in. flange bolt (S-10252) Short center collar channel (CTR-1040) 1/2 in. flange nut (S-10253) 1/2 in. bolt Center collar channel clip (CTR-0082) 1/2 in.
Page 92 Chapter 7: Roof Assembly Figure 7-19 Installing the long center collar channels to the center collar channels clips 1/2 x 1-3/4 in. flange bolt (S-10252) Center collar channel clip (CTR-0111) 1/2 in. flange nut (S-10253) Long center collar channel (CTR-1039) 9.
Page 93 Chapter 7: Roof Assembly Figure 7-20 Installing the short center collar channel assembly to the long center collar channel 1/2 x 1-3/4 in. flange bolt (S-10252) Short center collar channel (CTR-1040) 1/2 in. flange nut (S-10253) Long center collar channel (CTR-1039) 10.Install the remaining two assembled short channels (M) to the fourth set of holes located from each end of the short center collar channel (M) using the flange bolts (B) and the flange nuts (C).
Page 94 Chapter 7: Roof Assembly Figure 7-21 Installing the short center collar channel assembly to the short center collar channel 1/2 x 1-3/4 in. flange bolt (S-10252) Short center collar channel (CTR-1040) 1/2 in. flange nut (S-10253) Long center collar channel (CTR-1039) 11.Tighten all the hardware to the recommended torque specifications.
Page 95 16.Locate the holes in the cap plates and install four vendor eye bolts (W) for lifting. Eye bolts are NOT supplied by GSI. NOTE: Eyebolt will pass through multiple layers of steel: the cap plates, the long center collar chan- nels (N) and the center collar channel spacers (T).
Page 96 Chapter 7: Roof Assembly Figure 7-23 Cap plates assembly Side cap plate (CTR-1037), approximately 3/8 x 1 in. bolt with sealing washer (S-7487) 163.24 lb (74 kg) Bead of caulk 3/8 in. nut (S-456) Center cap plate (CTR-1038), approximately Eyebolt 314.72 lb (142.75 kg) 17.Make sure the holes in the cap plates are aligned with the holes in the center collar assembly.
Page 97: Center Collar Placement
Chapter 7: Roof Assembly 20.Use the appropriate lifting device and qualified personnel to lift the cap plates and the center collar channels as an assembly from the center collar assembly and keep it aside. 21.Remove the center collar and cap plates assembly (X) from the center collar assembly (Y) and keep it aside at a clean place.
Page 98 Chapter 7: Roof Assembly Figure 7-25 Center collar placement 291.531 in. (740.49 cm) from foundation to bottom of center collar on 78 ft diameter bin Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 99 Chapter 7: Roof Assembly IMPORTANT: The ladder assembly (A or B or C or D) and the manway hole (I or J or K or L) locations must be determined before the center collar is positioned. The relationship between the center collar channel clip (E), long center collar channel (F) and the cap plate (G) will dictate the orientation of the ladder assembly on top of the roof.
Page 100: Guidelines For Assembling And Lifting The A-Frame Rafter Sections
Chapter 7: Roof Assembly Guidelines for Assembling and Lifting the A-Frame Rafter Sections The roof is assembled in sections and referred to as A-frame rafter sections. Each A-frame rafter section is assembled on the ground and lifted into place. IMPORTANT: Do not drill additional holes in purlins. Install the flange bolts and nuts as dictated by the number of holes in the purlin.
Page 101: Attaching The A-Frames To The Center Collar
Chapter 7: Roof Assembly • Always practice safety when assembling rafter sections. Be aware of others around you when moving long A-frame sections. • Use evenly distributed connection points of support when lifting. • Before attempting a lift, adjust each lifting cable to achieve the appropriate angle needed (approxi- mately 30 degrees).
Page 102: Attaching The A-Frame To The Eave Bracket
Chapter 7: Roof Assembly Figure 7-28 Exploded view of A-frame to center collar A-frame rafter assembly 1/2 x 1-3/4 in. flange bolt (S-10252) Center collar (CTR-1092) 1/2 in. flange nut (S-10253) Attaching the A-Frame to the Eave Bracket Assemble the lower portion of the A-frame rafters to the sidewalls. 1.
Page 103: Assembling The Roof Panel Clips
