User Manual
User Manual
CE-250
Read this guide thoroughly and follow the installation and
operation procedures carefully in order to prevent any damage to
the units and/or any devices that connect to them.
This package contains:
1 CE-250L KVM Extender (Local Unit)
1 CE-250R KVM Extender (Remote Unit)
1 CS Custom KVM Cable
2 Power Adapters
1 User Manual
If anything is damaged or missing, contact your dealer.
Copyright © 2006 ATEN
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights
reserved. All other trademarks are the property of their respective owners.
®
International Co., Ltd.
Manual Part No. PAPE-1221-100
Printing Date: 03/2007
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ATEN CE-250
Summary of Contents for ATEN CE-250
-
Page 1: User Manual
® Copyright © 2006 ATEN International Co., Ltd. Manual Part No. PAPE-1221-100 Printing Date: 03/2007 ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. - Page 2 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause interference to radio...
- Page 3 Setup is as easy as can be - simply connect the computer system box and local console to the Local CE-250 Module; run the Cat. 5 cable to the Remote CE-250 Module (up to 150 meters away);...
- Page 4 Features Built-in ASIC for greater reliability and compatibility Cat 5 cable to connect the local and remote units – up to 150 meters apart Dual console operation – control your system from both the local and remote PS/2 keyboard, monitor, and mouse consoles Push button selection –...
-
Page 5: System Requirements
CS Custom KVM Cable that is provided with this package. Category 5 cable is the minimum required to connect the local and remote CE-250 units. Cable of a lesser standard will result in degrading the video signal. For best performance, we strongly recommend Category 5 cable. -
Page 6: Front View
Components The Local Unit (CE-250L) Front View: Description Function Operating Mode Pressing this button toggles between the operating Selection mode choices: Switch Local: only the local console can control the system(s) Auto: both consoles can control the system(s). LEDs The Local Unit has two LEDs to indicate the operating status of the Local and Remote units (see CE-250L (Local Unit), p. -
Page 7: Rear View
The Mouse connector of the KVM cable that connects to the computer's Mouse port plugs into this connector. Note: If you are combining the CE-250 with a KVM switch, the KVM cable connects back to the respective ports on the Console section of the switch. - Page 8 The Remote Unit (CE-250R) Front View: Description Function LEDs The Remote Unit has two LEDs (Power and On Line) to indicate the operating status of the Local and Remote units (see CE-250R (Remote Unit), p. 11). Mouse Port The remote PS/2 mouse plugs into this connector. Keyboard Port The remote PS/2 keyboard plugs into this connector.
-
Page 9: Installation
Installation Setting up the CE-250 KVM Extender system is simply a matter of plugging in the cables. Refer to the installation diagram on the following page and do the following: 1. Make sure that all the equipment to be connected up is powered Off. - Page 10 CE-250L FrontView CE-250L Rear View CE-250R - 10 -...
-
Page 11: Operation
Operation The Local and Remote Units each have two LEDs to indicate their operating status, as shown in the tables, below: CE-250L (Local Unit) Operating Mode Local Auto Local Lights to indicate that 1. Lights when the local console is active the local console is (the Remote LED is out). -
Page 12: Troubleshooting
Troubleshooting Problem Action No video Make sure that all cables are securely plugged into their sockets. Poor video quality. The video quality can be improved by reducing the refresh rate. TP Wiring Diagram PAIR 3 PAIR 2 PAIR 1 PAIR 4 1 2 3 4 5 6 Bl W-Bl G W-Br Br... -
Page 13: Specifications
Specifications Function CE-250L CE-250R Connectors Keyboard 2 x 6-pin Mini-DIN F 1 x 6-pin Mini-DIN F Mouse 2 x 6-pin Mini-DIN F 1 x 6-pin Mini-DIN F Monitor 1 x HDB-15 M 1 x HDB-15 F 1 x HDB-15 F LEDs 1 x Local 1 x Power On... -
Page 14: Limited Warranty
Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT FROM THE DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMENTATION. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and specially disclaims its quality, performance, merchantability, or fitness for any particular purpose.
