PEERLESS DS246 Installation And Assembly

Installation and Assembly - WIDE SCREEN WALL MOUNT
FOR LGM3800S and LGM2900S
IMPORTANT! Read instruction sheet before you start installation and assembly.
Before you start make sure all parts listed are included with your product.
Parts List
Description
A tilt plate adapter bracket
B wall plate
C M5 x 1" penta pin driver
D M10 x 15 mm penta pin screw
E M5 x 12 mm socket pin serrated washer head screw
F #14 x 2.5 phillips hex head wood screw
G alligator anchor
H 4 mm Allen wrench
Some parts may appear slightly different than illustrated.
B
• This product was designed and intended to be mounted to the following supporting surfaces checked below with the
hardware included in this product as specified in the installation sheet. To mount this product to an alternative support-
ing surface, contact Peerless customer care at 1-800-865-2112.
• This product was designed to be installed on the following wall construction only;
WALL CONSTRUCTION
x Wood Stud
x Wood Beam
x Solid Concrete
x Cinder Block
x Metal Stud
Brick
Other or unsure?
Visit the Peerless Web Site at www.peerlessmounts.com
Qty. Part #
1 201-1652
1 201-1653
1 520-9249
4 520-9263
6 510-1064
4 5S1-015-CO3
4 590-0097
1 560-1131
C
E
WARNING
ADDITIONAL HARDWARE REQUIRED
None
None
None
None
Do not attach except with Peerless accessory kit ACC415 for metal studs;
Contact Customer Service for Peerless accessory kit for metal studs.
Contact Customer Service
Contact Customer Service
1 of 5
A
D
G
Max Load Capacity: 50 lb (22.6 kg)
For customer service call 1-800-729-0307 or 708-865-8870.
Model: DS246
F
H
ISSUED: 02-03-09 SHEET #: 202-9308-1