Chapter 7: Roof Assembly Figure 7-29 Attaching the rafter to the eave bracket A-frame rafter assembly 1/2 in. flange nut (S-10253) 1/2 x 1-3/4 in. flange bolt (S-10252) Hole for alignment tool Eave bracket (CTR-0429) After You Finish Continue to the next A-frame installation until all of the A-frame rafter assemblies are installed. See About Temperature Cable Brackets and A-Frame Assemblies, page Assembling the Roof Panel Clips...
Page 104: Installing The Intermediate Purlins
Chapter 7: Roof Assembly NOTE: Ensure that the orientation of the roof panel clip is correct, roof panel holes facing the roof and the notch in the roof panel clip is facing the right-hand roof rafter. 3. Tighten all hardware to the recommended torque specifications only after the roof panels are installed.
Page 105: Attaching The Roof Panels
Chapter 7: Roof Assembly Figure 7-31 Exploded view of a 6–hole intermediate purlin Purlin Left purlin clip Right purlin clip A-frame roof assembly 1/2 x 1-3/4 in. flange bolt (S-10252) 1/2 in. flange nut (S-10253) NOTE: Purlin part numbers will vary with location. After You Finish Repeat this procedure for all the remaining intermediate purlins of the roof assembly.
Page 106 Chapter 7: Roof Assembly Figure 7-32 Roof panel overview Lower roof panel (CTR-0268) Upper roof panel (CTR-0267) Exposed gap 1. With assistance, position a lower roof panel (A) onto the first rafter in any A-frame. 2. Install five flange bolts (D) and five flange nuts (E) into the lower portion of the lower roof panel secur- ing the lower roof panel to the eave angle.
Page 107 Chapter 7: Roof Assembly Figure 7-33 Installing the lower roof panels Lower roof panel (CTR-0268) 5/16 in. flange nut (S-3611) 5/16-18 x 1 flange bolt with sealing washer (S-10260) 5. After installing the two lower roof panels onto the A-frame rafters, with assistance, position an upper roof panel (C) onto a A-frame rafter (F).
Page 108 Chapter 7: Roof Assembly Figure 7-34 Installing the upper roof panels Exposed gap 5/16 in. flange nut (S-3611) Upper roof panel (CTR-0267) A-frame roof rafter 5/16-18 x 1 flange bolt with sealing washer (S-10260) 9. When the initial two lower panels and two upper panels are installed, fill in the exposed gaps, by installing three additional lower roof panels (A) (as shown) overlapping each lower roof panel on the right, adjusting the lower roof panels as needed.
Page 109 Chapter 7: Roof Assembly Figure 7-35 Installing the roof panels into exposed gaps Lower roof panel (CTR-0268) 5/16-18 x 1 flange bolt with sealing washer (S- 10260) Exposed gap 5/16 in. flange nut (S-3611) 11.When the lower panels are installed, fill in the exposed gaps between the upper panels, by installing three additional upper roof panels (C) overlapping each upper roof panel on the right, adjusting the upper roof panels as needed.
Page 110 Chapter 7: Roof Assembly Figure 7-36 Securing the overlapping upper and lower panels Lower roof panel (CTR-0268) 5/16-18 x 1 flange bolt with sealing washer (S- 10260) Upper roof panel (CTR-0267) 5/16 in. flange nut (S-3611) 14.Working in a clockwise direction, repeat the procedure to continue installing all the lower roof panels and the upper roof panels onto the A-frames.
Page 111 Chapter 7: Roof Assembly Figure 7-37 Field drilling holes Roof panel (CTR-0267 and CTR-0268) Rafter Roof panel holes (drilled through purlin) Roof panel hole (for overlapping panels) Roof panel holes (drilled through rafter) Lower panel Purlin Upper panel Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 112: Installing The Roof Flashing
Chapter 7: Roof Assembly Installing the Roof Flashing The roof flashing will seal the area between the center collar and the roof panels. What You Should Know Each roof flashing section overlaps and bolts together with the previously installed roof flashing section. 1.
Page 113 Chapter 7: Roof Assembly NOTE: Remember to place caulk between the overlap of the last two panels. Figure 7-39 Installation of remaining roof flashing sections Roof flashing (CTR-1162) 5/16 in. flange nut (S-3611) 5/16-18 x 1 flange bolt with sealing washer Rope caulk (S-10260) After You Finish...
Page 114: Installing The Cap Plates Assembly
