- Page 1 INTEGRATION GUIDE iSELF VENDING CLASSIC...
-
Page 2: Table Of Contents
CONTENT INTRODUCTION ..................................... 3 1.1 iSELF VENDING CLASSIC PAYMENT SOLUTION PRESENTATION ................... 3 1.2 DIAGRAM OF iUP250LE CONNECTIVITY AND COMMUNICATIONS .................. 3 DESCRIPTION OF MODULES ............................... 4 2.1 iUP250LE – PIN PAD .................................. 4 2.1.1 iUP250LE TECHNICAL CHARACTERISTICS .......................... 4 2.1.2 iUP250LE OUTPUT CONNECTORS DESCRIPTION ........................ 5 2.1.3 WAKE-UP MECHANISM .................................. 7 2.2 iUR250 – HYBRID CARD READER .............................. 8 2.1.1 iUP250LE TECHNICAL CHARACTERISTICS .......................... 8 2.2.2 RGB LEDS ...................................... 10 2.2.3 OPTIONAL LEVER LOCK ................................... 10 2.2.4... -
Page 3: Introduction
INTRODUCTION iSELF is a cashless payment solution comprising both hardware INGENICO Partners, who are qualified professionals specializing and software components, designed by the INGENICO Group in their particular area of activity, have specific know-how (hereinafter “INGENICO”) to integrate payment functionality into and a high level of technical knowledge as regards integrating self-service devices or terminals, such as vending machines, fuel cashless payment solutions into their Terminals. pumps, ticket machines, kiosks, etc. (hereinafter the “ Terminal[s]”). These guidelines are intended as a reminder of good practice Products in the iSELF range are only intended to be installed in and set out the rules applicable to all our Partners with regard Terminals by manufacturers or integrators responsible for the to integrating iSELF into their Terminals. complete assembly of such devices (hereinafter the “Partner[s]”). iSELF VENDING CLASSIC PAYMENT SOLUTION PRESENTATION The iSelf Series is the new range of Ingenico unattended devices Additional peripherals can be added to build a complete solu- to offer payment into any kiosk through any segments (petrol, tion such as printer or bar code reader. Ingenico does not transport, vending, parking, etc.). The terminal solution consists p rovide these devices as such but they can be connected to of the following modules used for PIN management, contact the iUP250 (through, USB, or RS232). cards and contactless cards: The products, certified PCI PTS, must be installed together into • P IN pad, the iUP250LE an environment that must comply with several rules described • H ybrid card reader, the iUR250... -
Page 4: Description Of Modules
DESCRIPTION OF MODULES iUP250LE – PIN PAD Front view Rear view The target keyboard layout of the iUP250LE has got the command keys with the characters OK, CLR, STP. 2.1.1 iUP250LE TECHNICAL CHARACTERISTICS Mass 860 g Dimensions (height × width × depth) 134 × 101 × 32 mm (w/o Ethernet connectivity) 134 × 101 × 39 mm (w/Ethernet connectivity Power supply 9 – 1 6 V Max 2 A Platform Telium 2 Memory 32 Mb SDRAM and 128 Mb Flash Functionality Keys: 17 metallic keys 1 Jack for external lighting 128 × 64 graphic display wake-up mechanism on RS232 connectors RGB Backlight Buzzer RGB led internal status indicator 1 Maintenance Button µSD 2 SAM... -
Page 5: Iup250Le Output Connectors Description
OPERATING CONDITIONS Operational temperature * – 2 0 °C, +55 °C Functional temperature * – 2 0 °C, +65 °C Max relative humidity 85% at 55 °C, non-condensing Maximum backward leaning 30 degrees from vertical * 5 5 °C is a maximum using temperature for user safety (IEC 60950). The product is operational up to 65 °C with no tampering issue. STORAGE CONDITIONS Storage temperature – 2 0 °C, +65 °C Max relative humidity 85% at 55 °C, non-condensing 2.1.2 iUP250LE OUTPUT CONNECTORS DESCRIPTION Power LLT/Maintenance Button COM0 & COM2 Link USB hosts... - Page 6 ETHERNET The iUP250LE has a maintenance button on the back. • T he iUP250 PINPad unit can be connected to Ethernet. • T o enter LLT mode, press the button at power up or at The connector type is shielded RJ45. restart, until the red led lights on. • T he Ethernet cable is standard and not p rovided. • T o enter Maintenance mode, press the b utton at power • T he Ethernet cable must be shielded. up or at restart, until the red led starts blinking. • T o restart the product, press the button until the blue led USB DEVICE lights on. The iUP250LE unit can be connected by a JST low profile c onnector. BUZZER The buzzer is controlled by the application. The frequency USB HOST depends on the software.
