ST EP 3
• Slide the pre-installed screw and work surface into the slotted position.
• Hand tighten all 3 screws with the 6mm ball point allen wrench. Then tighten
all 3 screws securely using the short end side of the allen wrench.
Step 3
Slide the pre-installed screw and work surface into the slotted position. Hand
tighten all 3 screws with the 6mm ball point allen wrench. Then tighten all 3
screws securely using the short end side of the allen wrench.
ST EP 4
• Attach lower cover.
ST EP 5
• Install the Vesa plate onto the monitor(s).
4
X 3
X 3
Step 4
Attach lower cover.