Chapter 7: Roof Assembly Installing the Cap Plates Assembly The following procedure is for installing the center collar channels and cap plates assembly onto the center collar in the roof. Before You Begin Determine the appropriate lifting chains and lifting device for lifting the center collar channels and cap plates assembly as a unit.
Page 115 Chapter 7: Roof Assembly Figure 7-40 Lifting the center collar channel and cap plates assembly Tube caulk (S-10319) Cap plate assembly, approximately 930 lb (422 Appropriate lifting chains 1/2 x 1-3/4 in. flange bolt (S-10252) Appropriate lifting device 1/2 in. nut (S-10253) 8.
Page 116: Installing The Conveyor Support Brackets To The Peak Cap
Chapter 7: Roof Assembly Figure 7-41 Cap plate assembly installed 3/8 x 1 in. bolt with sealing washer (S- Holes for conveyor support brackets 7487) 3/8 in. nut (S-456) Installing the Conveyor Support Brackets to the Peak Cap Conveyor support brackets are attached to the peak cap and allow support for a conveyor or catwalk system.
Page 117 Chapter 7: Roof Assembly Figure 7-42 Conveyor support brackets 3/8 x 1-1/2 in. flange bolt (S-7488) 3/8 in. flange nut (S-456) Conveyor support bracket (CTR-0087) Caulk After You Finish Repeat this procedure for the remaining conveyor support brackets. Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 118 NOTES Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 119: Chapter 8 Accessories
Accessories Topics Covered in this Chapter ▪ Installing Roof Ladder Steps ▪ Roof Ring Placement ▪ Installing a Roof Ring ▪ Installation of Peak–To– Exhauster Ladder Kit ▪ Preparation for Roof Exhauster Installation ▪ Assembling the Roof Exhauster ▪ Installing Roof Exhauster Assembly ▪...
Page 120: Installing Roof Ladder Steps
Chapter 8: Accessories Installing Roof Ladder Steps Roof ladder steps will allow access to roof and manway access. What You Should Know Each eave-to-peak ladder step package (E) differs with the diameter of each bin. When installing the ladder steps, always start from the eave and work up toward the peak, installing the longest step first and the shortest step last.
Page 121 Chapter 8: Accessories Use the following table as a guide to the location of each ladder step (rung). Table 8-1 Ladder Rung Placement Chart Bin Diameter Location 72 ft. 75 ft. 78 ft. 90 ft. 105 ft. 135 ft. Bin Peak LS-260-1 LS-260-1 LS-260-1...
Page 122: Roof Ring Placement
Chapter 8: Accessories NOTE: The table above shows the correct ladder step and part number to be installed in the corresponding hole in the roof rib. Shaded areas also show the correct roof exhauster ladder step and part number with the corresponding hole in the roof rib. Roof Ring Placement The roof ring is a tubular ring bolted to the exterior of the roof.
Page 123: Installing A Roof Ring
Chapter 8: Accessories Installing a Roof Ring Quantity and part numbers of roof ring kits vary with the location placement and with the size of each bin. The following procedure will be similar for each kit. What You Should Know The roof ring and threaded stud may become dislocated from each other during high winds or when the inside pressure of the bin is too great.
Page 124 Chapter 8: Accessories 6. Install the threaded stud (F) with stud nuts (G) to the end of the roof ring section (B). NOTE: Install the threaded stud (F) to the side where the next roof ring section will be installed. 7.
Page 125: Installation Of Peak-To- Exhauster Ladder Kit
Chapter 8: Accessories Installation of Peak–To– Exhauster Ladder Kit Before installing the roof exhauster, the peak-to-exhauster ladder kit may be installed onto the roof to have access to the roof exhauster. Before You Begin Determine the location of the roof exhauster. What You Should Know This procedure is to install the peak to exhauster ladder kit onto the roof .
Page 126: Preparation For Roof Exhauster Installation
Chapter 8: Accessories Table 8-2 Peak-to-Exhauster Ladder Rung Kit Bin Diameter Location 72 ft 75 ft 78 ft 90 ft 105 ft 135 ft ↑ LS-260-1 Bin Peak LS-260-1 LS-260-1 LS-260-2 LS-260-2 LS-260-1 LS-260-1 LS-260-1 Bolt Hole LS-260-2 Count Located on LS-260-1 the Roof Rib LS-260-1...
Page 127 Chapter 8: Accessories 1. Position the roof panels (K) spanned by the roof exhauster mounting plate on the ground. Align the roof panel holes as if they are installed on the bin. 2. Temporarily install the roof exhauster mounting plate (F) to the roof panels (K) using bolts (G) and nuts (E), ensuring all holes are aligned and the teeth of the roof exhauster mounting plate (F) are nes- tled in between two roof ribs.