-
Page 7: Wake-Up Mechanism
2.1.3 WAKE-UP MECHANISM The iUP250LE and the terminal is designed to save power The wake-up pin is driven to “0” by the one asking the wake-up. thanks to a “stand-by and sleep mode”. It could be driven by any iSelf Series module or any devices If the stand-by mode is used, use the wake-up mechanism: designed to be compliant (Host device…). • W ith button connected on jack (optional) • W ith Pin 2 of COM0 link & COM2 link • B y pressing the “OK” key on keyboard WAKE-UP WIRING RECOMMENDED CIRCUIT IMPLEMENTATION – EXAMPLE OF iUP, iUR AND iUC 0 = ON mode Hz = sleep mode Connector COM0 or COM2 High level for wake-up of external product PIN 2: Wake-up pin The wake-up pin must be high impedance. Do not connect The voltage on this pin must not exceed 10 V in any case. -
Page 8: Iur250 - Hybrid Card Reader
iUR250 – HYBRID CARD READER Front view Rear view USB Device Wake-up 2.1.1 iUP250LE TECHNICAL CHARACTERISTICS Mass 700 g without cable Dimensions 148 × 108 × 73 mm (depth × width × height) OPERATING CONDITIONS Functional temperature – 2 0 °C, +65 °C Max relative humidity 85% at 55 °C, non-condensing Fixing Tilt iUR250 must be horizontally fixed or can be leaned up to 45° to evacuate water Power supply USB 5 V 500 mA Platform Telium 2 Card interface EMV level 1 and ISO 7816 (read & write) T=0, T=1 and synchronous cards Magnetic stripe: ISO 1/2/3 (read only) Functionality... - Page 9 USB DEVICE wake-up pin state iUR25x reader unit can be connected by typ A USB. Hz (high impedance) Stand-by authorized WAKE-UP MECHANISM Drive to “0” Wake-up/Stand-by unauthorized iUR25x is design to save power thanks to a “stand-by mode”. To wake-up iUR25x, insert a card or use Wake-up mechanism. Pin 2 of COM0 link drive the wake-up mechanism. The Wake-up pin is drive to “0” by the one asking the wake-up. It could be driven by iUR25x, iUP250 or any devices designed to be compliant (Host device...) COM0 LINK The iUR25x serial port COM0 is only available for debug feature and to manage wake-up mechanism. The connector type is RJ11. PIN No Function Wake-up RXD (not for customer use) Pin 6 Pin 1 RXD (not for customer use) RXD (not for customer use) RXD (not for customer use)
-
Page 10: Rgb Leds
• R ed led flashing slowly: product is disabled (Keys erased, no irruption). 2.2.3 OPTIONAL LEVER LOCK The Lever lock is controlled by application. NOTE A mechanical mechanism in the reader c omponent permits It may be used to forbid the withdrawal of the card during to extract the smart card, with an extraction force arount chip access. 30N to avoid permanent card blocking. 2.2.4 PIN PAD AND READER iUR250 INTERCONNECTIVITY The connection between the iUP250LE and the reader iUR250 Plug the USB cable on the iUP250LE and the iUR250 with the is done through USB. Ingenico standard USB cable USB-A – USB-B with the part number 296129367. iUC150B – COMPACT CONTACTLESS READER 2.3.1 PRODUCT VIEWS... -
Page 11: Iuc150B Output Connectors Description
2.3.2 iUC150B OUTPUT CONNECTORS DESCRIPTION USB Device Go cless Link Serial link + wake up cable 2.3.3 iUC150B TECHNICAL HARDWARE CHARACTERISTICS Mass 87 g Dimensions 61 × 73 × 23 mm (height × width × depth) Power supply 5 V Max 500 mA Platform Telium 2 Functionality Contactless cards reader Buzzer Go cless link Wake-up + serial link Link 1x USB device 2.3.4 PIN PAD AND READER iUC150B INTERCONNECTIVITY The connection between the iUP250LE and the reader iUC150B Plug the USB cable on the iUP250LE and the iUC150B with is done through USB. the Ingenico standard USB cable USB-A – USB-JST with the part number 296189206 (30 cm, included in the box) or 296192761AB (1.15 m, accessory). -
Page 12: Installation Procedure In Kiosks
INSTALLATION PROCEDURE IN KIOSKS NOTE It is required to use ESD-protective clothing while handling these devices. All parts of the kiosk should be connected to the ground using ground cables or ground braid. SECURITY REQUIREMENTS The integration must be done to be compliant with the PCI-PTS If the machine or kiosk doesn’t provide such a protection, requirements. an Ingenico privacy shield option can be provided. The PIN pad iUP250LE is not equipped with its own privacy shield. The iUP250LE must be mounted on the unattended machine Therefore the PIN pad must be integrated in the machine or as indicated in the installation guide to activate the removal kiosk in a way to fulfil the requirements for concealed PIN entry. detectors. Ingenico recommends to supply the PIN shield according the specification “EPC343-08 Version 2.0 PRIVACY SHIELDING FOR PIN ENTRY”. GENERAL INSTALLATION RECOMMENDATIONS • E nsure that you have enough free space for installation, • C arefully consider the ergonomic aspects and also the local o perational and maintenance needs. acts or recommendations concerning disabled and visually • B e aware of the safety regulations. -
Page 13: Metalic Kiosk Grounding Consideration
