User Manual
KVM Extender
CE-250
User Manual
Read this manual thoroughly and follow the installation
procedures carefully to prevent any damage to the CE-250
and/or the devices it connects to.
©Copyright 2000-2003 Aten® International Co., Ltd.
Manual Part No. PAPE-1221-100
Printed in Taiwan 01/2003
All brand names and trademarks are the registered property of their
respective owners.
Advertisement
Table of Contents
Related Manuals for ATEN CE-250
Summary of Contents for ATEN CE-250
-
Page 1: User Manual
KVM Extender CE-250 User Manual Read this manual thoroughly and follow the installation procedures carefully to prevent any damage to the CE-250 and/or the devices it connects to. ©Copyright 2000-2003 Aten® International Co., Ltd. Manual Part No. PAPE-1221-100 Printed in Taiwan 01/2003 All brand names and trademarks are the registered property of their respective owners. -
Page 2: Packing Checklist
- away from dust, dirt, and harsh environmental influences. The CE-250 System is also useful for control and security purposes, where you can have the system unit in a secure area at the same time that you put the console in a location that offers convenient access. -
Page 3: System Requirements
Setup is as easy as can be - simply connect the computer system box and local console to the Local CE-250 Module; run the Cat. 5 cable to the Remote CE-250 Module (up to 150 meters away); and plug the remote console into the Remote Module. - Page 4 AT type keyboard and mouse ports to the CE-250L. For those computers, using CS Custom KVM Cables must be used. Category 5 cable is required to connect the local and remote CE-250 units. Using cable of a lesser standard will result in degrading the video signal.
- Page 5 1. Operating Mode Selection Switch Pressing this button cycles you through the operating mode choices: Local: only the local console can control the system(s); Auto: both consoles can control the system(s)). 2. LEDs The Local Unit has two LEDs to indicate the Local and Remote units.
- Page 6 The mouse connector of the KVM cable that connects to the computer's Video port plugs into this connector. Note: If you are combining the CE-250 with a KVM switch, the KVM cable connects back to the respective ports on the Console section of the switch.
-
Page 7: Installation
The cable from the AC Power Adapter plugs into this jack. Installation Setting up the KVM Extender System is simply a matter of plugging in the cables: Make sure that all the equipment to be connected up is powered Off. -
Page 8: Operation
Plug the cables from the remote console devices (mouse, keyboard, monitor), into their ports on the Console side of the CE-250R. Each port is marked with an appropriate icon to indicate itself. Plug the second power adapter (supplied with this package) into an AC source;... -
Page 9: Troubleshooting
Local Local Lights to indicate that the local console is active (the Remote LED is out). Remote The LED is off. CE-250R (Remote Unit) Power 1. Lights steadily to indicate that the connection to the 2. Flashes when there is a problem with the connection On Line 1. -
Page 10: Tp Wiring Diagram
No Video Make sure that all cables are securely plugged into their sockets. TP Wiring Diagram TP Pin Assignments Assignment V OUT B /V OUT B V OUT G V OUT R /V OUT R /V OUT G Specifications Function Connectors Keyboard Mouse... -
Page 11: Limited Warranty
Video Resolution Power Consumption Operating Temp. Storage Temp. Humidity Housing Weight Dimensions (L x W x H) DDC, DDC2, and DDC2B support is for the Local monitor only. Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT FORM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK, OR ITS DOCUMENTATION.