Page 128: Assembling The Roof Exhauster
Chapter 8: Accessories 5. Remove the roof exhauster mounting plate (F), to make the necessary cut along the mark or scribe (I). Figure 8-7 Using the roof exhauster flashing and mounting plate as a template Marked or scribed hole to be cut 6.
Page 129: Installing Roof Exhauster Assembly
Chapter 8: Accessories Figure 8-8 Roof exhauster assembly 5/16 x 1 in. hex bolt (S-10260) 5/16 in. flange nut (S-3611) Roof exhauster hood Exhauster mounting plate (CTR-0288) Tube Caulk Exhauster standoff weldment (MIS-7117) Installing Roof Exhauster Assembly The roof exhauster assembly replaces one of the roof flashing panels and allows for the roof exhauster to be installed.
Page 130 Chapter 8: Accessories NOTE: The roof exhauster kit is shipped with additional parts. The following part numbers will not be used on 40-series bins: MIS-6703, MIS-6706, MIS-6707, MIS-6805, MIS-6810, MIS-6811, CRP-4793 and CRP-5262. 1. Before lifting the roof exhauster into place, apply strips of sealing caulk (F) along the ribs of each roof panel and on each roof flashing as shown.
Page 131 Chapter 8: Accessories Figure 8-9 Installing roof exhauster Roof exhauster flashing (CTR-0287) 5/16 flange nut (S-3611) 5/16-18 x 1 flange bolt, with sealing washer Sealing caulk (S-10260) 5/16-18 x 1 flange bolt with sealing washer Sealing caulk (S-10260) Roof exhauster assembly 7.
Page 132: Assembling The Auto Roof Vent
Chapter 8: Accessories Figure 8-10 Sealing caulk location Roof exhauster assembly Sealing caulk Assembling the Auto Roof Vent The following instructions are for assembling the auto-vent. First, check the packing list to ensure all com- ponents have been shipped. The unit is easiest assembled in the upside-down position as shown in the instructions.
Page 133: Assembling Grill Guard Roof Vent
Chapter 8: Accessories Figure 8-11 Auto roof vent assembly Hold-down angle (MIS-4404) Roof vent housing assembly (MIS-6778) 5/16 x 1-1/4 in hex bolt (S-7483) 5/16 in. flange nut (S-3611) #10 self-drilling screws (S-280) Flap assembly (MIS-6777) Assembling Grill Guard Roof Vent The following instructions are for assembling the wire grill guard roof vent.
Page 134 Chapter 8: Accessories 5. Insert another hex bolt (B) through the other side of the roof vent housing (D), and install a flange nut (E) to the hex bolt (B),insert the eyelet of the grill guard assembly (F) onto the edge of the hex bolt (B).
Page 135: Installing The Roof Vents
Chapter 8: Accessories Installing the Roof Vents The following instructions are for installing the wire grill guard roof vent and the auto roof vent. Before You Begin The wire grill guard roof vent and the auto roof vent must be assembled prior to installing. 1.
Page 136: Installing The Manway Cover
Chapter 8: Accessories Installing the Manway Cover Installation of a manway cover is necessary if a manway hole is present. 1. Install each hinge base (A) to the manway roof panel (B), and secure with hex bolts (C) and nuts (D). 2.
Page 137: Ladder Section Assembly
Chapter 8: Accessories Figure 8-14 Manway cover Hinge base (MW-291) Manway sill Manway roof panel (CTR-0302) Hinge leaf (MW-272) 5/16 x 3/4 in. hex bolt (S-275) Manway cover (MW-008) 5/16 in. nut (S-396) Latch (MW-271) Latch base bracket (MW-289) 5/16 X 4 in. hex bolt (S-855) Manway seal strip 5/16 in.
Page 138: Inside Ladder Placement
Chapter 8: Accessories NOTE: A portion of the last ladder section may need to be cut to fit the proper length to the ground or to the intermediate platform. 1. Place two ladder sections (A) together as shown. 2. Install a splice plate (C) to each outside channel, connecting the ladder sections (A). 3.
Page 139 Chapter 8: Accessories Figure 8-16 Positioning the ladder Manway access Ladder assembly 1. Install the right-hand starter bracket (C) to the top hole in the first sidewall ring, located closest to the eave. Install a flange bolt (D), and secure with a flange nut (G). 2.