METALIC KIOSK GROUNDING CONSIDERATION All parts of the kiosk should be connected to the ground using ground cables or ground braid. The devices have to be grounded according IEC 60950. Connect to ground... -
Page 14: Plastic Kiosk Grounding Consideration
PLASTIC KIOSK GROUNDING CONSIDERATION All parts of the kiosk should be connected to the ground using ground cables or ground braid. The devices have to be grounded according IEC 60950. Connect to ground... -
Page 15: Assembly Procedure For The Terminal
ASSEMBLY PROCEDURE FOR THE TERMINAL iUP250LE 4.1.1 KIOSK MINIMUM VOLUME FOR THE iUP250LE The iUP250LE requires minimum volume in the kiosk. The minimum volume is: • 1 01 mm width × 134 mm height × 28 mm depth It includes cables and pinshield mounting. (w/o Ethernet connectivity) 3D design on demand. • 1 01 mm width × 134 mm height × 35 mm depth (w/ Ethernet connectivity) Picture showing the minimum volume for the iUP250LE... -
Page 16: Kiosk Preparation For Iup250Le Installation
4.1.2 KIOSK PREPARATION FOR iUP250LE INSTALLATION The iUP250LE uses EVA mounting standard without additional CAUTION fixing studs. It requires a cut out in the kiosk to the dimensions It is important that the iUP250LE footprint s urface on the detailed in the diagram below (all dimensions are in millimeters). kiosk must be flat and cleared of any holes and burrs. The drawing below shows the footprint of iUP250 product. Special attention is required for the anti- r emoval switch areas. 3D step files are also available upon request. Fixing must be done by 4 × M4 × 16 mm welded studs. Drawing of the cut-out for the iUP250LE. Thickness of the panel: 2 mm... -
Page 17: Installation The Iup250Le Pin Pad In A New Kiosk
4.1.3 INSTALLATION THE iUP250LE PIN PAD IN A NEW KIOSK The iUP requires standards hexagonal nuts for integration It is recommended to use threadlocker fluid to prevent into a kiosk. u nscrewing with vibrations. Screw the 4 nuts with a 1.0 Nm torque. Picture showing a new installation of the iUP250 LE 89.5 mm Anti-removal switch area To be able to perform the commissioning procedure the PIN pad must be correctly mounted in the a nti-removal switch area. 50.8 mm The outside "holes" on the bottom are not available for mounting! Please use the inner holes at a distance of 50.8 mm. -
Page 18: Connecting The Iup250Le To The Kiosk Ground
4.1.4 CONNECTING THE iUP250LE TO THE KIOSK GROUND To insure good connexion of iUP250LE to the kiosk ground, on one specific area and connect this braid to the chassis. it is recommended to install one copper braid connected Torque value 1 Nm. Ground studs to connect copper braid to ground... -
Page 19: Iur250
iUR250 4.2.1 KIOSK PREPARATION FOR iUR250 INSTALLATION The iUR250 requires a cut-out in the kiosk. Dimensions in mm CAUTION detailed in the diagram below. The equivalent iUR250 hatched footprint s urface on the kisok must be flat and clear of any holes and burrs. Special attention is required for the area of the anti-removal switches. Fixing must be done by 4 M4 to M6 × 12 mm welded studs. iUR250 footprint area iUR250 Anti-removal switches area Cut-out drawing for iUR250 EVA EPS compact cut-out (rear mounting). 3D design is available on demand. -
Page 20: Layout Suggested For Iup250Le And Iur250 In A Kiosk
4.2.2 LAYOUT SUGGESTED FOR iUP250LE AND iUR250 IN A KIOSK I order to save space, keep good ergonomics and relative p rotection from environment, we recommend the following configurations. Vertical PIN pad above the reader Leaned backward PIN pad above vertical reader 23 mm Minimum distance between reader and Minimum distance between reader and PIN pad PIN pad is 23 mm. is 25 mm to allow access to cables. PIN shield must be managed separately! -
Page 21: Iuc150B
iUC150B 4.3.1 KIOSK PREPARATION FOR iUC150B INSTALLATION The reader iUC150B does not require any v olume inside the The surface must be flat and without any burrs and without kiosk cabinet. any sharp edges. The label with the PCI hardware version n umber must be To fix the iUC150B four screws M4 are required. v isibile once the device is installed. The length of the screw is depending on the panel thickness The reader can be mounted directly on the kiosk panel. It or front face. requires a cut-out in the kiosk to the dimensions detailed in the diagram below. All dimensions are in millimeters. Installation of iUC150B: Footprint and cut-out of front side. -
Page 22: Additional Information For Non-Voluntary Contactless Reading
Equipment front face The length of the screws is 5 mm (+0/– 1 mm) + thickness of panel. The thread depth of the reader is 5.9 mm. The torque is 0.6 to 0.75 Nm. The dimensions of the reader iUC150B allow also mounting into the EVA EPS c ompact cut-out (rear mounting). 4.3.2 ADDITIONAL INFORMATION FOR NON-VOLUNTARY CONTACTLESS READING The sensitive area (in blue) must be kept free in order to avoid non voluntary contactless reading. 8 cm 8 cm 8 cm... - Page 23 YOUR LOCAL POINT OF CONTACT CAN BE FOUND AT: six-payment-services.com/contacts six-payment-services.com worldline.com 110.0613.02 CHE_EN/05.2020...
