Connections to the Zero -3 stepper motor controlle r
2
2.1

Front side

1
Front side Overview
1 Connector D-Sub 9pol. for motor X1
2 Connector D-Sub 9pol. for motor X2 (not use for T-Rex)
3 Connector D-Sub 9pol. for motor Y
4 Connector D-Sub 9pol. for motor Z
5 Connector D-Sub 15pol. for 4th axis (Rotary axis / tangential knife)
6 Connector D-Sub 9pol. for Control line ST
7 Emergency-stop-button
8 Power-button
9 Status-LEDs
CNC-STEP e.K. ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
7
2 3 4 5 6 9
Quick Start Guide
T-Rex Series
8
Zero-3 Front Side