Page 140 Chapter 8: Accessories 7. Tighten hardware to the recommended torque specifications. See Bolt Torque Specifications, page 8. Install the ladder (B) to the starter brackets (C and K), and install hex bolts (M) and nuts (N), but do not tighten at this time. 9.
Page 141 Chapter 8: Accessories Figure 8-17 Installing ladder brackets Ladder assembly 5/16 in. hex bolt (S-275) Starter bracket (RH LDR-4347) Starter bracket (LH LDR-4346) See sidewall hardware chart. 3/8 in. field drilled hole location Approximately 18-3/4 in. (47.62 mm) 5/16 x 3/4 in. flange bolt (S-275) 3/8 in.
Page 142: Installing Inside Ladder Bottom Bracket
Chapter 8: Accessories Installing Inside Ladder Bottom Bracket The ladder bottom bracket keeps the lower portion of the ladder secure. What You Should Know The lower portion of the ladder may need to be cut to fit properly. Field drilling will be required to complete installation.
Page 143: Guidelines For Installing A Sidedraw System
NOTE: If a sidedraw system is installed, the standard 3/4 in. anchor bolts must be replaced with 1 in. anchor bolts. • Side discharge is only permitted in GSI commercial bins when a GSI manufactured sidedraw flume system has been installed. No corrugated steel bin must be unloaded through the side wall without installation of such a system and permission of the manufacturer.
Page 144 90 degrees apart. Installation of multiple systems requires approval of GSI. • Sidedraw systems are intended for use with dry, flowable grain. Sidedraws are not to be used for poorly flowing products. This is not unique to GSI bins and flume systems, but is a general rule for such systems.
Page 145 Chapter 8: Accessories Figure 8-19 Two and three post stiffener examples Typical 24-ring bin Two post stiffener Typical 29-ring bin Three post stiffener Sidewall sheet Standard height of discharge chute 16 ft. 4 in. (5 NOTE: Use the following tables as a guide or reference for the proper placement of the sidedraw system. Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 146: Installing The Sidedraw Baffle Chute (Two Post Stiffener)
Chapter 8: Accessories Table 8-3 Sidewall Instructions (Two Post Stiffener) Number of Rings on the Bin Chute Location Horizontal Starting Location Locate 1st chute in 2nd ring from top. Top bolt holes in chute to be located on 2nd corrugation of body sheet. 11, 12, 15, 17, 19, 21, and 23 Center chute over vertical seam.
Page 147: Installing The Sidedraw Baffle Chute (Three Post Stiffener)
Chapter 8: Accessories Figure 8-20 First Chute Locations (Two Post Stiffener Only) and Spacing of each baffle chute Stiffener’s center line Field drilled hole location (7/16 in. diameter hole) Second ring from top of bin 3/8 x 1-1/2 in. flange bolt (S-7488) Suitable baffle chute locations 3/8 in.
Page 148 Chapter 8: Accessories NOTE: Depending on the location of the baffle chute (C), the measurement from the sidewall edge will vary (D or E). 3. Locate the horizontal seam connecting the first and second ring, and measure approximately 2-21/32 in. (J) from the center hole in the horizontal seam, to the first center hole on the baffle chute, mark or scribe the hole location.
Page 149: Installing The Sidedraw Discharge Chute
Chapter 8: Accessories Figure 8-21 First chute locations (three post stiffener only), and spacing of each baffle chute Stiffener’s center line Field drilled hole location (7/16 in. diameter hole) Second ring from top of bin 3/8 x 1-1/2 in. flange bolt (S-7488) Suitable baffle chute locations 3/8 in.
Page 150 Chapter 8: Accessories Field cutting is required to create the opening for the discharge chute. Cutting the opening will require two sidewall panels to be modified. 1. Find the column of bolt holes (A) located on either side of the last baffle chute (B). Measure approxi- mately 11 in.
Page 151 Chapter 8: Accessories 4. Place another mark or scribe where the vertical center line (D) and the horizontal center line (G) meet, creating the center of the discharge chute location (F). 5. Remove the baffle chute from the sidewall panel. Figure 8-23 Horizontal line location of discharge chute Vertical center line Center of discharge chute location...
