Mocka Eclipse Entertainment Unit Assembly Instructions Manual page 3

Eclipse Entertainment Unit
Assembly Instructions
3
D
A
A
4
Attach panels [4] and [5] to panel [7] with 4x big dowels (A) and
secure with 4x locking nuts (D). Tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
D
A
D
A
D
7
4
5
4
A
D
A
A
Attach panels [3], [4], [5] and [6] to panel [1] with 6x big dowels (A) and
2x dowels (P) and secure with 6x locking nuts (D). Tighten with a screwdriver.
3
D
6
A D
A
P
P
D
1
3
