Item Description
Components, parts and materials containing
refractory ceramic fibers
Components, parts and materials containing
radioactive substances

2.0 Tools Required

List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Torx Driver
Flat Head Driver

3.0 Product Disassembly Process

3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. System Board Battery - Locate the battery on the system board. Use a medium flat head screwdriver or fingers to
remove the battery and dispose of properly.
2. Fan - Take the FAN out of the Chassis and dispose of properly.
3. Capacitors>2.5 cm - Remove the PSU from the system. With screw driver, remove the screws securing the top cover,
locate the capacitors and use a medium flat head screwdriver to remove them and dispose of properly.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
Attachment 1 – Battery Location
Attachment 2 – Fan Location
Attachment 3 & 4 – Electrolytic Capacitors location in PSU
MF877-00
Template Revision C, 30-July-2018
Copyright 2018 Hewlett Packard Enterprise Development LP
HPE instructions for this template are available at
Notes
Tool Size (if
applicable)
T15
Medium
MF877-01
Quantity
of items
included
in product
0
0
