- Page 1 Roger Access Control System RKD32 Installation Manual Product version: 1.0 App version: 1.3.2 Document version: Rev. C...
-
Page 2: Design And Application
RKD32 cabinet. Prior to placing keys inside cabinet, they must be firmly attached to included RFID fobs. RKD32 can recognize fobs so keys can be returned to any unoccupied slot in the cabinet. It is possible to assign users with authorizations for particular keys. Typically users are identified at the panel with Mifare proximity cards or PINs. -
Page 3: Power Supply
+12V and GND screw terminals at RKD board (fig. 4). Battery cannot be directly connected to RKD32 so the emergency supply (battery, UPS) must be ensured on the level of buffer power supply unit (e.g. HPSB2512B PSU from Pulsar company). The required emergency operational time of key cabinet(s) must be considered when battery or UPS is selected. - Page 4 MD70 panel Management of RKD32 is performed by means of MD70 panel. Single panel can be used to control up to 4 cabinets, each with 32 slots for RFID fobs and keys. The next cabinets (RKD32EXT) are connected to the main cabinet (RKD32) using RJ45 sockets on RKD boards (fig.
-
Page 5: Installation
Connect and lead all cables through cable hole in back cover and then mount the cover on wall according to fig. 6 using holes shown in fig. 5. When RKD32 is mounted on back cover as in fig. 6 then both locks will latch automatically. The communication with RKD32 in network mode and via web browser can be provided through Ethernet or Wi-Fi connection (more information on configuration of MD70 network parameters is given in its manual). - Page 6 RKD32 Installation and Configuration Manual.doc 16.10.2020 Fig. 5 Back cover Fig. 6 Wall mounting 6/20...
- Page 7 RKD32 Installation and Configuration Manual.doc 16.10.2020 Fig. 7 Connection of additional cabinets (RKD32EXT) to main cabinet (RKD32) Fig. 8 RKD and MCX4D boards Table 1. Screw terminals and sockets Terminal/ Description socket +12V 12VDC power supply Ground 7/20...
- Page 8 RJ45 socket for connection of third module (RKD32EXT), only at RKD32 BOX-4 RJ45 socket for connection of fourth module (RKD32EXT), only at RKD32 * In newer RKD32 models, MASTER socket is available inside key chamber after door opening in the right bottom corner (fig. 9). Fig. 9 USB MASTER socket 3.
- Page 9 Fig. 11 Main menu When in the top right corner is selected then Alarm Center is started. It shows all alarm events (forced opening, tamper, etc.) registered by RKD32 in selected time range. The colour of icon corresponds to following statuses: ·...
- Page 10 RKD32 Installation and Configuration Manual.doc 16.10.2020 When is selected then Report Center is started as in fig. 12. After selection of Events tile it is possible to browse, events (e.g. user login, key collecting, etc.) and after selection of in the same window it is possible to delete and export events registered by RDK32.
- Page 11 RKD32 Installation and Configuration Manual.doc 16.10.2020 Assigning the key to the Inner zone allows the implementation of key anti-passback function. The user can collect a key from another zone only when he returns all keys belonging to inner zone. The inner zone is intended for keys that should stay as short as possible outside the cabinet (e.g.
- Page 12 RKD32 Installation and Configuration Manual.doc 16.10.2020 is opened and user is logged out. Range: 0-99. Default value: 60. Fire alarm support (fobs release) Parameter enables emergency release of door and key locks as long as the input DR3 is triggered by external system e.g. fire alarm system.
- Page 13 MD70 starting screen. Additionally the parameter Custom wallpaper (table 2) must be enabled. Detect devices Command starts the view of the list of devices in the RKD32 system. After adding another depositor cabinet, run a scan to detect new devices.
- Page 14 Command displays information on uploaded RKD32 licenses in regard of network mode and management via web browser. Export database Command enables to make backup of RKD32 settings on pendrive as explained in section 7. Import database Command enables to import RKD32 settings from file on pendrive as explained in section 7.
- Page 15 Users who were defined in PR Master software of RACS 4 system can be imported to avoid another manual enrolment of the same data on the level of RKD32 key cabinet. 1. Start PR Master program, select Users and then Export in order to export users with their card numbers and PINs to PRM.CSV file.
-
Page 16: Configuration Via Web Browser
5. C ONFIGURATION VIA WEB BROWSER RKD32 key cabinet can be remotely configured and managed via web browser. In such scenario it is necessary to define parameters in section WWW settings (table 2). The communication with MD70 panel can be in Ethernet network or Wi-fi network. The IP address of the panel in LAN/WAN is configured by means of Ethernet app after exiting RAACA app with the command Show launcher (table 4). - Page 17 AN024 application note which is available at www.roger.pl. Settings backup RKD32 settings (including users) can be exported to file for the purpose of backup. Exporting and importing is also recommended in case of RAACA app update.
-
Page 18: Remote Technical Support
16.10.2020 License upload In case of RKD32 management via web browser or via VISO software (network mode) it is necessary to activate license on the level of key cabinet. You can verify your license selecting License file command (table 4). In order to upload purchased license place license file on USB disk or internal storage of device. -
Page 19: Ordering Information
Table 7. Ordering information RKD32 RKD32: Electronic key cabinet with 7” touch control panel; 32 RFID fobs attached to keys by user; external 12V power supply; SG option for P2 class glass window; option RP for control panel installed separately on a wall RKD32EXT RKD32EXT: Electronic key cabinet without control panel;... - Page 20 RKD32 Installation and Configuration Manual.doc 16.10.2020 This symbol placed on a product or packaging indicates that the product should not be disposed of with other wastes as this may have a negative impact on the environment and health. The user is obliged to deliver equipment to the designated collection points of electric and electronic waste.