Page 152 Chapter 8: Accessories 9. Field cut the discharge chute hole making a 1-1/2 radius at each corner. Figure 8-24 Discharge Chute Hole Outline Vertical center line Horizontal center line 10.Separate the upper sidewall panel (I) from the lower sidewall panel (J). 11.Apply two beads of caulk to seal the discharge chute assembly to the sidewall panels, and insert the discharge chute assembly (H) between the upper sidewall panel (I) and the lower sidewall panel (J).
Page 153 Chapter 8: Accessories Figure 8-25 Discharge chute assembly (view form inside the bin) Discharge chute assembly Lower sidewall panel Upper sidewall panel 12.Using the discharge chute assembly (H) as a guide or template, field drill all necessary holes to secure the discharge chute assembly (H) to the upper sidewall panel (I) and the lower sidewall panel (J).
Page 154 Chapter 8: Accessories Figure 8-26 Field drilling discharge chute assembly (view from inside the bin) Discharge chute assembly 3/8 x 1-1/2 in. flange bolt (S-7488) Upper sidewall panel 3/8 in. flange nut (S-456) Lower sidewall panel 14.Place the baffle chute (B) into place and field drill necessary holes, securing with flange bolts and flange nuts.
Page 155 Chapter 8: Accessories Figure 8-27 Reinstall baffle chute (view from inside the bin) Baffle chute Field drilled hole location 15.Tighten hardware to the recommended torque specifications. See Bolt Torque Specifications, page Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 156: Wind Ring Requirements
Chapter 8: Accessories Wind Ring Requirements Wind rings give additional strength against high winds and uneven loads. The quantities and placement of wind rings will depend on the size of bin being constructed. Figure 8-28 Wind ring locations A Distance (inches) between the center of each wind ring pipe Sidewall ring numbers and location for ring pipe (0.00) = horizontal seam installation.
Page 157 Chapter 8: Accessories Figure 8-29 Dimensions for OSHA Compliant Ladder Rung Placement NOTE: Ensure the wind rings are installed in rela- tion to the ladder rungs as shown to meet O.S.H.A. specifications. Pneg-4078-O15 78 Ft Diameter 40-Series Bin...
Page 158: Installing Wind Rings
Chapter 8: Accessories Installing Wind Rings Installation of wind rings is similar for a two and a three post bin design, although hardware quantities may vary. What You Should Know Before installing, determine the bin size, sidewall gauge thickness, and height. Use the hardware chart to match the correct bolt length with the correct sidewall gauge thickness when installing the wind ring brack- ets to the stiffeners (Refer to hardware requirements chapter).
Page 159 Chapter 8: Accessories 7. Slide the wind ring coupling collar (K), aligning the three pre-drilled holes, and install flange bolts (F) and hex nuts (G). Field drill the remaining three holes (L) using the wind ring coupling collar (K) as a guide or template.
Page 160: Assembling Weather Cover For Roller Valve
Chapter 8: Accessories Assembling Weather Cover for Roller Valve The following instructions are for assembling the weather cover for the roller valve. 1. Install the weather cover kit after the gate has been installed. 2. Use bead caulking at all seams where the weather cover attaches to the gate. 3.
Page 161: Gsi Group, Llc Limited Warranty
12 months from the date of shipment (or, if shipped by vessel, 14 months from the date of arrival at the port of discharge). If, in GSI’s sole judgment, a product is found to have a defect in materials and/or workmanship, GSI will, at its own option and expense, repair or replace the product or refund the purchase price.
Page 162 Authorities having jurisdiction should be consulted before installations are made. GSI Group 1004 E. Illinois St. Assumption, IL 62510-0020 Phone: 1-217-226-4421 Fax: 1-217-226-4420 www.gsiag.com GSI is a worldwide brand of AGCO Corporation. Copyright © 2015 by GSI Group Printed in the USA CN #322015...

GSi 40 Series Construction Manual

Chapter 1 Safety Precautions

Chapter 2 General Overview

Chapter 3 Hardware Requirements

Chapter 4 Assembling Sidewall Sheets

Chapter 5 Base Angle Installation

Chapter 6 Stiffeners

Chapter 7 Roof Assembly

Chapter 8 Accessories

Quick Links

Need help?

Questions and answers

Related Manuals for GSi 40 Series

Summary of Contents for GSi 40 Series

Table of Contents
